KX400, KX420, KX500 ENGINE PARTS AND FRAME
IDENTIFICATION
In an effort to help fellow bikers properly ID their bike I have provided the following information on VIN ( Vehicle Identification Number ) , Engine ID and part identification.
All the information provided is to the best of my knowledge correct.
As we part more bikes out we will add more information to this chart.
If you find something that is not accurate, please let us know and we will fix it.
This information is not intended for use outside of this web site or for publication.
In other words, use this information at your own risk.
Scroll to the right as there is a lot of data :-)
Need parts for your KX500? Click on this link
Need technical specifications for your KX500? Click on this link
Need parts for your KX500? Click on this link
Need technical specifications for your KX500? Click on this link
| YEAR | TYPE | VIN FRAME USA | ENGINE ID | ENGINE CASES | AIR BOX CAGE ELEMENT HOLDER | AIR BOX NO BOOT (DUCT) | YEAR | TYPE | AIR BOX BOOT JOINT DUCT | CABLE CLUTCH | CABLE THROTTLE | CARBURETOR | YEAR | TYPE | CARBURETOR FLOAT VALVE | CARBURETOR BOOT | CDI | YEAR | TYPE | CHAIN ADJUSTER BLOCKS | CHAIN GUIDE | YEAR | TYPE | CHAIN SLIDE | CLUTCH ARM | CLUTCH BASKET | CLUTCH FRICTION PLATES | CLUTCH COVER | CLUTCH HUB (INNER) | CLUTCH PRESSURE PLATE (OUTER) | YEAR | TYPE | COIL | COUNTER SPROCKET GUARD PLASTIC | CRANK SHAFT | CRANK SHAFT ROD KIT HOT RODS | CYLINDER | YEAR | TYPE | CYLINDER WATER NECK ELBOW | ENGINE MOUNTS FRONT | ENGINE MOUNTS UPPER | EXHAUST PIPE | EXHAUST PIPE FMF GNARLY | YEAR | TYPE | EXHAUST PIPE PRO CIRCUIT PLATINUM | EXHAUST PIPE PRO CIRCUIT PLATINUM 2 | EXHAUST PIPE PRO CIRCUIT WORKS | EXHAUST VALVE | EXHAUST VALVE COVER FRONT | EXHAUST VALVE COVER RIGHT | YEAR | TYPE | FLY WHEEL | FOOT PEGS | YEAR | TYPE | FOOT PEG SPRINGS | FORK | FORK SEAL SIZES | YEAR | TYPE | FORK GUARDS | FORK GUARD MOUNTS | FORK UNDER HOLDER (STEERING STEM LOWER CLAMP) TRIPLE TREE | FORK UPPER HOLDER (TOP CLAMP) TRIPLE TREE | YEAR | TYPE | FORK HOLDER BEARINGS (LOWER) | FORK HOLDER BEARINGS (UPPER) | YEAR | TYPE | FRONT AXLE | FRONT AXLE HOLDER | FRONT AXLE SPACERS COLLARS | FRONT BRAKE CALIPER | YEAR | TYPE | FRONT BRAKE CALIPER MOUNT | FRONT BRAKE HOSE | FRONT BRAKE LEVER | YEAR | TYPE | FRONT BRAKE MASTER CYLINDER | FRONT BRAKE ROTOR | YEAR | TYPE | FRONT BRAKE ROTOR GUARD | FRONT FENDER | FRONT HUB | YEAR | TYPE | FUEL/GAS TANK | GAS TANK CAP | YEAR | TYPE | GOVERNOR | GOVERNOR LEVER | GOVERNOR SHAFT | GOVERNOR WATER PUMP SPUR GEAR | GOVERNOR WEIGHT HOLDER | HEAD | KICK IDLER GEAR | KICK LEVER | YEAR | TYPE | KICK LEVER SHAFT | MUD FLAP | NUMBER PLATE | OIL CAPACITY | OIL DRAIN PLUG | PETCOCK FUEL VALVE TAP | PISTON | WISECO STD PISTON | YEAR | TYPE | PRIMARY CRANK GEAR | RADIATORS | RADIATOR SCREENS | RADIATOR SHROUDS | RADIATOR SHROUD RIGHT | YEAR | TYPE | REAR AXLE | REAR BRAKE BACKING PLATE | YEAR | REAR BRAKE CALIPER | REAR BRAKE CALIPER GUARD | REAR BRAKE CALIPER GUARD | REAR BRAKE CALIPER MOUNT | REAR BRAKE HOSE | YEAR | TYPE | REAR BRAKE ROTOR | REAR BRAKE LEVER | REAR BRAKE MASTER CYLINDER | YEAR | TYPE | REAR FENDER | REAR HUB | YEAR | TYPE | REAR WHEEL SPACERS | YEAR | TYPE | REED VALVE | SEAT | SHIFT DRUM | SHIFT FORKS | SHIFT LEVER | SHIFT SHAFT | YEAR | TYPE | SHOCK | SHOCK ARM LINKAGE UNI TRAK | SHOCK ARM SUSPENSION RODS (DOG BONES) | YEAR | TYPE | SHOCK BRACKETS | SIDE COVER LEFT | SIDE COVER RIGHT | YEAR | TYPE | STATOR | YEAR | TYPE | STATOR COVER | SUB FRAME | SWING ARM | SWING ARM PIVOT PIN | YEAR | TYPE | THROTTLE ASY | TRANSMISSION | TRANSMISSION INPUT SHAFT | TRANSMISSION INPUT 2ND GEAR | YEAR | TYPE | TRANSMISSION INPUT 3RD GEAR | TRANSMISSION INPUT 4TH GEAR | TRANSMISSION INPUT 5TH GEAR | TRANSMISSION OUTPUT SHAFT | TRANSMISSION OUTPUT SHAFT NUT | YEAR | TYPE | TRANSMISSION OUTPUT 1ST GEAR | TRANSMISSION OUTPUT 2ND GEAR | YEAR | TYPE | TRANSMISSION OUTPUT 3RD GEAR | TRANSMISSION OUTPUT 4TH GEAR | TRANSMISSION OUTPUT 5TH GEAR | WATER PUMP COVER | YEAR | TYPE | WATER PUMP COVER NECK | YEAR | TYPE | WATER PUMP IMPELLER | WATER PUMP NECK ELBOW | |
| 1975 | KX400 | FITS 75 KX400, 80-81 KX420, 79-80 KDX450 | 1975 | KX400 | 1975 | KX400 | 1975 | KX400 | 1975 | KX400 | 1975 | KX400 | N/A | 1975 | KX400 | N/A | N/A | 1975 | KX400 | N/A | N/A | N/A | NO VALVE | 1975 | KX400 | MR2393 FITS 74-79 KX125 KX250, 75 KX400, 80-81 KX420 | 1975 | KX400 | CONVENTIONAL – CHROME OD 35MM | 35MM X 48MM X 10.5/11 | 1975 | KX400 | CONVENTIONAL | 1975 | KX400 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1975 | KX400 | 1975 | KX400 | DRUM STYLE | 1975 | KX400 | DRUM STYLE | DRUM STYLE | 1975 | KX400 | DRUM STYLE | 15MM AXLE DIA - BRG TO BRG 76-77MM - DRUM MAX DIA 140.75MM - FITS 74, 76, 78-81 KX250 - 75 KX400 - 80-81 KX420 | 1975 | KX400 | LIME GREEN – 51001-095-2G | 1975 | KX400 | N/A | FITS 75 KX400, 79-82 KDX450, 80-81 KX250 KX420, 83-84 KX500 - 13064-5003 | 1975 | KX400 | N/A | 1975 | KX400 | AIR COOLED | AIR COOLED | AIR COOLED | AIR COOLED | 1975 | KX400 | DRUM 150.75MM MAX DIA - FITS 74-76 78-79 KX250, 75-76 KX400 - 42006-059 | 1975 | DRUM BRAKE | DRUM BRAKE | 1975 | KX400 | DRUM BRAKE | DRUM BRAKE | 1975 | KX400 | BLACK - FITS 74 76-79 KX250, 75 KX400 - 35022-132-10 | 17MM AXLE DIA - BRG TO BRG133-134MM - DRUM 150.75MM MAX DIA - FITS 74-76 78-79 KX250, 75-76 KX400 - 42005-045-21 | 1975 | KX400 | 1975 | KX400 | 1975 | KX400 | 1975 | KX400 | 1975 | KX400 | FITS 75-76 KX400 - 21003-029 | 1975 | KX400 | PART OF MAIN FRAME | 1975 | KX400 | 1975 | KX400 | 1975 | KX400 | 1975 | KX400 | N/A | 1975 | KX400 | 1975 | KX400 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 1976 | KX400 | 1976 | KX400 | 1976 | KX400 | 1976 | KX400 | 1976 | KX400 | 1976 | KX400 | N/A | 1976 | KX400 | 1976 | KX400 | 1976 | KX400 | 1976 | KX400 | CONVENTIONAL – CHROME OD 36MM | 36MM X 48MM X 10.5/11 | 1976 | KX400 | CONVENTIONAL | 1976 | KX400 | 1976 | KX400 | 1976 | KX400 | DRUM STYLE | 1976 | KX400 | DRUM STYLE | DRUM STYLE | 1976 | KX400 | DRUM STYLE | 1976 | KX400 | 1976 | KX400 | N/A | 1976 | KX400 | 1976 | KX400 | 1976 | KX400 | DRUM 150.75MM MAX DIA - FITS 74-76 78-79 KX250, 75-76 KX400 - 42006-059 | 1976 | DRUM BRAKE | 1976 | KX400 | 1976 | KX400 | 17MM AXLE DIA - BRG TO BRG133-134MM - DRUM 150.75MM MAX DIA - FITS 74-76 78-79 KX250, 75-76 KX400 - 42005-045-21 | 1976 | KX400 | 1976 | KX400 | 1976 | KX400 | 1976 | KX400 | 1976 | KX400 | FITS 75-76 KX400 - 21003-029 | 1976 | KX400 | PART OF MAIN FRAME | 1976 | KX400 | 1976 | KX400 | 1976 | KX400 | 1976 | KX400 | N/A | 1976 | KX400 | 1976 | KX400 | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| YEAR | TYPE | VIN FRAME USA | ENGINE ID | ENGINE CASES | AIR BOX CAGE ELEMENT HOLDER | AIR BOX NO BOOT (DUCT) | YEAR | TYPE | AIR BOX BOOT JOINT DUCT | CABLE CLUTCH | CABLE THROTTLE | CARBURETOR | YEAR | TYPE | CARBURETOR FLOAT VALVE | CARBURETOR BOOT | CDI | YEAR | TYPE | CHAIN ADJUSTER BLOCKS | CHAIN GUIDE | YEAR | TYPE | CHAIN SLIDE | CLUTCH ARM | CLUTCH BASKET | CLUTCH FRICTION PLATES | CLUTCH COVER | CLUTCH HUB (INNER) | CLUTCH PRESSURE PLATE (OUTER) | YEAR | TYPE | COIL | COUNTER SPROCKET GUARD PLASTIC | CRANK SHAFT | CRANK SHAFT ROD KIT HOT RODS | CYLINDER | YEAR | TYPE | CYLINDER WATER NECK ELBOW | ENGINE MOUNTS FRONT | ENGINE MOUNTS UPPER | EXHAUST PIPE | EXHAUST PIPE FMF GNARLY | YEAR | TYPE | EXHAUST PIPE PRO CIRCUIT PLATINUM | EXHAUST PIPE PRO CIRCUIT PLATINUM 2 | EXHAUST PIPE PRO CIRCUIT WORKS | EXHAUST VALVE | EXHAUST VALVE COVER FRONT | EXHAUST VALVE COVER RIGHT | YEAR | TYPE | FLY WHEEL | FOOT PEGS | YEAR | TYPE | FOOT PEG SPRINGS | FORK | FORK SEAL SIZES | YEAR | TYPE | FORK GUARDS | FORK GUARD MOUNTS | FORK UNDER HOLDER (STEERING STEM LOWER CLAMP) TRIPLE TREE | FORK UPPER HOLDER (TOP CLAMP) TRIPLE TREE | YEAR | TYPE | FORK HOLDER BEARINGS (LOWER) | FORK HOLDER BEARINGS (UPPER) | YEAR | TYPE | FRONT AXLE | FRONT AXLE HOLDER | FRONT AXLE SPACERS COLLARS | FRONT BRAKE CALIPER | YEAR | TYPE | FRONT BRAKE CALIPER MOUNT | FRONT BRAKE HOSE | FRONT BRAKE LEVER | YEAR | TYPE | FRONT BRAKE MASTER CYLINDER | FRONT BRAKE ROTOR | YEAR | TYPE | FRONT BRAKE ROTOR GUARD | FRONT FENDER | FRONT HUB | YEAR | TYPE | FUEL/GAS TANK | GAS TANK CAP | YEAR | TYPE | GOVERNOR | GOVERNOR LEVER | GOVERNOR SHAFT | GOVERNOR WATER PUMP SPUR GEAR | GOVERNOR WEIGHT HOLDER | HEAD | KICK IDLER GEAR | KICK LEVER | YEAR | TYPE | KICK LEVER SHAFT | MUD FLAP | NUMBER PLATE | OIL CAPACITY | OIL DRAIN PLUG | PETCOCK FUEL VALVE TAP | PISTON | WISECO STD PISTON | YEAR | TYPE | PRIMARY CRANK GEAR | RADIATORS | RADIATOR SCREENS | RADIATOR SHROUDS | RADIATOR SHROUD RIGHT | YEAR | TYPE | REAR AXLE | REAR BRAKE BACKING PLATE | YEAR | REAR BRAKE CALIPER | REAR BRAKE CALIPER GUARD | REAR BRAKE CALIPER GUARD | REAR BRAKE CALIPER MOUNT | REAR BRAKE HOSE | YEAR | TYPE | REAR BRAKE ROTOR | REAR BRAKE LEVER | REAR BRAKE MASTER CYLINDER | YEAR | TYPE | REAR FENDER | REAR HUB | YEAR | TYPE | REAR WHEEL SPACERS | YEAR | TYPE | REED VALVE | SEAT | SHIFT DRUM | SHIFT FORKS | SHIFT LEVER | SHIFT SHAFT | YEAR | TYPE | SHOCK | SHOCK ARM LINKAGE UNI TRAK | SHOCK ARM SUSPENSION RODS (DOG BONES) | YEAR | TYPE | SHOCK BRACKETS | SIDE COVER LEFT | SIDE COVER RIGHT | YEAR | TYPE | STATOR | YEAR | TYPE | STATOR COVER | SUB FRAME | SWING ARM | SWING ARM PIVOT PIN | YEAR | TYPE | THROTTLE ASY | TRANSMISSION | TRANSMISSION INPUT SHAFT | TRANSMISSION INPUT 2ND GEAR | YEAR | TYPE | TRANSMISSION INPUT 3RD GEAR | TRANSMISSION INPUT 4TH GEAR | TRANSMISSION INPUT 5TH GEAR | TRANSMISSION OUTPUT SHAFT | TRANSMISSION OUTPUT SHAFT NUT | YEAR | TYPE | TRANSMISSION OUTPUT 1ST GEAR | TRANSMISSION OUTPUT 2ND GEAR | YEAR | TYPE | TRANSMISSION OUTPUT 3RD GEAR | TRANSMISSION OUTPUT 4TH GEAR | TRANSMISSION OUTPUT 5TH GEAR | WATER PUMP COVER | YEAR | TYPE | WATER PUMP COVER NECK | YEAR | TYPE | WATER PUMP IMPELLER | WATER PUMP NECK ELBOW | KX500 ENGINE WEIGHT |
| 1980 | KX420 | FITS 75 KX400, 80-81 KX420, 79-80 KDX450 | 1980 | KX420 | 1980 | KX420 | 1980 | KX420 | 1980 | KX420 | FITS 80-81 KX125 KX250 KX420 12053-1046 | 1980 | KX420 | N/A | 1980 | KX420 | N/A | N/A | 1980 | KX420 | N/A | N/A | N/A | NO VALVE | 1980 | KX420 | MR2393 FITS 74-79 KX125 KX250, 75 KX400, 80-81 KX420 | 1980 | KX420 | CONVENTIONAL – CHROME OD 38MM – C/L 36 5/16” - 15MM AXLE CLAMP – M14 X 1.5 – OAL 42.5” - FITS 80-81 KX250 KX420 – 44001-1118 | 38MM X 50MM X 10.5 | 1980 | KX420 | CONVENTIONAL | 1980 | KX420 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1980 | KX420 | 15MM OD, THREADS M14 X 1.5 – FITS 74-76 78-81 KX250, 80-81 KX420 – 41068-1006 | 1980 | KX420 | DRUM STYLE | 1980 | KX420 | DRUM STYLE | DRUM STYLE | 1980 | KX420 | DRUM STYLE | 15MM AXLE DIA - BRG TO BRG 76-77MM - DRUM MAX DIA 140.75MM - FITS 74, 76, 78-81 KX250 - 75 KX400 - 80-81 KX420 | 1980 | KX420 | GREEN – FITS 80-81 KX250 KX420 – 51001-1030-7F | 1980 | KX420 | FITS 75 KX400, 79-82 KDX450, 80-81 KX250 KX420, 83-84 KX500 - 13064-5003 | 1980 | KX420 | N/A | 1980 | KX420 | 26T - FITS 80-81 KX420, 79-80 KDX400, 80-81 KDX420 - 13097-1019 | AIR COOLED | AIR COOLED | AIR COOLED | AIR COOLED | 1980 | KX420 | FITS 80-81 KX250 KX420, 80 KDX250, 79-80 KDX400 - 41035-4001 | 1980 | DRUM BRAKE | DRUM BRAKE | 1980 | KX420 | DRUM BRAKE | DRUM BRAKE | 1980 | KX420 | GREEN - FITS 80-81 KX125 KX250 KX420 - 35022-1043-6W | 17MM AXLE DIA - BRG TO BRG133-134MM - DRUM 150.75MM MAX DIA - FITS 80-81 KX250 KX420, 80-82 KDX250, 81-82 KDX450 - 41034-1019 | 1980 | KX420 | 1980 | KX420 | 1980 | KX420 | 1980 | KX420 | 1980 | KX420 | FITS 74-79 KX250, 80-81 KX420 - 21003-1010 | 1980 | KX420 | PART OF MAIN FRAME | FITS 80-81 KX250 KX420 - 33001-1043 | 1980 | KX420 | 1980 | KX420 | FITS 83-87 KX500, 80-81 KX420, 74-79 KX250, 79-80 KDX400, 81-82 KDX420 - 42045-008 - M24X1.0 | 1980 | KX420 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 32T - FITS 80-81 KX420, 83-85 KX500 - 13129-1622 | 1980 | KX420 | FITS 80-81 KX420, 83-85 KX500 - 13129-1679 | FITS 80-81 KX420, 83-85 KX500, 79-80 KDX400 - 13129-1132 | FITS 80-81 KX420, 83-87 KX500, 79-80 KDX400, 81 KDX420, 82 KDX450 - 13129-1133 | N/A | 1980 | KX420 | 1980 | KX420 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 1981 | KX420 | KX420AE00XXXX | FITS 75 KX400, 80-81 KX420, 79-80 KDX450 | 1981 | KX420 | 1981 | KX420 | A1 | 21119-1001 CU1172 | 1981 | KX420 | 1981 | KX420 | FITS 80-81 KX125 KX250 KX420 12053-1046 | 1981 | KX420 | N/A | 1981 | KX420 | N/A | N/A | 1981 | KX420 | N/A | N/A | N/A | NO VALVE | 1981 | KX420 | MR2393 FITS 74-79 KX125 KX250, 75 KX400, 80-81 KX420 | 1981 | KX420 | CONVENTIONAL – CHROME OD 38MM – C/L 36 5/16” - 15MM AXLE CLAMP – M14 X 1.5 – OAL 42.5” - FITS 80-81 KX250 KX420 – 44001-1118 | 38MM X 50MM X 10.5 | 1981 | KX420 | CONVENTIONAL | 1981 | KX420 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1981 | KX420 | 15MM OD, THREADS M14 X 1.5 – FITS 74-76 78-81 KX250, 80-81 KX420 – 41068-1006 | 1981 | KX420 | DRUM STYLE | 1981 | KX420 | DRUM STYLE | DRUM STYLE | 1981 | KX420 | DRUM STYLE | 15MM AXLE DIA - BRG TO BRG 76-77MM - DRUM MAX DIA 140.75MM - FITS 74, 76, 78-81 KX250 - 75 KX400 - 80-81 KX420 | 1981 | KX420 | GREEN – FITS 80-81 KX250 KX420 – 51001-1030-7F | 1981 | KX420 | 1030 | FITS 75 KX400, 79-82 KDX450, 80-81 KX250 KX420, 83-84 KX500 - 13064-5003 | 1981 | KX420 | 1.0 LITER | N/A | 1981 | KX420 | 26T - FITS 80-81 KX420, 79-80 KDX400, 80-81 KDX420 - 13097-1019 | AIR COOLED | AIR COOLED | AIR COOLED | AIR COOLED | 1981 | KX420 | FITS 80-81 KX250 KX420, 80 KDX250, 79-80 KDX400 - 41035-4001 | 1981 | DRUM BRAKE | DRUM BRAKE | 1981 | KX420 | DRUM BRAKE | DRUM BRAKE | 1981 | KX420 | GREEN - FITS 80-81 KX125 KX250 KX420 - 35022-1043-6W | 17MM AXLE DIA - BRG TO BRG133-134MM - DRUM 150.75MM MAX DIA - FITS 80-81 KX250 KX420, 80-82 KDX250, 81-82 KDX450 - 41034-1019 | 1981 | KX420 | 1981 | KX420 | 1981 | KX420 | 1981 | KX420 | 1981 | KX420 | FITS 74-79 KX250, 80-81 KX420 - 21003-1010 | 1981 | KX420 | -1 | PART OF MAIN FRAME | FITS 80-81 KX250 KX420 - 33001-1043 | 1981 | KX420 | 1981 | KX420 | FITS 83-87 KX500, 80-81 KX420, 74-79 KX250, 79-80 KDX400, 81-82 KDX420 - 42045-008 - M24X1.0 | 1981 | KX420 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 32T - FITS 80-81 KX420, 83-85 KX500 - 13129-1622 | 1981 | KX420 | FITS 80-81 KX420, 83-85 KX500 - 13129-1679 | FITS 80-81 KX420, 83-85 KX500, 79-80 KDX400 - 13129-1132 | FITS 80-81 KX420, 83-87 KX500, 79-80 KDX400, 81 KDX420, 82 KDX450 - 13129-1133 | N/A | 1981 | KX420 | 1981 | KX420 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| YEAR | TYPE | VIN FRAME USA | ENGINE ID | ENGINE CASES | AIR BOX CAGE ELEMENT HOLDER | AIR BOX NO BOOT (DUCT) | YEAR | TYPE | AIR BOX BOOT JOINT DUCT | CABLE CLUTCH | CABLE THROTTLE | CARBURETOR | YEAR | TYPE | CARBURETOR FLOAT VALVE | CARBURETOR BOOT | CDI | YEAR | TYPE | CHAIN ADJUSTER BLOCKS | CHAIN GUIDE | YEAR | TYPE | CHAIN SLIDE | CLUTCH ARM | CLUTCH BASKET | CLUTCH FRICTION PLATES | CLUTCH COVER | CLUTCH HUB (INNER) | CLUTCH PRESSURE PLATE (OUTER) | YEAR | TYPE | COIL | COUNTER SPROCKET GUARD PLASTIC | CRANK SHAFT | CRANK SHAFT ROD KIT HOT RODS | CYLINDER | YEAR | TYPE | CYLINDER WATER NECK ELBOW | ENGINE MOUNTS FRONT | ENGINE MOUNTS UPPER | EXHAUST PIPE | EXHAUST PIPE FMF GNARLY | YEAR | TYPE | EXHAUST PIPE PRO CIRCUIT PLATINUM | EXHAUST PIPE PRO CIRCUIT PLATINUM 2 | EXHAUST PIPE PRO CIRCUIT WORKS | EXHAUST VALVE | EXHAUST VALVE COVER FRONT | EXHAUST VALVE COVER RIGHT | YEAR | TYPE | FLY WHEEL | FOOT PEGS | YEAR | TYPE | FOOT PEG SPRINGS | FORK | FORK SEAL SIZES | YEAR | TYPE | FORK GUARDS | FORK GUARD MOUNTS | FORK UNDER HOLDER (STEERING STEM LOWER CLAMP) TRIPLE TREE | FORK UPPER HOLDER (TOP CLAMP) TRIPLE TREE | YEAR | TYPE | FORK HOLDER BEARINGS (LOWER) | FORK HOLDER BEARINGS (UPPER) | YEAR | TYPE | FRONT AXLE | FRONT AXLE HOLDER | FRONT AXLE SPACERS COLLARS | FRONT BRAKE CALIPER | YEAR | TYPE | FRONT BRAKE CALIPER MOUNT | FRONT BRAKE HOSE | FRONT BRAKE LEVER | YEAR | TYPE | FRONT BRAKE MASTER CYLINDER | FRONT BRAKE ROTOR | YEAR | TYPE | FRONT BRAKE ROTOR GUARD | FRONT FENDER | FRONT HUB | YEAR | TYPE | FUEL/GAS TANK | GAS TANK CAP | YEAR | TYPE | GOVERNOR | GOVERNOR LEVER | GOVERNOR SHAFT | GOVERNOR WATER PUMP SPUR GEAR | GOVERNOR WEIGHT HOLDER | HEAD | KICK IDLER GEAR | KICK LEVER | YEAR | TYPE | KICK LEVER SHAFT | MUD FLAP | NUMBER PLATE | OIL CAPACITY | OIL DRAIN PLUG | PETCOCK FUEL VALVE TAP | PISTON | WISECO STD PISTON | YEAR | TYPE | PRIMARY CRANK GEAR | RADIATORS | RADIATOR SCREENS | RADIATOR SHROUDS | RADIATOR SHROUD RIGHT | YEAR | TYPE | REAR AXLE | REAR BRAKE BACKING PLATE | YEAR | REAR BRAKE CALIPER | REAR BRAKE CALIPER GUARD | REAR BRAKE CALIPER GUARD | REAR BRAKE CALIPER MOUNT | REAR BRAKE HOSE | YEAR | TYPE | REAR BRAKE ROTOR | REAR BRAKE LEVER | REAR BRAKE MASTER CYLINDER | YEAR | TYPE | REAR FENDER | REAR HUB | YEAR | TYPE | REAR WHEEL SPACERS | YEAR | TYPE | REED VALVE | SEAT | SHIFT DRUM | SHIFT FORKS | SHIFT LEVER | SHIFT SHAFT | YEAR | TYPE | SHOCK | SHOCK ARM LINKAGE UNI TRAK | SHOCK ARM SUSPENSION RODS (DOG BONES) | YEAR | TYPE | SHOCK BRACKETS | SIDE COVER LEFT | SIDE COVER RIGHT | YEAR | TYPE | STATOR | YEAR | TYPE | STATOR COVER | SUB FRAME | SWING ARM | SWING ARM PIVOT PIN | YEAR | TYPE | THROTTLE ASY | TRANSMISSION | TRANSMISSION INPUT SHAFT | TRANSMISSION INPUT 2ND GEAR | YEAR | TYPE | TRANSMISSION INPUT 3RD GEAR | TRANSMISSION INPUT 4TH GEAR | TRANSMISSION INPUT 5TH GEAR | TRANSMISSION OUTPUT SHAFT | TRANSMISSION OUTPUT SHAFT NUT | YEAR | TYPE | TRANSMISSION OUTPUT 1ST GEAR | TRANSMISSION OUTPUT 2ND GEAR | YEAR | TYPE | TRANSMISSION OUTPUT 3RD GEAR | TRANSMISSION OUTPUT 4TH GEAR | TRANSMISSION OUTPUT 5TH GEAR | WATER PUMP COVER | YEAR | TYPE | WATER PUMP COVER NECK | YEAR | TYPE | WATER PUMP IMPELLER | WATER PUMP NECK ELBOW | KX500 ENGINE WEIGHT |
| 1983 | KX500 | JKAKXVA1-DA--XXXX | KX500AE000001-001500 | FITS 83-85 KX500 - 14001-5158 | FITS 83-84 KX250 11011-1115 | 1983 | KX500 | FITS 83-84 KX500 - 14073-1079 | FITS 84-85 KXT, 83-85 KX250, 83-84 KX500 - 54011-1112 | FITS 85 KX250, 83-85 KX500 - 54012-1211 | MIKUNI 38MM - FITS 83-84 KX500 | 1983 | KX500 | FITS 83-84 KX500 | FITS 83-85 KX500 – 21119-1133 | 1983 | KX500 | FITS 82-83 KX125, 83-85 KX250 & KX500, 83 KDX200 & KDX250 | 1983 | KX500 | FITS 83-85 KX250, 83-84 KX500, 84-85 KXT250 13102-1077 | FITS 83-84 KX500 - 13095-1103 | FITS 83-84 KX500 - 14032-1079 | FITS 80-84 KX250 KDX250, 83-84 KX500 - 13087-044 | FITS 83-84 KDX250, 83-86 KX250 KX500, 84-87 KXT - 13187-1011 | 1983 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | FITS 82-87 KX125, 83-87 KX250 KX500 KDX200, 84-87 KXT250 - 14026-1119 | FITS 83-84 KX500 - 86MM STD STROKE - 13031-1074 | N/A | FITS 83-84 KX500 - 11005-1188 | 1983 | KX500 | N/A | FITS 83-84 KX500 | N/A | 1983 | KX500 | N/A | N/A | N/A | NO VALVE | 1983 | KX500 | F3T205 FITS 83-85 KX500 - 21007-1052 | FITS 83-84 KX250 & KX500 - 34028-1050 - 34028-1051 | 1983 | KX500 | 83-87 KX250 KX500, 84-87 KX125, 84-94 KDX200 | CHROME OD 43MM - C/L 36 5/8" - C/L OF CALIPER MOUNTS 62MM - AXLE CLAMP 20MM | 43MM X 55MM X 9.5/10.5/11 | 1983 | KX500 | CONVENTIONAL | FITS 83-84 KX250, KX500, 84 KX125 | FITS 83-84 KX250, KX500 | 1983 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1983 | KX500 | FITS 82-83 KX125, 82-84 KX250, 83-84 KX500 | FITS 82-86 KX125, 83-86 KX250 KX500, 86-87 KDX200 | 1983 | KX500 | FITS 82-86 KX125, 83-86 KX250 KX250 - PART OF CALIPER ASY 43041-1084 | FITS 82-86 KX125 KX250, 83-86 KX500, 84-87 KX80, 86-88 KDX200, 46092-1108 | 1983 | KX500 | FITS 82-86 KX125 & KX250, 83-86 KX500, 84-87 KX80, 86-88 KDX200 - 43015-1281 | OD 250MM - ID 129.5MM - BC 8 ON 146MM - FITS 82-84 KX125 & KX250, 83-84 KX500 | 1983 | KX500 | PAT 585875 - 17MM AXLE DIA - BRG TO BRG 102MM - ROTOR 8 ON A 145MM BC - FITS 82-83 KX125, 82-84 KX250, 83-84 KX500 - 36 SPOKES | 1983 | KX500 | GREEN - FITS 83-84 KX500 51001-5384-6W | 1983 | KX500 | FITS 83-84 KX500 | 27T - FITS 83-85 KX500 - 59051-1107 | FITS 75 KX400, 79-82 KDX450, 80-81 KX250 KX420, 83-84 KX500 - 13064-5003 | 1983 | KX500 | FITS 83-84 KX500 | 800 ML = .846 QUARTS | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | FITS 83-84 KX500 – 13001-1088 | N/A | 1983 | KX500 | 25T - FITS 83-84 KX500 - 13097-1060 | AIR COOLED | AIR COOLED | AIR COOLED | AIR COOLED | 1983 | KX500 | 41035-1107 FOR 130MM DRUM – IT SHOULD FIT 82-83 KX125, 82-84 KX250, 83-84 KX500 | 1983 | DRUM BRAKE | DRUM BRAKE | 1983 | KX500 | DRUM BRAKE | FITS 83-84 KX250 KX500 43001-1159 | DRUM BRAKE | 1983 | KX500 | GREEN - FITS 82-83 KX125, 82-84 KX250, 83-84 KX500 - 35022-1204-AE | PAT 585873 - 17MM AXLE DIA - BRG TO BRG 131-132MM - DRUM 130MM ID - SPROCKET 6 ON A 150MM BC - FITS 82-83 KX125, 82-84 KX250, 83-84 KX500 - 41034-5005 | 1983 | KX500 | 1983 | KX500 | FITS 83-84 KX500 | FITS 83-85 KX500 | FITS 83-86 KX250, KX500 - 13242-1166 | FITS 83-86 KX500 | 1983 | KX500 | FITS 83-84 KX250 KX500 -39007-1052 | 1983 | KX500 | GREEN - FITS 82-83 KX125, 82-84 KX250, 83-84 KX500 - 36001-1146-6W | GREEN - FITS 82-83 KX125, 82-84 KX250, 83-84 KX500 - 36001-1147-6W | 1983 | KX500 | FITS 83-85 KX500 - 21003-1109 - 336-504 OHMS BLACK/RED TO BLACK YELLOW - 14.2-21.4 OHMS RED TO BLACK/YELLOW - 10.4-15.6 OHMS WHITE/RED TO BLACK/YELLOW | 1983 | KX500 | BLACK FITS 83-04 KX500 - 14031-1091 | PART OF MAIN FRAME | FITS 83-84 KX250 KX500 - 33001-1205 | FITS 82-86 KX125, 82-84 KX250, 83-84 KX500, 81-84 KDX250, 83-85 KDX200, 84-85 KXT250 - 33032-1042 | 1983 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | FITS 83-84 KX500 - 13127-1126 | 22T - FITS 83-85 KX500 - 13129-1407 | 1983 | KX500 | 22T - FITS 83-85 KX500 - 13129-1408 | 22T - FITS 83-85 KX500 - 13129-1409 | 24T - FITS 83-85 KX500, 84-86 KL600, 87-96 KLR650 - 13129-1410 | FITS 83-85 KX500 - 13128-1042 | FITS 83-87 KX500, 80-81 KX420, 74-79 KX250, 79-80 KDX400, 81-82 KDX420 - 42045-008 - M24X1.0 | 1983 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 32T - FITS 80-81 KX420, 83-85 KX500 - 13129-1622 | 1983 | KX500 | FITS 80-81 KX420, 83-85 KX500 - 13129-1679 | FITS 80-81 KX420, 83-85 KX500, 79-80 KDX400 - 13129-1132 | FITS 80-81 KX420, 83-87 KX500, 79-80 KDX400, 81 KDX420, 82 KDX450 - 13129-1133 | N/A | 1983 | KX500 | 1983 | KX500 | |||||||||||||||||||||||||||||||||||||||
| 1984 | KX500 | JKAKXVA1-EA--0015 | KX500AE0015001-002400 | FITS 83-85 KX500 - 14001-5158 | FITS 83-84 KX250 11011-1115 | 1984 | KX500 | FITS 83-84 KX500 - 14073-1079 | FITS 84-85 KXT, 83-85 KX250, 83-84 KX500 - 54011-1112 | FITS 85 KX250, 83-85 KX500 - 54012-1211 | MIKUNI 38MM - FITS 83-84 KX500 | 1984 | KX500 | FITS 83-84 KX500 | FITS 83-85 KX500 – 21119-1133 | 1984 | KX500 | FITS 82-83 KX125, 83-85 KX250 & KX500, 83 KDX200 & KDX250 | 1984 | KX500 | FITS 83-85 KX250, 83-84 KX500, 84-85 KXT250 13102-1077 | FITS 83-84 KX500 - 13095-1103 | FITS 83-84 KX500 - 14032-1079 | FITS 80-84 KX250 KDX250, 83-84 KX500 - 13087-044 | FITS 83-84 KDX250, 83-86 KX250 KX500, 84-87 KXT - 13187-1011 | 1984 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | FITS 82-87 KX125, 83-87 KX250 KX500 KDX200, 84-87 KXT250 - 14026-1119 | FITS 83-84 KX500 - 86MM STD STROKE - 13031-1074 | N/A | FITS 83-84 KX500 - 11005-1188 | 1984 | KX500 | N/A | FITS 83-84 KX500 | N/A | 1984 | KX500 | N/A | N/A | N/A | NO VALVE | 1984 | KX500 | F3T205 FITS 83-85 KX500 - 21007-1052 | FITS 83-84 KX250 & KX500 - 34028-1050 - 34028-1051 | 1984 | KX500 | 83-87 KX250 KX500, 84-87 KX125, 84-94 KDX200 | CHROME OD 43MM - C/L 36 5/8" - C/L OF CALIPER MOUNTS 62MM - AXLE CLAMP 20MM | 43MM X 55MM X 9.5/10.5/11 | 1984 | KX500 | CONVENTIONAL | FITS 83-84 KX250, KX500, 84 KX125 | FITS 83-84 KX250, KX500 | 1984 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1984 | KX500 | FITS 82-83 KX125, 82-84 KX250, 83-84 KX500 | FITS 82-86 KX125, 83-86 KX250 KX500, 86-87 KDX200 | 1984 | KX500 | FITS 82-86 KX125, 83-86 KX250 KX250 - PART OF CALIPER ASY 43041-1084 | FITS 82-86 KX125 KX250, 83-86 KX500, 84-87 KX80, 86-88 KDX200, 46092-1108 | 1984 | KX500 | FITS 82-86 KX125 & KX250, 83-86 KX500, 84-87 KX80, 86-88 KDX200 - 43015-1281 | OD 250MM - ID 129.5MM - BC 8 ON 146MM - FITS 82-84 KX125 & KX250, 83-84 KX500 | 1984 | KX500 | PAT 585875 - 17MM AXLE DIA - BRG TO BRG 102MM - ROTOR 8 ON A 145MM BC - FITS 82-83 KX125, 82-84 KX250, 83-84 KX500 - 36 SPOKES | 1984 | KX500 | GREEN - FITS 83-84 KX500 51001-5384-6W | 1984 | KX500 | FITS 83-84 KX500 | 27T - FITS 83-85 KX500 - 59051-1107 | FITS 75 KX400, 79-82 KDX450, 80-81 KX250 KX420, 83-84 KX500 - 13064-5003 | 1984 | KX500 | FITS 83-84 KX500 | 800 ML = .846 QUARTS | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | DOME TOP 1 RING - BOOK SAYS 83-84 , KAWI MAN SAYS 83-04 WILL WORK – 13001-1199 | N/A | 1984 | KX500 | 25T - FITS 83-84 KX500 - 13097-1060 | AIR COOLED | AIR COOLED | AIR COOLED | AIR COOLED | 1984 | KX500 | 41035-1107 FOR 130MM DRUM – IT SHOULD FIT 82-83 KX125, 82-84 KX250, 83-84 KX500 | 1984 | DRUM BRAKE | DRUM BRAKE | 1984 | KX500 | DRUM BRAKE | FITS 83-84 KX250 KX500 43001-1159 | DRUM BRAKE | 1984 | KX500 | GREEN - FITS 82-83 KX125, 82-84 KX250, 83-84 KX500 - 35022-1204-AE | PAT 585873 - 17MM AXLE DIA - BRG TO BRG 131-132MM - DRUM 130MM ID - SPROCKET 6 ON A 150MM BC - FITS 82-83 KX125, 82-84 KX250, 83-84 KX500 - 41034-5005 | 1984 | KX500 | 1984 | KX500 | FITS 83-84 KX500 | FITS 83-85 KX500 | FITS 83-86 KX250, KX500 - 13242-1166 | FITS 83-86 KX500 | 1984 | KX500 | FITS 83-84 KX250 KX500 -39007-1052 | 1984 | KX500 | GREEN - FITS 82-83 KX125, 82-84 KX250, 83-84 KX500 - 36001-1146-6W | GREEN - FITS 82-83 KX125, 82-84 KX250, 83-84 KX500 - 36001-1147-6W | 1984 | KX500 | FITS 83-85 KX500 - 21003-1109 - 336-504 OHMS BLACK/RED TO BLACK YELLOW - 14.2-21.4 OHMS RED TO BLACK/YELLOW - 10.4-15.6 OHMS WHITE/RED TO BLACK/YELLOW | 1984 | KX500 | BLACK FITS 83-04 KX500 - 14031-1091 | PART OF MAIN FRAME | FITS 83-84 KX250 KX500 - 33001-1205 | FITS 82-86 KX125, 82-84 KX250, 83-84 KX500, 81-84 KDX250, 83-85 KDX200, 84-85 KXT250 - 33032-1042 | 1984 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | FITS 83-84 KX500 - 13127-1126 | 22T - FITS 83-85 KX500 - 13129-1407 | 1984 | KX500 | 22T - FITS 83-85 KX500 - 13129-1408 | 22T - FITS 83-85 KX500 - 13129-1409 | 24T - FITS 83-85 KX500, 84-86 KL600, 87-96 KLR650 - 13129-1410 | FITS 83-85 KX500 - 13128-1042 | FITS 83-87 KX500, 80-81 KX420, 74-79 KX250, 79-80 KDX400, 81-82 KDX420 - 42045-008 - M24X1.0 | 1984 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 32T - FITS 80-81 KX420, 83-85 KX500 - 13129-1622 | 1984 | KX500 | FITS 80-81 KX420, 83-85 KX500 - 13129-1679 | FITS 80-81 KX420, 83-85 KX500, 79-80 KDX400 - 13129-1132 | FITS 80-81 KX420, 83-87 KX500, 79-80 KDX400, 81 KDX420, 82 KDX450 - 13129-1133 | N/A | 1984 | KX500 | 1984 | KX500 | |||||||||||||||||||||||||||||||||||||||
| 1985 | KX500 | JKAKXVA17EA00XXXX | KX500BE000001-001800 | FITS 83-85 KX500 - 14001-5158 | FITS 84-85 KX125, 85-86 KX250 KX500, 86-88 KDX200 - 13091-1267 | FITS 85 KX250 KX500 11011-1180 | 1985 | KX500 | FITS 85-86 KX500 - 14073-1194 | FITS 85 KX250, 83-85 KX500 - 54012-1211 | MIKUNI 39MM FITS 85 KX500 | 1985 | KX500 | FITS 85-86 KX250 KX500 - 16030-1060 | FITS 85 KX500 | FITS 83-85 KX500 – 21119-1133 | 1985 | KX500 | FITS 82-83 KX125, 83-85 KX250 & KX500, 83 KDX200 & KDX250 | 1985 | KX500 | FITS 85 KX500 | FITS 85 KX500 - 13095-1122 | FITS 85 KX500 | FITS 85 KX250 KX500 - 13087-1061 | FITS 83-84 KDX250, 83-86 KX250 KX500, 84-87 KXT - 13187-1011 | 1985 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | FITS 82-87 KX125, 83-87 KX250 KX500 KDX200, 84-87 KXT250 - 14026-1119 | FITS 85-86 KX500 - 86MM STD STROKE - 13031-1182 | FITS 85-04 KX500 - 8148 | FITS 85 KX500 | 1985 | KX500 | FITS 83-85 KX250, 85-87 KX500, 84-85 KXT250 - 52014-1004 | FITS 85 KX500 | N/A | 1985 | KX500 | FITS 85 KX500 | N/A | N/A | NO VALVE | 1985 | KX500 | F3T205 FITS 83-85 KX500 - 21007-1052 | FITS 85 KX125 KX250 KX500 | 1985 | KX500 | 83-87 KX250 KX500, 84-87 KX125, 84-94 KDX200 | CHROME OD 43MM - C/L 36 5/8" - C/L OF CALIPER MOUNTS 62MM - AXLE CLAMP 20MM | 43MM X 55MM X 9.5/10.5/11 | 1985 | KX500 | CONVENTIONAL | FITS 85 KX125, KX250, KX500 | FITS 85 KX250, KX500 | 1985 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1985 | KX500 | FITS 85-88 KX125 KX250 KX500 - 41068-1241 | FITS 82-86 KX125, 83-86 KX250 KX500, 86-87 KDX200 | 1985 | KX500 | FITS 82-86 KX125, 83-86 KX250 KX250 - PART OF CALIPER ASY 43041-1084 | FITS 82-86 KX125 KX250, 83-86 KX500, 84-87 KX80, 86-88 KDX200, 46092-1108 | 1985 | KX500 | FITS 82-86 KX125 & KX250, 83-86 KX500, 84-87 KX80, 86-88 KDX200 - 43015-1281 | OD: 250MM OD - ID 5 3/32" - 8 HOLES ON A 5 3/4" BOLT CIRCLE FITS 85-88 KX125, 250, 500, KDX200 86-92 | 1985 | KX500 | F-1123 - BLACK - 17MM AXLE DIA - BRG TO BRG 102MM - ROTOR OD 250MM - 8 ON A 146MM BC - FITS 85-87 KX125 KX250 KX500 - 41034-1115 | 1985 | KX500 | GREEN - FITS 85-86 KX500 51001-1193-6W | 1985 | KX500 | FITS 85-04 KX500 - 59051-1129 | FITS 85 KX500 - 11001-1189 | 27T - FITS 83-85 KX500 - 59051-1107 | FITS 85-86 KX500 – 13064-1118 - KAWI MAN SAYS 86-04 WILL ALL WORK | 1985 | KX500 | FITS 85-04 KX500 - 13066-1056 | 800 ML = .846 QUARTS | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | DOME TOP 1 RING - BOOK SAYS 83-84 , KAWI MAN SAYS 83-04 WILL WORK – 13001-1199 | N/A | 1985 | KX500 | 26T - FITS 85 KX500 - 13097-1133 | FITS 85-86 KX500 | BLACK 14037-1077-6C FITS 85-86 KX500, 83-86 KX250, 86-87 KXT250 | GREEN – FITS 85 KX250 KX500 - 49089-5004-6W | GREEN - FITS 85 KX250 KX500 - 49089-5005-6W | 1985 | KX500 | FITS 85-87 KX125 KX250 KX500 - 41068-1180 | HYDRAULIC BRAKE | 1985 | DRUM BRAKE | DRUM BRAKE | 1985 | KX500 | DRUM BRAKE | FITS 84-85 KX125, 85 KX250 KX500 43001-1173 | DRUM BRAKE | 1985 | KX500 | GREEN – FITS 84-85 KX125, 85 KX250 KX500 - 35022-1203-6W | BLACK - 20MM AXLE DIA - BRG TO BRG 131-132MM - DRUM - FITS 85 KX250 & KX500 | 1985 | KX500 | FITS 85 KX125, KX250, KX500 | 1985 | KX500 | FITS 85 KX125, 250 & 500 | FITS 83-85 KX500 | FITS 83-86 KX250, KX500 - 13242-1166 | FITS 83-86 KX500 | 1985 | KX500 | FITS 85 KX250 KX500 - 39007-5006 | 1985 | KX500 | GREEN - FITS 84-85 KX125, 85 KX250 KX500 - 36001-1279-AE | GREEN - FITS 84-85 KX125, 85 KX250 KX500 - 36001-1280-AE | 1985 | KX500 | FITS 83-85 KX500 - 21003-1109 - 336-504 OHMS BLACK/RED TO BLACK YELLOW - 14.2-21.4 OHMS RED TO BLACK/YELLOW - 10.4-15.6 OHMS WHITE/RED TO BLACK/YELLOW | 1985 | KX500 | BLACK FITS 83-04 KX500 - 14031-1091 | PART OF MAIN FRAME | FITS 85 KX125, 85-86 KX250 KX500 | 1985 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | 22T - FITS 83-85 KX500 - 13129-1407 | 1985 | KX500 | 22T - FITS 83-85 KX500 - 13129-1408 | 22T - FITS 83-85 KX500 - 13129-1409 | 24T - FITS 83-85 KX500, 84-86 KL600, 87-96 KLR650 - 13129-1410 | FITS 83-85 KX500 - 13128-1042 | FITS 83-87 KX500, 80-81 KX420, 74-79 KX250, 79-80 KDX400, 81-82 KDX420 - 42045-008 - M24X1.0 | 1985 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 32T - FITS 80-81 KX420, 83-85 KX500 - 13129-1622 | 1985 | KX500 | FITS 80-81 KX420, 83-85 KX500 - 13129-1679 | FITS 80-81 KX420, 83-85 KX500, 79-80 KDX400 - 13129-1132 | FITS 80-81 KX420, 83-87 KX500, 79-80 KDX400, 81 KDX420, 82 KDX450 - 13129-1133 | FITS 85-86 KX500 - 16142-1060 | 1985 | KX500 | 1985 | KX500 | |||||||||||||||||||||||||||||||||||||
| 1986 | KX500 | JKAKXVB18GA00XXXX | KX500BE001801-004100 | FITS 86 KX500 - 14001-5207 | FITS 84-85 KX125, 85-86 KX250 KX500, 86-88 KDX200 - 13091-1267 | FITS 86 KX250 KX500 11011-1220 | 1986 | KX500 | FITS 85-86 KX500 - 14073-1194 | FITS 86 KX250 KX500 - 54011-1233 | FITS 86 KX250 KX500 - 54012-1309 | MIKUNI E5 92 FITS 86 KX500 | 1986 | KX500 | FITS 85-86 KX250 KX500 - 16030-1060 | FITS 86 KX500 - 16065-1137 | FITS 86 KX500 – 21119-1191 - 15 deg BTDC @ 6000 RPM | 1986 | KX500 | FITS 86-87 KX125 & KX250 & KX500 | 1986 | KX500 | FITS 86 KX500, KX250, 86-87 TECATE | 17T & 66T - FITS 86 KX500 - 13095-1137 | KX500B 1 FITS 86-87 KX500 | FITS 86 KX500 - 13087-1074 - 5 bolt post | FITS 83-84 KDX250, 83-86 KX250 KX500, 84-87 KXT - 13187-1011 | 1986 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | FITS 82-87 KX125, 83-87 KX250 KX500 KDX200, 84-87 KXT250 - 14026-1119 | FITS 85-86 KX500 - 86MM STD STROKE - 13031-1182 | FITS 85-04 KX500 - 8148 | .499L FITS 86 KX500 | 1986 | KX500 | FITS 83-85 KX250, 85-87 KX500, 84-85 KXT250 - 52014-1004 | FITS 86 KX500 | N/A | 1986 | KX500 | FITS 86 KX500 | N/A | N/A | FITS 86 KX500 2 VALVE- 12005-1066 DRUMS - STEEL OR ALLOY YOU NEVER KNOW… | 1986 | KX500 | F3T81171 5801 FITS 86-88 and sometimes 89 - 21007-1140 - 1.35lb or 21.6 oz - 3.475" OD | FITS 86-87 KDX200 KX125 KX250 KX500 - 34028-1173 - 34028-1174 | 1986 | KX500 | 83-87 KX250 KX500, 84-87 KX125, 84-94 KDX200 | CHROME OD 43MM - C/L 36 5/8" - C/L OF CALIPER MOUNTS 62MM - AXLE CLAMP 20MM | 43MM X 55MM X 9.5/10.5/11 | 1986 | KX500 | CONVENTIONAL | FITS 86 KX125, KX250, KX500 | FITS 86 KX125 KX250 KX500 44039-1142 | 1986 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1986 | KX500 | FITS 85-88 KX125 KX250 KX500 - 41068-1241 | FITS 82-86 KX125, 83-86 KX250 KX500, 86-87 KDX200 | 1986 | KX500 | FITS 82-86 KX125, 83-86 KX250 KX250 - PART OF CALIPER ASY 43041-1084 | FITS 82-86 KX125 KX250, 83-86 KX500, 84-87 KX80, 86-88 KDX200, 46092-1108 | 1986 | KX500 | FITS 82-86 KX125 & KX250, 83-86 KX500, 84-87 KX80, 86-88 KDX200 - 43015-1281 | OD: 250MM OD - ID 5 3/32" - 8 HOLES ON A 5 3/4" BOLT CIRCLE FITS 85-88 KX125, 250, 500, KDX200 86-92 | 1986 | KX500 | F-1123 - BLACK - 17MM AXLE DIA - BRG TO BRG 102MM - ROTOR OD 250MM - 8 ON A 146MM BC - FITS 85-87 KX125 KX250 KX500 - 41034-1115 | 1986 | KX500 | GREEN - FITS 85-86 KX500 51001-1193-6W | 1986 | KX500 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 86 KX500 - 11001-1214 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 85-86 KX500 – 13064-1118 - KAWI MAN SAYS 86-04 WILL ALL WORK | 1986 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125 KX250 KX500 - 58029-5018-6W GREEN | 800 ML = .846 QUARTS | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | DOME TOP 1 RING - BOOK SAYS 86 , KAWI MAN SAYS 85-04 WILL WORK – 13001-1226 | N/A | 1986 | KX500 | 26T - FITS 86-87 KX500 - 13097-1154 | FITS 85-86 KX500 | BLACK 14037-1077-6C FITS 85-86 KX500, 83-86 KX250, 86-87 KXT250 | GREEN - FITS 86 KX250 KX500 - 49089-5009-6W | GREEN - FITS 86 KX250 KX500 - 49089-5010-6W | 1986 | KX500 | FITS 85-87 KX125 KX250 KX500 - 41068-1180 | HYDRAULIC BRAKE | 1986 | FITS 86 KX125, KX250, KX500 | FITS 86-87 KX125 KX250 KX500 - 43059-1364 | 1986 | KX500 | FITS 86 KX250 & KX500 | FITS 86 KX250 KX500 43001-1195 | FITS 86 KX125 & KX250 & KX500 | 1986 | KX500 | GREEN – FITS 86-87 KX125 KX250 KX500 - 35022-1217-6W | R-1158 – BLACK - 20MM – BRG TO BRG 144-145MM – ROTOR OD 220MM – ROTOR BC 8 ON 126MM – SPROCKET 6 ON 150MM BC – 36 SPOKES – FITS 86-87 KX125 KX250 KX500 - 41034-1139 | 1986 | KX500 | LEFT FITS 86-88 KX125 KX250 KX125 - 92027-1942 | 1986 | KX500 | FITS 85 KX250, 86 KX500, 86-87 KXT250 - 12021-1058 | FITS 86 KX125, KX250 & KX500 - 53001-1436 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 83-86 KX250, KX500 - 13242-1166 | FITS 83-86 KX500 | 1986 | KX500 | Spring thickness: 12MM OD - Spring Diameter: 88MM - Spring length as mounted: 267MM - Upper mount tab thickness: 32MM - Upper mount tab hole ID: 12MM - Lower Mount Internal Width: 26.5MM - Lower mount hole ID: 10MM - Eye to Eye: 420MM | FITS 86 KX250 KX500 - 39007-1081 | 1986 | KX500 | GREEN – FITS 86 KX500 – 36002-5185-AC | GREEN – FITS 86 KX500 – 36002-5186-AC | 1986 | KX500 | (2 coil style) FITS 86 KX500 - 21003-1141 - 432-648 OHMS BLACK/RED TO BLACK/YELLOW - 4.0-6.0 OHMS WHITE/GREEN TO WHITE/RED | 1986 | KX500 | BLACK FITS 83-04 KX500 - 14031-1091 | PART OF MAIN FRAME | FITS 86 KX250 & KX500 - 33001-1246 | FITS 85 KX125, 85-86 KX250 KX500 | 1986 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 86 KX500 - GEARS FIT 86-87 KX500 | FITS 86 KX500 - 13127-1131 | FITS 86-87 KX500 - 13129-1741 | 1986 | KX500 | FITS 86-87 KX500 - 13129-1742 | FITS 86-88 KX500 - 13129-1743 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 86 KX500 - 13128-1128 | FITS 83-87 KX500, 80-81 KX420, 74-79 KX250, 79-80 KDX400, 81-82 KDX420 - 42045-008 - M24X1.0 | 1986 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | FITS 86-87 KX500 - 13129-1746 | 1986 | KX500 | FITS 86-87 KX500 - 13129-1747 | FITS 86-88 KX500 - 13129-1748 | FITS 80-81 KX420, 83-87 KX500, 79-80 KDX400, 81 KDX420, 82 KDX450 - 13129-1133 | FITS 85-86 KX500 - 16142-1060 | 1986 | KX500 | 1986 | KX500 | |||||||||||||||||||||||||||||
| 1987 | KX500 | JKAKXVC19HA00XXXX | KX500BE004101-006600 | FITS 87 KX500 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 87 KX125 KX250 KX500 11011-1241 | 1987 | KX500 | 1286 - FITS 87 KX500 - 14073-1286 | FITS 87 KX250 KX500 - 54011-1252 | FITS 87 KX250 KX500 - 54012-1324 | MIKUNI FITS 87 KX500 - 40MM | 1987 | KX500 | FITS 87 KX500 | 17 deg BTDC @ 6000 RPM | 1987 | KX500 | FITS 86-87 KX125 & KX250 & KX500 | 1987 | KX500 | FITS 87 KX125 KX250 KX500, 87-88 KDX200, 87-88 KXF250 | FITS 87 KX250 & KX500 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 87-91 KX250 KX500, 91-94 KDX250 - 13088-1069 | FITS 86-87 KX500 | FITS 87 KX250 KX500 - 13087-1085 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 1987 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | FITS 82-87 KX125, 83-87 KX250 KX500 KDX200, 84-87 KXT250 - 14026-1119 | FITS 1987 - 86MM STD STROKE - 13031-1231 | FITS 85-04 KX500 - 8148 | FITS 87 KX500 | 1987 | KX500 | FITS 83-85 KX250, 85-87 KX500, 84-85 KXT250 - 52014-1004 | FITS 87 KX500 | N/A | 1987 | KX500 | FITS 87 KX500 | N/A | N/A | FITS 87-88 KX500 2 VALVE - 12005-1080 DRUMS - STEEL OR ALLOY YOU NEVER KNOW… | 1987 | KX500 | F3T81171 5801 FITS 86-88 and sometimes 89 - 21007-1140 - 1.35lb or 21.6 oz - 3.475" OD | FITS 86-87 KDX200 KX125 KX250 KX500 - 34028-1173 - 34028-1174 | 1987 | KX500 | 83-87 KX250 KX500, 84-87 KX125, 84-94 KDX200 | CONVENTIONAL - CHROME OD 43MM - C/L 36 5/8" - C/L OF CALIPER MOUNTS 89MM - AXLE CLAMP 20MM | 43MM X 55MM X 9.5/10.5/11 | 1987 | KX500 | CONVENTIONAL | FITS 87 KX250, KX500 | FITS 87 KX250 KX500 44039-1147 | 1987 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1987 | KX500 | FITS 85-88 KX125 KX250 KX500 - 41068-1241 | FITS 87 KX125 KX250 KX500 | 1987 | KX500 | CALIPER HOLDER FITS 87-88 KX500, 88 KX125 KX250 - 43044-1069 | FITS 87 KX125 KX250 KX500 - 43059-1385 | FITS 87 KX125 KX250 KX500 46092-1141 | 1987 | KX500 | FITS 87 KX125 KX250 KX500 | OD: 250MM OD - ID 5 3/32" - 8 HOLES ON A 5 3/4" BOLT CIRCLE FITS 85-88 KX125, 250, 500, KDX200 86-92 | 1987 | KX500 | F-1123 - BLACK - 17MM AXLE DIA - BRG TO BRG 102MM - ROTOR OD 250MM - 8 ON A 146MM BC - FITS 85-87 KX125 KX250 KX500 - 41034-1115 | 1987 | KX500 | GREEN – FITS 87 KX500 51001-1254-6W | FITS 87-95 KX125 KX250 KX500, 88-95 KX80, 89-95 KDX200, 91-94 KDX250, 93-95 KLX650, 94 KLX250 - 51049-1089 | 1987 | KX500 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 87 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 87 KX500 - 13064-1130 - KAWI MAN SAYS 86-04 WILL ALL WORK | 1987 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 86-89 KX125 KX250 KX500 - 58029-5018-6W GREEN | 800 ML = .846 QUARTS | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | DOME TOP 1 RING - BOOK SAYS 87 , KAWI MAN SAYS 85-04 WILL WORK – 13001-1245 | N/A | 1987 | KX500 | 26T - FITS 86-87 KX500 - 13097-1154 | FITS 87 KX500 | BLACK 14037-1087 FITS 87 KX250, KX500 | GREEN - FITS 87 KX500 – 49089-5020-6W | GREEN - FITS 87 KX500 – 49089-5021-6W | 1987 | KX500 | FITS 85-87 KX125 KX250 KX500 - 41068-1180 | HYDRAULIC BRAKE | 1987 | FITS 87-88 KX125, KX250, KX500 - 43041-1244 | FITS 87-88 KX125 KX250 KX500 - 43044-1068 | FITS 86-87 KX125 KX250 KX500 - 43059-1364 | 1987 | KX500 | OD: 8 11/16" - ID: 4 5/16" - 8 BOLT HOLES ON A 4 15/16" BOLT CIRCLE - 86-88 KX125, 87-88 KX250 & KX500 | FITS 87 KX250 KX500 43001-1217 | FITS 87 KX125 & KX250 & KX500 | 1987 | KX500 | GREEN – FITS 86-87 KX125 KX250 KX500 - 35022-1217-6W | R-1158 – BLACK - 20MM – BRG TO BRG 144-145MM – ROTOR OD 220MM – ROTOR BC 8 ON 126MM – SPROCKET 6 ON 150MM BC – 36 SPOKES – FITS 86-87 KX125 KX250 KX500 - 41034-1139 | 1987 | KX500 | 1987 | KX500 | FITS 87 KX125 KX250 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 87 KX250 & KX500 | FITS 87-93 KX500 - 13161-1144 | 1987 | KX500 | FITS 87 KX125 KX250 KX500 - 39007-1115 | FITS 87 KX250 KX500 - 46102-1200 | 1987 | KX500 | GREEN - FITS 87 KX125 KX250 KX125 – 36002-5310-6W | GREEN - FITS 87 KX125 KX250 KX125 – 36001-1345-AC | 1987 | KX500 | (2 coil style) FITS 87-89 KX500 - 21003-1169 - 432-648 OHMS: BLACK/WHITE TO BLACK/YELLOW - 4.0-6.0 OHMS: WHITE/RED TO BLACK/YELLOW | 1987 | KX500 | BLACK FITS 83-04 KX500 - 14031-1091 | FITS 87 KX125 KX250 KX500 - 32002-1911 | FITS 87 KX250 KX500 - 33001-1276 | 1987 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 87 KX500 - GEARS FIT 86-87 KX500 | FITS 87 KX500 - 13127-1143 | FITS 86-87 KX500 - 13129-1741 | 1987 | KX500 | FITS 86-87 KX500 - 13129-1742 | FITS 86-88 KX500 - 13129-1743 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 87 KX500 - 13128-1142 | FITS 83-87 KX500, 80-81 KX420, 74-79 KX250, 79-80 KDX400, 81-82 KDX420 - 42045-008 - M24X1.0 | 1987 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | FITS 86-87 KX500 - 13129-1746 | 1987 | KX500 | FITS 86-87 KX500 - 13129-1747 | FITS 86-88 KX500 - 13129-1748 | FITS 80-81 KX420, 83-87 KX500, 79-80 KDX400, 81 KDX420, 82 KDX450 - 13129-1133 | FITS 87 KX500 - 16142-1072 | 1987 | KX500 | 1987 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | 59.25LB NO OIL, SPARK PLUG, CARBURETOR | |||||||||||||||||||||||
| 1988 | KX500 | JKAKXVD17JA00XXXX | KX500BE006601-008500 | FITS 88 KX500 - 14001-5245 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 88 KX500 - 11011-1288 | 1988 | KX500 | 1329 - FITS 88 KX500 - 14073-1329 | FITS 88-89 KX250 KX500 - 54011-1264 | FITS 88-91 KX250, 88-04 KX500, 88 KDX200 - 54012-1341 | KEIHIN PWK V396 FITS 88 KX500 - 39MM | 1988 | KX500 | FITS 88 KX500 | FITS 88 KX500 – 17 deg BTDC @ 6000 RPM | 1988 | KX500 | FITS 88-89 KX125 KX250 KX500 - 33040-1085 | FITS 88-89 KX125 KX250 KX500 | 1988 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500, 89-93 KDX200, 91-94 KDX250 12053-1240 | FITS 88 KX250 & KX500 - 13102-1094 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 87-91 KX250 KX500, 91-94 KDX250 - 13088-1069 | FITS 88-04 KX500 - 14032-1245 | FITS 88-91 KX250, 88 KX500 - 13087-1098 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 1988 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | FITS 1988 – 86MM STD STROKE - 13031-1260 | FITS 85-04 KX500 - 8148 | FITS 88 KX500 – 86MM STD BORE | 1988 | KX500 | FITS 88-96 KX500, 93-95 KLX650, 94-96 KLX250 - 52014-1065 | FITS 88 KX500 - 18002-1799 | 20055 FITS 88-04 KX500 | 1988 | KX500 | FITS 88 KX500 | N/A | N/A | FITS 87-88 KX500 2 VALVE - 12005-1080 DRUMS - STEEL OR ALLOY YOU NEVER KNOW… | FITS 88-04 KX500 - 14024-1611 | 1988 | KX500 | F3T81171 5801 FITS 86-88 and sometimes 89 - 21007-1140 - 1.35lb or 21.6 oz - 3.475" OD | FITS 88-89 KX125 KX250 KX500 - 34028-1233 - 34028-1234 | 1988 | KX500 | FITS 88-04 KX500, 88-96 KX125 KX250, 91 93-94 KDX250, 95-05 KDX200, 97-05 KDX220 | KYB - CONVENTIONAL - CHROME OD 43MM - C/L 37" - C/L OF CALIPER MOUNTS 89MM - AXLE CLAMP 20MM | 43MM X 55MM X 9.5/10.5/11 | 1988 | KX500 | CONVENTIONAL | FITS 88 KX250, KX500 | FITS 88 KX250 KX500 44039-1176 | 1988 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1988 | KX500 | FITS 85-88 KX125 KX250 KX500 - 41068-1241 | FITS 88 KX125 KX250 KX500 | 1988 | KX500 | CALIPER HOLDER FITS 87-88 KX500, 88 KX125 KX250 - 43044-1069 | FITS 88-92 KX125 KX250, 88-93 KX500 KX80, 89-94 KDX200, 91-94 KD250 | 1988 | KX500 | FITS 88 KX125 KX250 KX500 - 43015-1367 | OD: 250MM OD - ID 5 3/32" - 8 HOLES ON A 5 3/4" BOLT CIRCLE FITS 85-88 KX125, 250, 500, KDX200 86-92 | 1988 | KX500 | GREEN - FITS 88 KX250 KX500, 86-88 KDX200 - 35004-1176-6W | F-1123 - GRAY - 17MM AXLE DIA - BRG TO BRG 102MM - FITS 88 KX 125, 250, 500 - 41034-1170 | 1988 | KX500 | GREEN – FITS 88-91 KX500 51001-1281-6W (SHOULD FIT 88-04 KX500) | FITS 87-95 KX125 KX250 KX500, 88-95 KX80, 89-95 KDX200, 91-94 KDX250, 93-95 KLX650, 94 KLX250 - 51049-1089 | 1988 | KX500 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 88 KX500 - 11001-1269 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 88-91 KX500 - 13064-1134 - KAWI MAN SAYS 86-04 WILL ALL WORK | 1988 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 86-89 KX125 KX250 KX500 - 58029-5018-6W GREEN | 800 ML = .846 QUARTS | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | DOME TOP 1 RINGS - BOOK SAYS 88 , KAWI MAN SAYS 85-04 WILL WORK – 13001-1267 | 575M08600 FITS 88-04 KX500 86MM STD BORE | 1988 | KX500 | 26T - FITS 88-04 KX500 - 13097-1205 | BOOK SAYS THEY FIT 88-96 KX500 - 39061-1112 39061-1113 BUT KAWI MAN SAYS THEY FIT 88-04 KX500 | GREEN 14037-1099-6W FITS 88-95 KX500, 88-93 KX250, 90-93 KX125, 89-95 KDX200, 91-94 KDX250, 94-95 KLX250 | GREEN – FITS 88 KX500 - 49089-5035-6W | GREEN – FITS 88 KX500 – 49089-5036-6W | 1988 | KX500 | FITS 88 KX125 KX250 KX500 - 41068-1249 CLICK HERE FOR MEASUREMENTS | HYDRAULIC BRAKE | 1988 | FITS 87-88 KX125, KX250, KX500 - 43041-1244 | FITS 87-88 KX125 KX250 KX500 - 43044-1068 | 1988 | KX500 | OD: 8 11/16" - ID: 4 5/16" - 8 BOLT HOLES ON A 4 15/16" BOLT CIRCLE - 86-88 KX125, 87-88 KX250 & KX500 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43001-1239 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43015-1368 | 1988 | KX500 | GREEN – FITS 88 KX250 KX500 - 35022-1234-6W | R-1158 – GRAY - 20MM – BRG TO BRG 144-145MM – ROTOR OD 220MM – ROTOR BC 8 ON 126MM – SPROCKET 6 ON 150MM BC – 36 SPOKES – FITS 88 KX 125, 250, 500 - 41034-1171 | 1988 | KX500 | 1988 | KX500 | FITS 88-04 KX500, 91-94 KDX250 - 12021-1070 | FITS 88-89 KX125 KX250, 88-90 KX500, 94 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 88-93 KX125, KX250 & KX500 - 13156-1240 | FITS 87-93 KX500 - 13161-1144 | 1988 | KX500 | KYB - SPRING THICKNESS 11.5MM - SPRING OD 88MM, LENGTH 254MM - BODY OD 53.7MM - CHROME OD 16MM - EYE TO EYE 440MM - UPPER MOUNT WIDTH 27MM, HOLE ID 10MM - LOWER MOUNT WIDTH 27MM, HOLE ID 10MM - FITS 88 KX500 - 45014-1387 | FITS 88 KX125 KX250 KX500 - 39007-1145 | 1988 | KX500 | GREEN – FITS 88 KX125 KX250 KX500 - 36002-5451-6W | GREEN - FITS 88 KX250 KX500 – 36001-1376-AC | 1988 | KX500 | (2 coil style) FITS 87-89 KX500 - 21003-1169 - 432-648 OHMS: BLACK/WHITE TO BLACK/YELLOW - 4.0-6.0 OHMS: WHITE/RED TO BLACK/YELLOW | 1988 | KX500 | GRAY FITS 83-04 KX500 - 14031-1220 | FITS 88 KX125 KX250 KX500 - 32002-1965 | FITS 88 KX125 KX250 KX500 - 33001-1306-X3 | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 1988 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 88-04KX500 - GEARS FIT 88-89 KX500 | 16T - FITS 88-04 KX500 - 13127-1159 | 20T - FITS 88-89 KX500 - 13129-1908 | 1988 | KX500 | 22T - FITS 88-89 KX500 - 13129-1909 | FITS 86-88 KX500 - 13129-1743 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 88-04 KX500 - 13128-1150 | 1988 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | FITS 88-89 KX500 - 13129-1955 | 1988 | KX500 | 26T - FITS 88-89 KX500 - 13129-1910 | FITS 86-88 KX500 - 13129-1748 | 19T - FITS 84-86 KL600, 87-96 KLR650, 88-04 KX500 - 13129-1575 | FITS 88-04 KX500 - 16142-1086 | 1988 | KX500 | FITS 88-89 KX250, 88-04 KX500, 88-03 KX60, 89-06 KDX200, FITS 91-94 KDX250 | 1988 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | FITS 88-89 KX250, 88-04 KX500, 89-06 KDX200 - 52014-1067 | |||||||||||||||||||||
| 1989 | KX500 | JKAKXVE10KA00XXXX | KX500BE008501- | FITS 89-04 KX500 - set 14001-5258 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 89 KX500 - 11011-1299 | 1989 | KX500 | 1360 - FITS 89-04 KX500 - 14073-1360 | FITS 88-89 KX250 KX500 - 54011-1264 | FITS 88-91 KX250, 88-04 KX500, 88 KDX200 - 54012-1341 | KEIHIN PWK V461 FITS 89 KX500 - 39MM | 1989 | KX500 | FITS 89-04 KX500 - 16065-1180 | FITS 89-04 KX500 – 21119-1267 - 19 deg BTDC @ 6000 RPM | 1989 | KX500 | FITS 88-89 KX125 KX250 KX500 - 33040-1085 | FITS 88-89 KX125 KX250 KX500 | 1989 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500, 89-93 KDX200, 91-94 KDX250 12053-1240 | BOOK SAYS IT FITS 89 KX250 & KX500 - 13102-1101 - IT WILL FIT 88-04 KX500 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 87-91 KX250 KX500, 91-94 KDX250 - 13088-1069 | FITS 88-04 KX500 - 14032-1245 | FITS 89-04 KX500, 91-94 KDX250 - 13087-1138 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 1989 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | BOOK SAYS 89-91 KX500, KAWAI MAN SAYS 89-04 - 29.95 MM FLY WHEEL SIDE – 30.00 PRIMARY GEAR SIDE – 86MM STD STROKE – 13031-1285 - | FITS 85-04 KX500 - 8148 | FITS 89-04 KX500 – 86MM STD BORE - 11005-1564 | 1989 | KX500 | FITS 88-96 KX500, 93-95 KLX650, 94-96 KLX250 - 52014-1065 | FITS 89-04 KX500 - 32029-1652 | FITS 89-04 KX500 - 32029-1639 | FITS 89-96 KX500 - 18002-1862 | 20055 FITS 88-04 KX500 | 1989 | KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 3 VALVE | FITS 88-92 KX250, 89-04 KX500 - 14024-1588 | FITS 88-04 KX500 - 14024-1611 | 1989 | KX500 | F4T102 71 FITS 89-91 KX500 - 21007-1183 - 2.55lb or 41.6 oz. - 4.370" OD | FITS 88-89 KX125 KX250 KX500 - 34028-1233 - 34028-1234 | 1989 | KX500 | FITS 88-04 KX500, 88-96 KX125 KX250, 91 93-94 KDX250, 95-05 KDX200, 97-05 KDX220 | CONVENTIONAL - KX 89 L / KX 89 R - CHROME OD 46MM - C/L 36.75" - BRAKE MOUNT 78MM - AXLE CLAMP ID'S 22MM | 46MM X 58MM X 10.5 | 1989 | KX500 | CONVENTIONAL | FITS 89 KX125, KX250, KX500 - 190MM C/L TO C/L OF FORK TUBES | FITS 89 KX125 KX250 KX500 44039-1192 | 1989 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1989 | KX500 | FITS 89 KX125 KX250 KX500 | FITS 89-93 KX500, 89-92 KX125 KX250, 93-96 KLX650C KLX650R, 94-96 KLX250R, 97-07 KLX300R, 00-10 KL250 - 44063-1056 | FITS 89 KX125 KX250 KX500 - 43041-1294 | 1989 | KX500 | FITS 89 KX125 KX250 KX500 - 14079-1071 | FITS 88-92 KX125 KX250, 88-93 KX500 KX80, 89-94 KDX200, 91-94 KD250 | 1989 | KX500 | FITS 89-90 KX125 KX250 KX500 KX80 - 43015-1395 | ROTOR OD 250MM - ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 89-91 KX125 KX250, 89-93 KX500, 93-94 KDX200 | 1989 | KX500 | F-1212 - GRAY - 17MM AXLE DIA - BRG TO BRG 92MM - ROTOR BC 4 ON 116MM - FITS 89 KX125 KX250 KX500 | 1989 | KX500 | GREEN – FITS 88-91 KX500 51001-1281-6W (SHOULD FIT 88-04 KX500) | FITS 87-95 KX125 KX250 KX500, 88-95 KX80, 89-95 KDX200, 91-94 KDX250, 93-95 KLX650, 94 KLX250 - 51049-1089 | 1989 | KX500 | SET FITS 89-04 KX500 | FITS 89-91 KX500 - 13168-1401 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 89-04 1288 E-2 OR E-1, GASKET SURFACE TO NUT SURFACE .913" - 11001-1288 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 88-91 KX500 - 13064-1134 - KAWI MAN SAYS 86-04 WILL ALL WORK | 1989 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 86-89 KX125 KX250 KX500 - 58029-5018-6W GREEN | 800 ML = .846 QUARTS | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | FLAT TOP 2 RINGS BOOK SAYS 89 , KAWI MAN SAYS 83-04 WILL WORK – 13001-1298 | 575M08600 FITS 88-04 KX500 86MM STD BORE | 1989 | KX500 | 26T - FITS 88-04 KX500 - 13097-1205 | BOOK SAYS THEY FIT 88-96 KX500 - 39061-1112 39061-1113 BUT KAWI MAN SAYS THEY FIT 88-04 KX500 | GREEN 14037-1099-6W FITS 88-95 KX500, 88-93 KX250, 90-93 KX125, 89-95 KDX200, 91-94 KDX250, 94-95 KLX250 | GREEN – FITS 89 KX500 – 49089-5069-6W | GREEN – FITS 89 KX500 – 49089-5070-6W | 1989 | KX500 | HYDRAULIC BRAKE | 1989 | FITS 89-93 KX125 KX250 KX500, 91-94 KDX250, 95-03 KDX200, 97-03 KDX220 - 43041-1448 | FITS 89 KX125 KX250 KX500 - 43044-1082 | 1989 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43001-1239 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43015-1368 | 1989 | KX500 | GREEN - FITS 89-04 KX500, 88-89 KX125, 89 KX250 - 35022-1241-6W | R-1213 – GRAY – 20MM AXLE - BRG TO BRG 130MM - ROTOR OD 220MM - ROTOR BC 6X ON 116MM – 36 SPOKES – FITS 89 KDX200, KX125, KX250, KX500 - 2 BRG - 41034-1184 | 1989 | KX500 | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 1989 | KX500 | FITS 88-04 KX500, 91-94 KDX250 - 12021-1070 | PAN STAMP 1531 - FITS 88 KX125 KX250 KX500 - 53001-1532 - KX GURU SAYS IT FITS 89-04 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 88-93 KX125, KX250 & KX500 - 13156-1240 | FITS 87-93 KX500 - 13161-1144 | 1989 | KX500 | WILL NOT FIT 90 OR NEWER | FITS 89 KX125 KX250 KX500 - 39007-1170 | FITS 89 KX125 KX250, 89-04 KX500 - 46102-1253 | 1989 | KX500 | GREEN - FITS 89-95 KX500, 89 KX125 KX250, 89-94 KDX200 - 36010-5023-6W | GREEN – FITS 89 KX125 KX250 KX500 - 36010-5135-6W | 1989 | KX500 | (2 coil style) FITS 87-89 KX500 - 21003-1169 - (1 COIL STYLE) FITS 89-91 - 21003-1215 - 432-648 OHMS: BLACK/WHITE TO BLACK/YELLOW - 4.0-6.0 OHMS: WHITE/RED TO BLACK/YELLOW | 1989 | KX500 | GRAY FITS 83-04 KX500 - 14031-1220 | FITS 89-90 KX500, 89 KX125 KX250 - 32160-1031 - KAWI MAN SAYS IT FITS 89-04 KX500 | FITS 89 KX125 KX250 KX500 – 33001-1324-CE | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 1989 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 88-04KX500 - GEARS FIT 88-89 KX500 | 16T - FITS 88-04 KX500 - 13127-1159 | 20T - FITS 88-89 KX500 - 13129-1908 | 1989 | KX500 | 22T - FITS 88-89 KX500 - 13129-1909 | 22T - FITS 89-04 KX500 - 13260-1020 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 88-04 KX500 - 13128-1150 | 1989 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 29T - FITS 88-89 KX500 - 13129-1955 | 1989 | KX500 | 26T - FITS 88-89 KX500 - 13129-1910 | 21T - FITS 89-04 KX500 - 13260-1021 | 19T - FITS 84-86 KL600, 87-96 KLR650, 88-04 KX500 - 13129-1575 | FITS 88-04 KX500 - 16142-1086 | 1989 | KX500 | FITS 88-89 KX250, 88-04 KX500, 88-03 KX60, 89-06 KDX200, FITS 91-94 KDX250 | 1989 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | FITS 88-89 KX250, 88-04 KX500, 89-06 KDX200 - 52014-1067 | 62 LB WITH OIL AND SPARK PLUG, NO CARBURETOR | |||||||||||||||
| 1990 | KX500 | JKAKXVE12LA00XXXX | KX500BE010701- 004000 | FITS 89-04 KX500 - set 14001-5258 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 89 KX125 KX250, 90-04 KX500 11011-1304 | 1990 | KX500 | 1360 - FITS 89-04 KX500 - 14073-1360 | FITS 90 KX250, 90-04 KX500 - 54011-1304 | FITS 88-91 KX250, 88-04 KX500, 88 KDX200 - 54012-1341 | KEIHIN PWK V563 FITS 90-93 KX500 - 39MM | 1990 | KX500 | FITS 89-04 KX500 - 16065-1180 | FITS 89-04 KX500 – 21119-1267 - 19 deg BTDC @ 6000 RPM | 1990 | KX500 | FITS 90-92 KX125 KX250, 90-04 KX500 - 33040-1106 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | 1990 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500, 89-93 KDX200, 91-94 KDX250 12053-1240 | BOOK SAYS IT FITS 90 KX250, 90-04 KX500 13102-1107 - IT WILL FIT 88-04 KX500 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 87-91 KX250 KX500, 91-94 KDX250 - 13088-1069 | FITS 88-04 KX500 - 14032-1245 | FITS 89-04 KX500, 91-94 KDX250 - 13087-1138 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 1990 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | BOOK SAYS 89-91 KX500, KAWAI MAN SAYS 89-04 - 29.95 MM FLY WHEEL SIDE – 30.00 PRIMARY GEAR SIDE – 86MM STD STROKE – 13031-1285 | FITS 85-04 KX500 - 8148 | FITS 89-04 KX500 – 86MM STD BORE - 11005-1564 | 1990 | KX500 | FITS 88-96 KX500, 93-95 KLX650, 94-96 KLX250 - 52014-1065 | FITS 89-04 KX500 - 32029-1652 | FITS 89-04 KX500 - 32029-1639 | FITS 89-96 KX500 - 18002-1862 | 20055 FITS 88-04 KX500 | 1990 | KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 3 VALVE | FITS 88-92 KX250, 89-04 KX500 - 14024-1588 | FITS 88-04 KX500 - 14024-1611 | 1990 | KX500 | F4T102 71 FITS 89-91 KX500 - 21007-1183 - 2.55lb or 41.6 oz. - 4.370" OD | FITS 90 KX125 KX250, 90-91 KX500 - 34028-1318 - 34028-1319 | 1990 | KX500 | FITS 88-04 KX500, 88-96 KX125 KX250, 91 93-94 KDX250, 95-05 KDX200, 97-05 KDX220 | USD - CHROME OD 41MM C/L 37.25" - BRAKE MOUNT C/L 61MM – AXLE CLAMP ID 22MM | 41MM X 53MM X 8/9.5/10.5 | 1990 | KX500 | FITS 90-93 KX125 KX250 KX500 - 55020-1384 | FITS 90-93 KX125 KX250 KX500 - 13070-1204 | FITS 90 KX125, KX250, KX500 - 190MM C/L TO C/L OF FORK TUBES | FITS 90 KX250 KX500 44039-1190 | 1990 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1990 | KX500 | FITS 90-92 KX125 KX250, 90-93 KX500 41068-1310 | FITS 89-93 KX500, 89-92 KX125 KX250, 93-96 KLX650C KLX650R, 94-96 KLX250R, 97-07 KLX300R, 00-10 KL250 - 44063-1056 | FITS 90 KX125 KX250 KX500 - 43041-1285 | 1990 | KX500 | FITS 90-91 KX125 KX250 KX500, 91 KDX250 - 14079-1072 | FITS 90-93 KX125 KX250 KX500 - 43059-1577 | FITS 88-92 KX125 KX250, 88-93 KX500 KX80, 89-94 KDX200, 91-94 KD250 | 1990 | KX500 | FITS 89-90 KX125 KX250 KX500 KX80 - 43015-1395 | ROTOR OD 250MM - ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 89-91 KX125 KX250, 89-93 KX500, 93-94 KDX200 | 1990 | KX500 | FITS 90-93 KX125 KX250 KX500 - 14024-1859-6F | F-1212 - GRAY - 17MM AXLE DIA - BRG TO BRG 92MM - FITS 90-92 KX125 AND 250 - 1990-1993 KX500 - 41034-1204 | 1990 | KX500 | GREEN – FITS 88-91 KX500 51001-1281-6W (SHOULD FIT 88-04 KX500) | FITS 87-95 KX125 KX250 KX500, 88-95 KX80, 89-95 KDX200, 91-94 KDX250, 93-95 KLX650, 94 KLX250 - 51049-1089 | 1990 | KX500 | SET FITS 89-04 KX500 | FITS 89-91 KX500 - 13168-1401 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 89-04 1288 E-2 OR E-1, GASKET SURFACE TO NUT SURFACE .913" - 11001-1288 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 88-91 KX500 - 13064-1134 - KAWI MAN SAYS 86-04 WILL ALL WORK | 1990 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 90 KX125 KX250 KX500 58029-5027-6W GREEN | 800 ML = .846 QUARTS | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | FLAT TOP 2 RINGS BOOK SAYS 90-04 KAWI MAN SAYS 83-04 WILL WORK 13001-1327 | 575M08600 FITS 88-04 KX500 86MM STD BORE | 1990 | KX500 | 26T - FITS 88-04 KX500 - 13097-1205 | BOOK SAYS THEY FIT 88-96 KX500 - 39061-1112 39061-1113 BUT KAWI MAN SAYS THEY FIT 88-04 KX500 | GREEN 14037-1099-6W FITS 88-95 KX500, 88-93 KX250, 90-93 KX125, 89-95 KDX200, 91-94 KDX250, 94-95 KLX250 | GREEN – FITS 90 KX500 – 49089-5087-6W | GREEN – FITS 90 KX500 – 49089-5088-6W | 1990 | KX500 | FITS 90-04 KX500, 90-92 KX125 KX250 - 41068-1299 | HYDRAULIC BRAKE | 1990 | FITS 89-93 KX125 KX250 KX500, 91-94 KDX250, 95-03 KDX200, 97-03 KDX220 - 43041-1448 | WHITE - FITS 90-93 KX125 KX250 KX500, 90-94 KDX200, 93-96 KLX650R KLX650C, 94-96 KLX250R - 55020-1323-6F | FITS 90-93 KX125 KX250, 90-91 KX500 - 43044-1092 | 1990 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43001-1239 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43015-1368 | 1990 | KX500 | GREEN - FITS 89-04 KX500, 88-89 KX125, 89 KX250 - 35022-1241-6W | R-1213 OR 1237 - GRAY - 20MM AXLE - BRG TO BRG 130MM - ROTOR OD 220MM – ROTOR BC 6X ON 116MM – 36 SPOKES - FITS 90-94 KDX200, 90-96 KX125 KX250 KX500 - 2 BRG - 41034-1205 | 1990 | KX500 | FITS 90-96 KX125 KX250 KX500 - 92143-1356 - ID 20.26MM, MAJ OD 36.06MM, MINOR OD 25MM, LENGTH 19.63MM | 1990 | KX500 | FITS 88-04 KX500, 91-94 KDX250 - 12021-1070 | PAN STAMP 1531 - FITS 89 KX125 KX250 KX500 - 53001-1577-MD - KX GURU SAYS IT FITS 89-04 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 88-93 KX125, KX250 & KX500 - 13156-1240 | FITS 87-93 KX500 - 13161-1144 | 1990 | KX500 | KYB - Spring thickness: 12.0MM OD - Spring Dia: 89MM - BODY DIA 53.5MM - Spring as mounted: 265MM - Upper tab: 20MM - Upper tab hole ID: 10MM - Lower Mount INTERNAL: 22.8MM – LOWER MOUNT EXTERNAL 41.7MM - Lower mount hole ID: 10MM - Eye to Eye: 450MM – FITS AT LEAST 90-04 KX500 | 1186 - FITS 90-04 KX500 - 39007-1186 | FITS 89 KX125 KX250, 89-04 KX500 - 46102-1253 | 1990 | KX500 | FITS 90-04 KX500 - 32037-1532 and 32037-1533 | GREEN - FITS 89-95 KX500, 89 KX125 KX250, 89-94 KDX200 - 36010-5023-6W | GREEN - FITS 90-95 KX500, 89-94 KDX200 - 36010-5187-6W | 1990 | KX500 | (2 coil style) FITS 87-89 KX500 - 21003-1169 - (1 COIL STYLE) FITS 89-91 - 21003-1215 - 432-648 OHMS: BLACK/WHITE TO BLACK/YELLOW - 4.0-6.0 OHMS: WHITE/RED TO BLACK/YELLOW | 1990 | KX500 | GRAY FITS 83-04 KX500 - 14031-1220 | FITS 89-90 KX500, 89 KX125 KX250 - 32160-1031 - KAWI MAN SAYS IT FITS 89-04 KX500 | FITS 90 KX500 - 33001-1347-CE | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 1990 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 88-04 KX500 - GEARS FIT 90-04 KX500 | 16T - FITS 88-04 KX500 - 13127-1159 | 18T - FITS 90-04 KX500 - 13260-1100 | 1990 | KX500 | 22T - FITS 90-04 KX500 - 13260-1101 | 22T - FITS 89-04 KX500 - 13260-1020 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 88-04 KX500 - 13128-1150 | 1990 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 26T - FITS 90-04 KX500 - 13260-1102 | 1990 | KX500 | 26T - FITS 90-04 KX500 - 13260-1103 | 21T - FITS 89-04 KX500 - 13260-1021 | 19T - FITS 84-86 KL600, 87-96 KLR650, 88-04 KX500 - 13129-1575 | FITS 88-04 KX500 - 16142-1086 | 1990 | KX500 | FITS 88-89 KX250, 88-04 KX500, 88-03 KX60, 89-06 KDX200, FITS 91-94 KDX250 | 1990 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | FITS 88-89 KX250, 88-04 KX500, 89-06 KDX200 - 52014-1067 | 62 LB WITH OIL AND SPARK PLUG, NO CARBURETOR | |||||||||
| YEAR | TYPE | VIN FRAME USA | ENGINE ID | ENGINE CASES | AIR BOX CAGE ELEMENT HOLDER | AIR BOX NO BOOT (DUCT) | YEAR | TYPE | AIR BOX BOOT JOINT DUCT | CABLE CLUTCH | CABLE THROTTLE | CARBURETOR | YEAR | TYPE | CARBURETOR FLOAT VALVE | CARBURETOR BOOT | CDI | YEAR | TYPE | CHAIN ADJUSTER BLOCKS | CHAIN GUIDE | YEAR | TYPE | CHAIN SLIDE | CLUTCH ARM | CLUTCH BASKET | CLUTCH FRICTION PLATES | CLUTCH COVER | CLUTCH HUB (INNER) | CLUTCH PRESSURE PLATE (OUTER) | YEAR | TYPE | COIL | COUNTER SPROCKET GUARD PLASTIC | CRANK SHAFT | CRANK SHAFT ROD KIT HOT RODS | CYLINDER | YEAR | TYPE | CYLINDER WATER NECK ELBOW | ENGINE MOUNTS FRONT | ENGINE MOUNTS UPPER | EXHAUST PIPE | EXHAUST PIPE FMF GNARLY | YEAR | TYPE | EXHAUST PIPE PRO CIRCUIT PLATINUM | EXHAUST PIPE PRO CIRCUIT PLATINUM 2 | EXHAUST PIPE PRO CIRCUIT WORKS | EXHAUST VALVE | EXHAUST VALVE COVER FRONT | EXHAUST VALVE COVER RIGHT | YEAR | TYPE | FLY WHEEL | FOOT PEGS | YEAR | TYPE | FOOT PEG SPRINGS | FORK | FORK SEAL SIZES | YEAR | TYPE | FORK GUARDS | FORK GUARD MOUNTS | FORK UNDER HOLDER (STEERING STEM LOWER CLAMP) TRIPLE TREE | FORK UPPER HOLDER (TOP CLAMP) TRIPLE TREE | YEAR | TYPE | FORK HOLDER BEARINGS (LOWER) | FORK HOLDER BEARINGS (UPPER) | YEAR | TYPE | FRONT AXLE | FRONT AXLE HOLDER | FRONT AXLE SPACERS COLLARS | FRONT BRAKE CALIPER | YEAR | TYPE | FRONT BRAKE CALIPER MOUNT | FRONT BRAKE HOSE | FRONT BRAKE LEVER | YEAR | TYPE | FRONT BRAKE MASTER CYLINDER | FRONT BRAKE ROTOR | YEAR | TYPE | FRONT BRAKE ROTOR GUARD | FRONT FENDER | FRONT HUB | YEAR | TYPE | FUEL/GAS TANK | GAS TANK CAP | YEAR | TYPE | GOVERNOR | GOVERNOR LEVER | GOVERNOR SHAFT | GOVERNOR WATER PUMP SPUR GEAR | GOVERNOR WEIGHT HOLDER | HEAD | KICK IDLER GEAR | KICK LEVER | YEAR | TYPE | KICK LEVER SHAFT | MUD FLAP | NUMBER PLATE | OIL CAPACITY | OIL DRAIN PLUG | PETCOCK FUEL VALVE TAP | PISTON | WISECO STD PISTON | YEAR | TYPE | PRIMARY CRANK GEAR | RADIATORS | RADIATOR SCREENS | RADIATOR SHROUDS | RADIATOR SHROUD RIGHT | YEAR | TYPE | REAR AXLE | REAR BRAKE BACKING PLATE | YEAR | REAR BRAKE CALIPER | REAR BRAKE CALIPER GUARD | REAR BRAKE CALIPER GUARD | REAR BRAKE CALIPER MOUNT | REAR BRAKE HOSE | YEAR | TYPE | REAR BRAKE ROTOR | REAR BRAKE LEVER | REAR BRAKE MASTER CYLINDER | YEAR | TYPE | REAR FENDER | REAR HUB | YEAR | TYPE | REAR WHEEL SPACERS | YEAR | TYPE | REED VALVE | SEAT | SHIFT DRUM | SHIFT FORKS | SHIFT LEVER | SHIFT SHAFT | YEAR | TYPE | SHOCK | SHOCK ARM LINKAGE UNI TRAK | SHOCK ARM SUSPENSION RODS (DOG BONES) | YEAR | TYPE | SHOCK BRACKETS | SIDE COVER LEFT | SIDE COVER RIGHT | YEAR | TYPE | STATOR | YEAR | TYPE | STATOR COVER | SUB FRAME | SWING ARM | SWING ARM PIVOT PIN | YEAR | TYPE | THROTTLE ASY | TRANSMISSION | TRANSMISSION INPUT SHAFT | TRANSMISSION INPUT 2ND GEAR | YEAR | TYPE | TRANSMISSION INPUT 3RD GEAR | TRANSMISSION INPUT 4TH GEAR | TRANSMISSION INPUT 5TH GEAR | TRANSMISSION OUTPUT SHAFT | TRANSMISSION OUTPUT SHAFT NUT | YEAR | TYPE | TRANSMISSION OUTPUT 1ST GEAR | TRANSMISSION OUTPUT 2ND GEAR | YEAR | TYPE | TRANSMISSION OUTPUT 3RD GEAR | TRANSMISSION OUTPUT 4TH GEAR | TRANSMISSION OUTPUT 5TH GEAR | WATER PUMP COVER | YEAR | TYPE | WATER PUMP COVER NECK | YEAR | TYPE | WATER PUMP IMPELLER | WATER PUMP NECK ELBOW | KX500 ENGINE WEIGHT |
| 1991 | KX500 | JKAKXVE12MA00XXXX | KX500BE013001 | FITS 89-04 KX500 - set 14001-5258 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 89 KX125 KX250, 90-04 KX500 11011-1304 | 1991 | KX500 | 1360 - FITS 89-04 KX500 - 14073-1360 | FITS 90 KX250, 90-04 KX500 - 54011-1304 | FITS 88-91 KX250, 88-04 KX500, 88 KDX200 - 54012-1341 | KEIHIN PWK V563 FITS 90-93 KX500 - 39MM | 1991 | KX500 | FITS 89-04 KX500 - 16065-1180 | FITS 89-04 KX500 – 21119-1267 - 19 deg BTDC @ 6000 RPM | 1991 | KX500 | FITS 90-92 KX125 KX250, 90-04 KX500 - 33040-1106 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | 1991 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500, 89-93 KDX200, 91-94 KDX250 12053-1240 | BOOK SAYS IT FITS 90 KX250, 90-04 KX500 13102-1107 - IT WILL FIT 88-04 KX500 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 87-91 KX250 KX500, 91-94 KDX250 - 13088-1069 | FITS 88-04 KX500 - 14032-1245 | FITS 89-04 KX500, 91-94 KDX250 - 13087-1138 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 1991 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | BOOK SAYS 89-91 KX500, KAWAI MAN SAYS 89-04 - 29.95 MM FLY WHEEL SIDE – 30.00 PRIMARY GEAR SIDE – 86MM STD STROKE – 13031-1285 | FITS 85-04 KX500 - 8148 | FITS 89-04 KX500 – 86MM STD BORE - 11005-1564 | 1991 | KX500 | FITS 88-96 KX500, 93-95 KLX650, 94-96 KLX250 - 52014-1065 | FITS 89-04 KX500 - 32029-1652 | FITS 89-04 KX500 - 32029-1639 | FITS 89-96 KX500 - 18002-1862 | 20055 FITS 88-04 KX500 | 1991 | KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 3 VALVE | FITS 88-92 KX250, 89-04 KX500 - 14024-1588 | FITS 88-04 KX500 - 14024-1611 | 1991 | KX500 | F4T102 71 FITS 89-91 KX500 - 21007-1183 - 2.55lb or 41.6 oz. - 4.370" OD | FITS 90 KX125 KX250, 90-91 KX500 - 34028-1318 - 34028-1319 | 1991 | KX500 | FITS 88-04 KX500, 88-96 KX125 KX250, 91 93-94 KDX250, 95-05 KDX200, 97-05 KDX220 | USD – KYB – X125-R X125-L - CHROME OD 43MM - C/L 37.25" - BLUE - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 61MM – AXLE CLAMP ID 22MM | 43MM X 55MM X 9.5/10.5/11 | 1991 | KX500 | FITS 90-93 KX125 KX250 KX500 - 55020-1384 | FITS 90-93 KX125 KX250 KX500 - 13070-1204 | FITS 91 KX125, KX250, 91-93 KX500 - 190MM C/L TO C/L OF FORK TUBES | FITS 91 KX250, 91-93 KX500 44039-1212 | 1991 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1991 | KX500 | FITS 90-92 KX125 KX250, 90-93 KX500 41068-1310 | FITS 89-93 KX500, 89-92 KX125 KX250, 93-96 KLX650C KLX650R, 94-96 KLX250R, 97-07 KLX300R, 00-10 KL250 - 44063-1056 | FITS 91 KX125 KX250. 91-92 KX500, 91-94 KDX250, 93-94 KDX200 - 43041-1427 | 1991 | KX500 | FITS 90-91 KX125 KX250 KX500, 91 KDX250 - 14079-1072 | FITS 90-93 KX125 KX250 KX500 - 43059-1577 | FITS 88-92 KX125 KX250, 88-93 KX500 KX80, 89-94 KDX200, 91-94 KD250 | 1991 | KX500 | FITS 91-92 KX125 KX250, 91 KX500 - 43015-1443 | ROTOR OD 250MM - ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 89-91 KX125 KX250, 89-93 KX500, 93-94 KDX200 | 1991 | KX500 | FITS 90-93 KX125 KX250 KX500 - 14024-1859-6F | F-1212 - GRAY - 17MM AXLE DIA - BRG TO BRG 92MM - FITS 90-92 KX125 AND 250 - 1990-1993 KX500 - 41034-1204 | 1991 | KX500 | GREEN – FITS 88-91 KX500 51001-1281-6W (SHOULD FIT 88-04 KX500) | FITS 87-95 KX125 KX250 KX500, 88-95 KX80, 89-95 KDX200, 91-94 KDX250, 93-95 KLX650, 94 KLX250 - 51049-1089 | 1991 | KX500 | SET FITS 89-04 KX500 | FITS 89-91 KX500 - 13168-1401 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 89-04 1288 E-2 OR E-1, GASKET SURFACE TO NUT SURFACE .913" - 11001-1288 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 88-91 KX500 - 13064-1134 - KAWI MAN SAYS 86-04 WILL ALL WORK | 1991 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 91 KX125 KX250 KX500 58029-5028-6W GREEN | 800 ML = .846 QUARTS | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | FLAT TOP 2 RINGS BOOK SAYS 90-04 KAWI MAN SAYS 83-04 WILL WORK 13001-1327 | 575M08600 FITS 88-04 KX500 86MM STD BORE | 1991 | KX500 | 26T - FITS 88-04 KX500 - 13097-1205 | BOOK SAYS THEY FIT 88-96 KX500 - 39061-1112 39061-1113 BUT KAWI MAN SAYS THEY FIT 88-04 KX500 | GREEN 14037-1099-6W FITS 88-95 KX500, 88-93 KX250, 90-93 KX125, 89-95 KDX200, 91-94 KDX250, 94-95 KLX250 | GREEN – FITS 91 KX500 – 49089-5114-6W | GREEN – FITS 91 KX500 – 49089-5115-6W | 1991 | KX500 | FITS 90-04 KX500, 90-92 KX125 KX250 - 41068-1299 | HYDRAULIC BRAKE | 1991 | FITS 89-93 KX125 KX250 KX500, 91-94 KDX250, 95-03 KDX200, 97-03 KDX220 - 43041-1448 | WHITE - FITS 90-93 KX125 KX250 KX500, 90-94 KDX200, 93-96 KLX650R KLX650C, 94-96 KLX250R - 55020-1323-6F | FITS 90-93 KX125 KX250, 90-91 KX500 - 43044-1092 | FITS 91-93 KX500 - 43059-1682 | 1991 | KX500 | ROTOR OD IS 220MM - ROTOR BOLT CIRCLE 6 ON 116MM FITS 91-94 KX125 KX250 KX500 - 41080-1294 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43001-1239 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43015-1368 | 1991 | KX500 | GREEN - FITS 89-04 KX500, 88-89 KX125, 89 KX250 - 35022-1241-6W | R-1213 OR 1237 - GRAY - 20MM AXLE - BRG TO BRG 130MM - ROTOR OD 220MM – ROTOR BC 6X ON 116MM – 36 SPOKES - FITS 90-94 KDX200, 90-96 KX125 KX250 KX500 - 2 BRG - 41034-1205 | 1991 | KX500 | FITS 90-96 KX125 KX250 KX500 - 92143-1356 - ID 20.26MM, MAJ OD 36.06MM, MINOR OD 25MM, LENGTH 19.63MM | 1991 | KX500 | FITS 88-04 KX500, 91-94 KDX250 - 12021-1070 | PAN STAMP 1531 – FITS 91 KX500 - KX GURU SAYS IT FITS 89-04 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 88-93 KX125, KX250 & KX500 - 13156-1240 | FITS 87-93 KX500 - 13161-1144 | 1991 | KX500 | KYB - Spring thickness: 12.0MM OD - Spring Dia: 89MM - BODY DIA 53.5MM - Spring as mounted: 265MM - Upper tab: 20MM - Upper tab hole ID: 10MM - Lower Mount INTERNAL: 22.8MM – LOWER MOUNT EXTERNAL 41.7MM - Lower mount hole ID: 10MM - Eye to Eye: 450MM – FITS AT LEAST 90-04 KX500 - 45014-1490 | 1186 - FITS 90-04 KX500 - 39007-1186 | FITS 89 KX125 KX250, 89-04 KX500 - 46102-1253 | 1991 | KX500 | FITS 90-04 KX500 - 32037-1532 and 32037-1533 | GREEN - FITS 89-95 KX500, 89 KX125 KX250, 89-94 KDX200 - 36010-5023-6W | GREEN - FITS 90-95 KX500, 89-94 KDX200 - 36010-5187-6W | 1991 | KX500 | (2 coil style) FITS 87-89 KX500 - 21003-1169 - (1 COIL STYLE) FITS 89-91 - 21003-1215 - 432-648 OHMS: BLACK/WHITE TO BLACK/YELLOW - 4.0-6.0 OHMS: WHITE/RED TO BLACK/YELLOW | 1991 | KX500 | GRAY FITS 83-04 KX500 - 14031-1220 | ALUMINUM COLOR - FITS 91-02 KX500 - 32160-1170 - KAWI MAN SAYS IT FITS 89-04 | FITS 91-93 KX500 - 33001-1371-CE | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 1991 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 88-04 KX500 - GEARS FIT 90-04 KX500 | 16T - FITS 88-04 KX500 - 13127-1159 | 18T - FITS 90-04 KX500 - 13260-1100 | 1991 | KX500 | 22T - FITS 90-04 KX500 - 13260-1101 | 22T - FITS 89-04 KX500 - 13260-1020 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 88-04 KX500 - 13128-1150 | 1991 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 26T - FITS 90-04 KX500 - 13260-1102 | 1991 | KX500 | 26T - FITS 90-04 KX500 - 13260-1103 | 21T - FITS 89-04 KX500 - 13260-1021 | 19T - FITS 84-86 KL600, 87-96 KLR650, 88-04 KX500 - 13129-1575 | FITS 88-04 KX500 - 16142-1086 | 1991 | KX500 | FITS 88-89 KX250, 88-04 KX500, 88-03 KX60, 89-06 KDX200, FITS 91-94 KDX250 | 1991 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | FITS 88-89 KX250, 88-04 KX500, 89-06 KDX200 - 52014-1067 | 62 LB WITH OIL AND SPARK PLUG, NO CARBURETOR | |||||||
| 1992 | KX500 | JKAKXVE12NA00XXXX | KX500BE013001 | FITS 89-04 KX500 - set 14001-5258 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 89 KX125 KX250, 90-04 KX500 11011-1304 | 1992 | KX500 | 1360 - FITS 89-04 KX500 - 14073-1360 | FITS 90 KX250, 90-04 KX500 - 54011-1304 | FITS 88-91 KX250, 88-04 KX500, 88 KDX200 - 54012-1341 | KEIHIN PWK V563 FITS 90-93 KX500 - 39MM | 1992 | KX500 | FITS 89-04 KX500 - 16065-1180 | FITS 89-04 KX500 – 21119-1267 - 19 deg BTDC @ 6000 RPM | 1992 | KX500 | FITS 90-92 KX125 KX250, 90-04 KX500 - 33040-1106 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | 1992 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500, 89-93 KDX200, 91-94 KDX250 12053-1240 | BOOK SAYS IT FITS 90 KX250, 90-04 KX500 13102-1107 - IT WILL FIT 88-04 KX500 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 88-04 KX500 - 14032-1245 | FITS 89-04 KX500, 91-94 KDX250 - 13087-1138 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 1992 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | BOOK SAYS 92-04 KX500, KAWAI MAN SAYS 89-04 - 29.95 MM FLY WHEEL SIDE – 30.00 PRIMARY GEAR SIDE – 86MM STD STROKE - 13031-1340 - 9.2LB | FITS 85-04 KX500 - 8148 | FITS 89-04 KX500 – 86MM STD BORE - 11005-1564 | 1992 | KX500 | FITS 88-96 KX500, 93-95 KLX650, 94-96 KLX250 - 52014-1065 | FITS 89-04 KX500 - 32029-1652 | FITS 89-04 KX500 - 32029-1639 | FITS 89-96 KX500 - 18002-1862 | 20055 FITS 88-04 KX500 | 1992 | KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 3 VALVE | FITS 88-92 KX250, 89-04 KX500 - 14024-1588 | FITS 88-04 KX500 - 14024-1611 | 1992 | KX500 | F4T107 71 FITS 92-04 KX500 - 21007-1241 - 2.55lb or 41.6 oz. - 4.370" OD | FITS 91 KX125 KX250 KDX25, 92 KX500 - 34028-1332 - 34028-1333 | 1992 | KX500 | FITS 88-04 KX500, 88-96 KX125 KX250, 91 93-94 KDX250, 95-05 KDX200, 97-05 KDX220 | USD - CHROME OD 43MM - C/L 37.25" - BLUE - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 61MM | 43MM X 55MM X 9.5/10.5/11 | 1992 | KX500 | FITS 90-93 KX125 KX250 KX500 - 55020-1384 | FITS 90-93 KX125 KX250 KX500 - 13070-1204 | FITS 91 KX125, KX250, 91-93 KX500 - 190MM C/L TO C/L OF FORK TUBES | FITS 91 KX250, 91-93 KX500 44039-1212 | 1992 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1992 | KX500 | FITS 90-92 KX125 KX250, 90-93 KX500 41068-1310 | FITS 89-93 KX500, 89-92 KX125 KX250, 93-96 KLX650C KLX650R, 94-96 KLX250R, 97-07 KLX300R, 00-10 KL250 - 44063-1056 | FITS 91 KX125 KX250. 91-92 KX500, 91-94 KDX250, 93-94 KDX200 - 43041-1427 | 1992 | KX500 | FITS 92-93 KX125 KX250 KX500, 92-94 KDX250 - 14079-1088 | FITS 90-93 KX125 KX250 KX500 - 43059-1577 | FITS 88-92 KX125 KX250, 88-93 KX500 KX80, 89-94 KDX200, 91-94 KD250 | 1992 | KX500 | FITS 92-93 KX500 - 43015-1516 | ROTOR OD 250MM - ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 89-91 KX125 KX250, 89-93 KX500, 93-94 KDX200 | 1992 | KX500 | FITS 90-93 KX125 KX250 KX500 - 14024-1859-6F | F-1212 - GRAY - 17MM AXLE DIA - BRG TO BRG 92MM - FITS 90-92 KX125 AND 250 - 1990-1993 KX500 - 41034-1204 | 1992 | KX500 | GREEN – FITS 92 KX500 51003-5390-6W (SHOULD FIT 88-04 KX500) | FITS 87-95 KX125 KX250 KX500, 88-95 KX80, 89-95 KDX200, 91-94 KDX250, 93-95 KLX650, 94 KLX250 - 51049-1089 | 1992 | KX500 | SET FITS 89-04 KX500 | FITS 92-04 KX500 - 13168-1497 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 89-04 1288 E-2 OR E-1, GASKET SURFACE TO NUT SURFACE .913" - 11001-1288 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 92-97 KX500 - 13064-1165 - KAWI MAN SAYS 86-04 WILL ALL WORK | 1992 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 92-95 KX125 KX250 KX500 58029-1074-6F WHITE | 800 ML = .846 QUARTS | FITS 92-04 KX500, 96-07 KX250, 96-05 KX125, 01-12 KX100 KX85, 00-12 KX65, 04-12 KX250F - 92066-1437 | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | FLAT TOP 2 RINGS BOOK SAYS 90-04 KAWI MAN SAYS 83-04 WILL WORK 13001-1327 | 575M08600 FITS 88-04 KX500 86MM STD BORE | 1992 | KX500 | 26T - FITS 88-04 KX500 - 13097-1205 | BOOK SAYS THEY FIT 88-96 KX500 - 39061-1112 39061-1113 BUT KAWI MAN SAYS THEY FIT 88-04 KX500 | GREEN 14037-1099-6W FITS 88-95 KX500, 88-93 KX250, 90-93 KX125, 89-95 KDX200, 91-94 KDX250, 94-95 KLX250 | GREEN – FITS 92 KX500 – 49089-5136-6W | GREEN – FITS 92 KX500 – 49089-5137-6W | 1992 | KX500 | FITS 90-04 KX500, 90-92 KX125 KX250 - 41068-1299 | HYDRAULIC BRAKE | 1992 | FITS 89-93 KX125 KX250 KX500, 91-94 KDX250, 95-03 KDX200, 97-03 KDX220 - 43041-1448 | WHITE - FITS 90-93 KX125 KX250 KX500, 90-94 KDX200, 93-96 KLX650R KLX650C, 94-96 KLX250R - 55020-1323-6F | FITS 92-95 KX500, 94 KX125 KX250 - 43044-1111 | FITS 91-93 KX500 - 43059-1682 | 1992 | KX500 | ROTOR OD IS 220MM - ROTOR BOLT CIRCLE 6 ON 116MM FITS 91-94 KX125 KX250 KX500 - 41080-1294 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43001-1239 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43015-1368 | 1992 | KX500 | GREEN - FITS 89-04 KX500, 88-89 KX125, 89 KX250 - 35022-1241-6W | R-1213 OR 1237 - GRAY - 20MM AXLE - BRG TO BRG 130MM - ROTOR OD 220MM – ROTOR BC 6X ON 116MM – 36 SPOKES - FITS 90-94 KDX200, 90-96 KX125 KX250 KX500 - 2 BRG - 41034-1205 | 1992 | KX500 | FITS 90-96 KX125 KX250 KX500 - 92143-1356 - ID 20.26MM, MAJ OD 36.06MM, MINOR OD 25MM, LENGTH 19.63MM | 1992 | KX500 | FITS 88-04 KX500, 91-94 KDX250 - 12021-1070 | PAN STAMP 1531 – FITS 92-93 KX500 - KX GURU SAYS IT FITS 89-04 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 88-93 KX125, KX250 & KX500 - 13156-1240 | FITS 87-93 KX500 - 13161-1144 | 1992 | KX500 | KYB - Spring thickness: 12.0MM OD - Spring Dia: 89MM - BODY DIA 53.5MM - Spring as mounted: 265MM - Upper tab: 20MM - Upper tab hole ID: 10MM - Lower Mount INTERNAL: 22.8MM – LOWER MOUNT EXTERNAL 41.7MM - Lower mount hole ID: 10MM - Eye to Eye: 450MM – FITS AT LEAST 90-04 KX500 - 45014-1490 | 1186 - FITS 90-04 KX500 - 39007-1186 | FITS 89 KX125 KX250, 89-04 KX500 - 46102-1253 | 1992 | KX500 | FITS 90-04 KX500 - 32037-1532 and 32037-1533 | GREEN - FITS 89-95 KX500, 89 KX125 KX250, 89-94 KDX200 - 36010-5023-6W | GREEN - FITS 90-95 KX500, 89-94 KDX200 - 36010-5187-6W | 1992 | KX500 | (1 COIL STYLE) BOOK SAYS FITS 92-96 KX500 - 21003-1242 - KAWI MAN SAYS 92-04 153-230 OHMS: BLACK/WHITE TO BLACK/YELLOW - 7.9-11.9 OHMS: WHITE/RED TO BLACK/YELLOW | 1992 | KX500 | GRAY FITS 83-04 KX500 - 14031-1220 | ALUMINUM COLOR - FITS 91-02 KX500 - 32160-1170 - KAWI MAN SAYS IT FITS 89-04 | FITS 91-93 KX500 - 33001-1371-CE | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 1992 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 88-04 KX500 - GEARS FIT 90-04 KX500 | 16T - FITS 88-04 KX500 - 13127-1159 | 18T - FITS 90-04 KX500 - 13260-1100 | 1992 | KX500 | 22T - FITS 90-04 KX500 - 13260-1101 | 22T - FITS 89-04 KX500 - 13260-1020 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 88-04 KX500 - 13128-1150 | 1992 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 26T - FITS 90-04 KX500 - 13260-1102 | 1992 | KX500 | 26T - FITS 90-04 KX500 - 13260-1103 | 21T - FITS 89-04 KX500 - 13260-1021 | 19T - FITS 84-86 KL600, 87-96 KLR650, 88-04 KX500 - 13129-1575 | FITS 88-04 KX500 - 16142-1086 | 1992 | KX500 | FITS 88-89 KX250, 88-04 KX500, 88-03 KX60, 89-06 KDX200, FITS 91-94 KDX250 | 1992 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | FITS 88-89 KX250, 88-04 KX500, 89-06 KDX200 - 52014-1067 | 62 LB WITH OIL AND SPARK PLUG, NO CARBURETOR | |||||||
| 1993 | KX500 | JKAKXVE12PA00XXXX | KX500BE013001 | FITS 89-04 KX500 - set 14001-5258 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 89 KX125 KX250, 90-04 KX500 11011-1304 | 1993 | KX500 | 1360 - FITS 89-04 KX500 - 14073-1360 | FITS 90 KX250, 90-04 KX500 - 54011-1304 | FITS 88-91 KX250, 88-04 KX500, 88 KDX200 - 54012-1341 | KEIHIN PWK V563 FITS 90-93 KX500 - 39MM | 1993 | KX500 | FITS 89-04 KX500 - 16065-1180 | FITS 89-04 KX500 – 21119-1267 - 19 deg BTDC @ 6000 RPM | 1993 | KX500 | FITS 90-92 KX125 KX250, 90-04 KX500 - 33040-1106 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | 1993 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500, 89-93 KDX200, 91-94 KDX250 12053-1240 | BOOK SAYS IT FITS 90 KX250, 90-04 KX500 13102-1107 - IT WILL FIT 88-04 KX500 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 88-04 KX500 - 14032-1245 | FITS 89-04 KX500, 91-94 KDX250 - 13087-1138 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 1993 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | BOOK SAYS 92-04 KX500, KAWAI MAN SAYS 89-04 - 29.95 MM FLY WHEEL SIDE – 30.00 PRIMARY GEAR SIDE – 86MM STD STROKE - 13031-1340 - 9.2LB | FITS 85-04 KX500 - 8148 | FITS 89-04 KX500 – 86MM STD BORE - 11005-1564 | 1993 | KX500 | FITS 88-96 KX500, 93-95 KLX650, 94-96 KLX250 - 52014-1065 | FITS 89-04 KX500 - 32029-1652 | FITS 89-04 KX500 - 32029-1639 | FITS 89-96 KX500 - 18002-1862 | 20055 FITS 88-04 KX500 | 1993 | KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 3 VALVE | FITS 88-92 KX250, 89-04 KX500 - 14024-1588 | FITS 88-04 KX500 - 14024-1611 | 1993 | KX500 | F4T107 71 FITS 92-04 KX500 - 21007-1241 - 2.55lb or 41.6 oz. - 4.370" OD | FITS 92-96 KX125 KX250, 93-04 KX500, 92-94 KDX250, 95-05 KDX200, 97-05 KDX220 - 34028-1332-CE 34028-1365-CE | 1993 | KX500 | FITS 88-04 KX500, 88-96 KX125 KX250, 91 93-94 KDX250, 95-05 KDX200, 97-05 KDX220 | USD - CHROME OD 43MM - C/L 37.25" - BLUE - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 61MM | 43MM X 55MM X 9.5/10.5/11 | 1993 | KX500 | FITS 90-93 KX125 KX250 KX500 - 55020-1384 | FITS 90-93 KX125 KX250 KX500 - 13070-1204 | FITS 91 KX125, KX250, 91-93 KX500 - 190MM C/L TO C/L OF FORK TUBES | FITS 91 KX250, 91-93 KX500 44039-1212 | 1993 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1993 | KX500 | FITS 90-92 KX125 KX250, 90-93 KX500 41068-1310 | FITS 89-93 KX500, 89-92 KX125 KX250, 93-96 KLX650C KLX650R, 94-96 KLX250R, 97-07 KLX300R, 00-10 KL250 - 44063-1056 | FITS 92-93 KX125 KX250, 93 KX500 - 43041-1462 | 1993 | KX500 | FITS 92-93 KX125 KX250 KX500, 92-94 KDX250 - 14079-1088 | FITS 90-93 KX125 KX250 KX500 - 43059-1577 | FITS 88-92 KX125 KX250, 88-93 KX500 KX80, 89-94 KDX200, 91-94 KD250 | 1993 | KX500 | FITS 92-93 KX500 - 43015-1516 | ROTOR OD 250MM - ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 89-91 KX125 KX250, 89-93 KX500, 93-94 KDX200 | 1993 | KX500 | FITS 90-93 KX125 KX250 KX500 - 14024-1859-6F | F-1212 - GRAY - 17MM AXLE DIA - BRG TO BRG 92MM - FITS 90-92 KX125 AND 250 - 1990-1993 KX500 - 41034-1204 | 1993 | KX500 | GREEN – FITS 93-94 KX500 51001-1473-6W (KAWI MAN SAYS FITS 88-04 KX500) | FITS 87-95 KX125 KX250 KX500, 88-95 KX80, 89-95 KDX200, 91-94 KDX250, 93-95 KLX650, 94 KLX250 - 51049-1089 | 1993 | KX500 | SET FITS 89-04 KX500 | FITS 92-04 KX500 - 13168-1497 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 89-04 1288 E-2 OR E-1, GASKET SURFACE TO NUT SURFACE .913" - 11001-1288 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 92-97 KX500 - 13064-1165 - KAWI MAN SAYS 86-04 WILL ALL WORK | 1993 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 92-95 KX125 KX250 KX500 58029-1074-6F WHITE | 800 ML = .846 QUARTS | FITS 92-04 KX500, 96-07 KX250, 96-05 KX125, 01-12 KX100 KX85, 00-12 KX65, 04-12 KX250F - 92066-1437 | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | FLAT TOP 2 RINGS BOOK SAYS 90-04 KAWI MAN SAYS 83-04 WILL WORK 13001-1327 | 575M08600 FITS 88-04 KX500 86MM STD BORE | 1993 | KX500 | 26T - FITS 88-04 KX500 - 13097-1205 | BOOK SAYS THEY FIT 88-96 KX500 - 39061-1112 39061-1113 BUT KAWI MAN SAYS THEY FIT 88-04 KX500 | GREEN 14037-1099-6W FITS 88-95 KX500, 88-93 KX250, 90-93 KX125, 89-95 KDX200, 91-94 KDX250, 94-95 KLX250 | GREEN – FITS 93 KX500 – 49089-5159-6W | GREEN – FITS 93 KX500 – 49089-5160-6W | 1993 | KX500 | FITS 90-04 KX500, 90-92 KX125 KX250 - 41068-1299 | HYDRAULIC BRAKE | 1993 | FITS 89-93 KX125 KX250 KX500, 91-94 KDX250, 95-03 KDX200, 97-03 KDX220 - 43041-1448 | WHITE - FITS 90-93 KX125 KX250 KX500, 90-94 KDX200, 93-96 KLX650R KLX650C, 94-96 KLX250R - 55020-1323-6F | FITS 92-95 KX500, 94 KX125 KX250 - 43044-1111 | FITS 91-93 KX500 - 43059-1682 | 1993 | KX500 | ROTOR OD IS 220MM - ROTOR BOLT CIRCLE 6 ON 116MM FITS 91-94 KX125 KX250 KX500 - 41080-1294 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43001-1239 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43015-1368 | 1993 | KX500 | GREEN - FITS 89-04 KX500, 88-89 KX125, 89 KX250 - 35022-1241-6W | R-1213 OR 1237 - GRAY - 20MM AXLE - BRG TO BRG 130MM - ROTOR OD 220MM – ROTOR BC 6X ON 116MM – 36 SPOKES - FITS 90-94 KDX200, 90-96 KX125 KX250 KX500 - 2 BRG - 41034-1205 | 1993 | KX500 | FITS 90-96 KX125 KX250 KX500 - 92143-1356 - ID 20.26MM, MAJ OD 36.06MM, MINOR OD 25MM, LENGTH 19.63MM | 1993 | KX500 | FITS 88-04 KX500, 91-94 KDX250 - 12021-1070 | PAN STAMP 1531 – FITS 92-93 KX500 - KX GURU SAYS IT FITS 89-04 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 88-93 KX125, KX250 & KX500 - 13156-1240 | FITS 87-93 KX500 - 13161-1144 | 1993 | KX500 | KYB - Spring thickness: 12.0MM OD - Spring Dia: 89MM - BODY DIA 53.5MM - Spring as mounted: 265MM - Upper tab: 20MM - Upper tab hole ID: 10MM - Lower Mount INTERNAL: 22.8MM – LOWER MOUNT EXTERNAL 41.7MM - Lower mount hole ID: 10MM - Eye to Eye: 450MM – FITS AT LEAST 90-04 KX500 - 45014-1490 | 1186 - FITS 90-04 KX500 - 39007-1186 | FITS 89 KX125 KX250, 89-04 KX500 - 46102-1253 | 1993 | KX500 | FITS 90-04 KX500 - 32037-1532 and 32037-1533 | GREEN - FITS 89-95 KX500, 89 KX125 KX250, 89-94 KDX200 - 36010-5023-6W | GREEN - FITS 90-95 KX500, 89-94 KDX200 - 36010-5187-6W | 1993 | KX500 | (1 COIL STYLE) BOOK SAYS FITS 92-96 KX500 - 21003-1242 - KAWI MAN SAYS 92-04 153-230 OHMS: BLACK/WHITE TO BLACK/YELLOW - 7.9-11.9 OHMS: WHITE/RED TO BLACK/YELLOW | 1993 | KX500 | GRAY FITS 83-04 KX500 - 14031-1220 | ALUMINUM COLOR - FITS 91-02 KX500 - 32160-1170 - KAWI MAN SAYS IT FITS 89-04 | FITS 91-93 KX500 - 33001-1371-CE | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 1993 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 88-04 KX500 - GEARS FIT 90-04 KX500 | 16T - FITS 88-04 KX500 - 13127-1159 | 18T - FITS 90-04 KX500 - 13260-1100 | 1993 | KX500 | 22T - FITS 90-04 KX500 - 13260-1101 | 22T - FITS 89-04 KX500 - 13260-1020 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 88-04 KX500 - 13128-1150 | 1993 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 26T - FITS 90-04 KX500 - 13260-1102 | 1993 | KX500 | 26T - FITS 90-04 KX500 - 13260-1103 | 21T - FITS 89-04 KX500 - 13260-1021 | 19T - FITS 84-86 KL600, 87-96 KLR650, 88-04 KX500 - 13129-1575 | FITS 88-04 KX500 - 16142-1086 | 1993 | KX500 | FITS 88-89 KX250, 88-04 KX500, 88-03 KX60, 89-06 KDX200, FITS 91-94 KDX250 | 1993 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | FITS 88-89 KX250, 88-04 KX500, 89-06 KDX200 - 52014-1067 | 62 LB WITH OIL AND SPARK PLUG, NO CARBURETOR | |||||||
| 1994 | KX500 | JKAKXVE12RA00XXXX | KX500BE013001 | FITS 89-04 KX500 - set 14001-5258 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 89 KX125 KX250, 90-04 KX500 11011-1304 | 1994 | KX500 | 1360 - FITS 89-04 KX500 - 14073-1360 | FITS 90 KX250, 90-04 KX500 - 54011-1304 | FITS 88-91 KX250, 88-04 KX500, 88 KDX200 - 54012-1341 | KEIHIN PWK V923 FITS 94-95 KX500 - 39MM | 1994 | KX500 | FITS 89-04 KX500 - 16065-1180 | FITS 89-04 KX500 – 21119-1267 - 19 deg BTDC @ 6000 RPM | 1994 | KX500 | FITS 90-92 KX125 KX250, 90-04 KX500 - 33040-1106 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | 1994 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500, 89-93 KDX200, 91-94 KDX250 12053-1240 | BOOK SAYS IT FITS 90 KX250, 90-04 KX500 13102-1107 - IT WILL FIT 88-04 KX500 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 88-04 KX500 - 14032-1245 | FITS 89-04 KX500, 91-94 KDX250 - 13087-1138 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 1994 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | BOOK SAYS 92-04 KX500, KAWAI MAN SAYS 89-04 - 29.95 MM FLY WHEEL SIDE – 30.00 PRIMARY GEAR SIDE – 86MM STD STROKE - 13031-1340 - 9.2LB | FITS 85-04 KX500 - 8148 | FITS 89-04 KX500 – 86MM STD BORE - 11005-1564 | 1994 | KX500 | FITS 88-96 KX500, 93-95 KLX650, 94-96 KLX250 - 52014-1065 | FITS 89-04 KX500 - 32029-1652 | FITS 89-04 KX500 - 32029-1639 | FITS 89-96 KX500 - 18002-1862 | 20055 FITS 88-04 KX500 | 1994 | KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 3 VALVE | FITS 88-92 KX250, 89-04 KX500 - 14024-1588 | FITS 88-04 KX500 - 14024-1611 | 1994 | KX500 | F4T107 71 FITS 92-04 KX500 - 21007-1241 - 2.55lb or 41.6 oz. - 4.370" OD | FITS 92-96 KX125 KX250, 93-04 KX500, 92-94 KDX250, 95-05 KDX200, 97-05 KDX220 - 34028-1332-CE 34028-1365-CE | 1994 | KX500 | FITS 88-04 KX500, 88-96 KX125 KX250, 91 93-94 KDX250, 95-05 KDX200, 97-05 KDX220 | KYB KX94L KX94R - CHROME OD 43MM - C/L 37.25" - UPPER 51.9MM - LOWER 56.6MM - BRAKE CALIPER C/L 102MM | 43MM X 55MM X 9.5/10.5/11 | 1994 | KX500 | FITS 94-95 KX125 KX250 KX500 - 55020-1492-RZ | FITS 94-95 KX125 KX250 KX500 - LH 13070-1277 - RH 13070-1278 | FITS 94-95 KX500 - 190MM C/L TO C/L OF FORK TUBES | FITS 94-95 KX500 44039-1252 | 1994 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1994 | KX500 | FITS 93-98 KX125 & KX250, 94-04 KX500 – 41068-1342 | FITS 93-03 KX125 KX250, 94-04 KX500 - 92143-1581 - 92143-1580 | ML3 3 - FITS 94-96 KX125 & KX250, 94-03 KX500, 95-03 KDX200, 97-03 KDX220, 96 KLX650R, 97-03 KLX300R - 43041-1576 | 1994 | KX500 | NISSIN 555 - FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 - 14079-1097 | FITS 94 KX125 KX250 KX500 - 43059-1760 | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | 1994 | KX500 | FITS 94-95 KX125 KX250 KX500 KX80 - 43015-1556 | ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 115MM - FITS KX125 AND 250 92-02 - KX500 94-04 - KLX650R 93-96 - KLX300R 97-07 | 1994 | KX500 | GREEN - FITS 94-02 KX125 KX250, 94-04 KX500 - 35004-1318-6W | F-1249 - AXLE OD 20MM - BRG TO BRG 89.5MM - ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 93-98 KX125 KX250, 94-04 KX500 - 41034-1226 | 1994 | KX500 | GREEN – FITS 93-94 KX500 51001-1473-6W (KAWI MAN SAYS FITS 88-04 KX500) | FITS 87-95 KX125 KX250 KX500, 88-95 KX80, 89-95 KDX200, 91-94 KDX250, 93-95 KLX650, 94 KLX250 - 51049-1089 | 1994 | KX500 | SET FITS 89-04 KX500 | FITS 92-04 KX500 - 13168-1497 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 89-04 1288 E-2 OR E-1, GASKET SURFACE TO NUT SURFACE .913" - 11001-1288 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 92-97 KX500 - 13064-1165 - KAWI MAN SAYS 86-04 WILL ALL WORK | 1994 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 92-95 KX125 KX250 KX500 58029-1074-6F WHITE | 800 ML = .846 QUARTS | FITS 92-04 KX500, 96-07 KX250, 96-05 KX125, 01-12 KX100 KX85, 00-12 KX65, 04-12 KX250F - 92066-1437 | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | FLAT TOP 2 RINGS BOOK SAYS 90-04 KAWI MAN SAYS 83-04 WILL WORK 13001-1327 | 575M08600 FITS 88-04 KX500 86MM STD BORE | 1994 | KX500 | 26T - FITS 88-04 KX500 - 13097-1205 | BOOK SAYS THEY FIT 88-96 KX500 - 39061-1112 39061-1113 BUT KAWI MAN SAYS THEY FIT 88-04 KX500 | GREEN 14037-1099-6W FITS 88-95 KX500, 88-93 KX250, 90-93 KX125, 89-95 KDX200, 91-94 KDX250, 94-95 KLX250 | GREEN – FITS 94 KX500 – 49089-5195-6W | GREEN – FITS 94 KX500 – 49089-5196-6W | 1994 | KX500 | FITS 90-04 KX500, 90-92 KX125 KX250 - 41068-1299 | HYDRAULIC BRAKE | 1994 | FITS 94 KX125 KX250, 94-95 KX500 - 43041-1532 | FITS 94-02 KX125 KX250 KX500, 95-02 KDX200, 97-02 KDX220 KLX300R, 96 KLX650R - 55020-1488-6F | FITS 92-95 KX500, 94 KX125 KX250 - 43044-1111 | 1994 | KX500 | ROTOR OD IS 220MM - ROTOR BOLT CIRCLE 6 ON 116MM FITS 91-94 KX125 KX250 KX500 - 41080-1294 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43001-1239 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43015-1368 | 1994 | KX500 | GREEN - FITS 89-04 KX500, 88-89 KX125, 89 KX250 - 35022-1241-6W | R-1213 OR 1237 - GRAY - 20MM AXLE - BRG TO BRG 130MM - ROTOR OD 220MM – ROTOR BC 6X ON 116MM – 36 SPOKES - FITS 90-94 KDX200, 90-96 KX125 KX250 KX500 - 2 BRG - 41034-1205 | 1994 | KX500 | FITS 90-96 KX125 KX250 KX500 - 92143-1356 - ID 20.26MM, MAJ OD 36.06MM, MINOR OD 25MM, LENGTH 19.63MM | 1994 | KX500 | FITS 88-04 KX500, 91-94 KDX250 - 12021-1070 | PAN STAMP 1531 – FITS 88-89 KX125 KX250, 88-90 KX500, 94 KX500 - KX GURU SAYS IT FITS 89-04 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 94-01 KX125 KX250, 94-04 KX500, 00-09 KX65 - 13156-1347 | FITS 94-04 KX500 - 13161-1203 | 1994 | KX500 | KYB - Spring thickness: 12.0MM OD - Spring Dia: 89MM - BODY DIA 53.5MM - Spring as mounted: 265MM - Upper tab: 20MM - Upper tab hole ID: 10MM - Lower Mount INTERNAL: 22.8MM – LOWER MOUNT EXTERNAL 41.7MM - Lower mount hole ID: 10MM - Eye to Eye: 450MM – FITS AT LEAST 90-04 KX500 | 1186 - FITS 90-04 KX500 - 39007-1186 | FITS 89 KX125 KX250, 89-04 KX500 - 46102-1253 | 1994 | KX500 | FITS 90-04 KX500 - 32037-1532 and 32037-1533 | GREEN - FITS 89-95 KX500, 89 KX125 KX250, 89-94 KDX200 - 36010-5023-6W | GREEN - FITS 90-95 KX500, 89-94 KDX200 - 36010-5187-6W | 1994 | KX500 | (1 COIL STYLE) BOOK SAYS FITS 92-96 KX500 - 21003-1242 - KAWI MAN SAYS 92-04 153-230 OHMS: BLACK/WHITE TO BLACK/YELLOW - 7.9-11.9 OHMS: WHITE/RED TO BLACK/YELLOW | 1994 | KX500 | GRAY FITS 83-04 KX500 - 14031-1220 | ALUMINUM COLOR - FITS 91-02 KX500 - 32160-1170 - KAWI MAN SAYS IT FITS 89-04 | FITS 94-95 KX500 - 33001-1371-TX | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 1994 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 88-04 KX500 - GEARS FIT 90-04 KX500 | 16T - FITS 88-04 KX500 - 13127-1159 | 18T - FITS 90-04 KX500 - 13260-1100 | 1994 | KX500 | 22T - FITS 90-04 KX500 - 13260-1101 | 22T - FITS 89-04 KX500 - 13260-1020 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 88-04 KX500 - 13128-1150 | 1994 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 26T - FITS 90-04 KX500 - 13260-1102 | 1994 | KX500 | 26T - FITS 90-04 KX500 - 13260-1103 | 21T - FITS 89-04 KX500 - 13260-1021 | 19T - FITS 84-86 KL600, 87-96 KLR650, 88-04 KX500 - 13129-1575 | FITS 88-04 KX500 - 16142-1086 | 1994 | KX500 | FITS 88-89 KX250, 88-04 KX500, 88-03 KX60, 89-06 KDX200, FITS 91-94 KDX250 | 1994 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | FITS 88-89 KX250, 88-04 KX500, 89-06 KDX200 - 52014-1067 | 62 LB WITH OIL AND SPARK PLUG, NO CARBURETOR | ||||||||
| 1995 | KX500 | JKAKXVE12SA00XXXX | KX500BE013001 | FITS 89-04 KX500 - set 14001-5258 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 89 KX125 KX250, 90-04 KX500 11011-1304 | 1995 | KX500 | 1360 - FITS 89-04 KX500 - 14073-1360 | FITS 90 KX250, 90-04 KX500 - 54011-1304 | FITS 88-91 KX250, 88-04 KX500, 88 KDX200 - 54012-1341 | KEIHIN PWK V923 FITS 94-95 KX500 - 39MM | 1995 | KX500 | FITS 89-04 KX500 - 16065-1180 | FITS 89-04 KX500 – 21119-1267 - 19 deg BTDC @ 6000 RPM | 1995 | KX500 | FITS 90-92 KX125 KX250, 90-04 KX500 - 33040-1106 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | 1995 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500, 89-93 KDX200, 91-94 KDX250 12053-1240 | BOOK SAYS IT FITS 90 KX250, 90-04 KX500 13102-1107 - IT WILL FIT 88-04 KX500 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 88-04 KX500 - 14032-1245 | FITS 89-04 KX500, 91-94 KDX250 - 13087-1138 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 1995 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | BOOK SAYS 92-04 KX500, KAWAI MAN SAYS 89-04 - 29.95 MM FLY WHEEL SIDE – 30.00 PRIMARY GEAR SIDE – 86MM STD STROKE - 13031-1340 - 9.2LB | FITS 85-04 KX500 - 8148 | FITS 89-04 KX500 – 86MM STD BORE - 11005-1564 | 1995 | KX500 | FITS 88-96 KX500, 93-95 KLX650, 94-96 KLX250 - 52014-1065 | FITS 89-04 KX500 - 32029-1652 | FITS 89-04 KX500 - 32029-1639 | FITS 89-96 KX500 - 18002-1862 | 20055 FITS 88-04 KX500 | 1995 | KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 3 VALVE | FITS 88-92 KX250, 89-04 KX500 - 14024-1588 | FITS 88-04 KX500 - 14024-1611 | 1995 | KX500 | F4T107 71 FITS 92-04 KX500 - 21007-1241 - 2.55lb or 41.6 oz. - 4.370" OD | FITS 92-96 KX125 KX250, 93-04 KX500, 92-94 KDX250, 95-05 KDX200, 97-05 KDX220 - 34028-1332-CE 34028-1365-CE | 1995 | KX500 | FITS 88-04 KX500, 88-96 KX125 KX250, 91 93-94 KDX250, 95-05 KDX200, 97-05 KDX220 | KYB KX94L KX94R - CHROME OD 43MM - C/L 37.25" - UPPER 51.9MM - LOWER 56.6MM - BRAKE CALIPER C/L 102MM | 43MM X 55MM X 9.5/10.5/11 | 1995 | KX500 | FITS 94-95 KX125 KX250 KX500 - 55020-1492-RZ | FITS 94-95 KX125 KX250 KX500 - LH 13070-1277 - RH 13070-1278 | FITS 94-95 KX500 - 190MM C/L TO C/L OF FORK TUBES | FITS 94-95 KX500 44039-1252 | 1995 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1995 | KX500 | FITS 93-98 KX125 & KX250, 94-04 KX500 – 41068-1342 | FITS 93-03 KX125 KX250, 94-04 KX500 - 92143-1581 - 92143-1580 | ML3 3 - FITS 94-96 KX125 & KX250, 94-03 KX500, 95-03 KDX200, 97-03 KDX220, 96 KLX650R, 97-03 KLX300R - 43041-1576 | 1995 | KX500 | NISSIN 555 - FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 - 14079-1097 | FITS 95 KX125 KX250 KX500 - 43059-1881 | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | 1995 | KX500 | FITS 94-95 KX125 KX250 KX500 KX80 - 43015-1556 | ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 115MM - FITS KX125 AND 250 92-02 - KX500 94-04 - KLX650R 93-96 - KLX300R 97-07 | 1995 | KX500 | GREEN - FITS 94-02 KX125 KX250, 94-04 KX500 - 35004-1318-6W | F-1249 - AXLE OD 20MM - BRG TO BRG 89.5MM - ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 93-98 KX125 KX250, 94-04 KX500 - 41034-1226 | 1995 | KX500 | GREEN – FITS 95 KX500 51080-5123-6W (SHOULD FIT 88-04 KX500) | FITS 87-95 KX125 KX250 KX500, 88-95 KX80, 89-95 KDX200, 91-94 KDX250, 93-95 KLX650, 94 KLX250 - 51049-1089 | 1995 | KX500 | SET FITS 89-04 KX500 | FITS 92-04 KX500 - 13168-1497 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 89-04 1288 E-2 OR E-1, GASKET SURFACE TO NUT SURFACE .913" - 11001-1288 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 92-97 KX500 - 13064-1165 - KAWI MAN SAYS 86-04 WILL ALL WORK | 1995 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 92-95 KX125 KX250 KX500 58029-1074-6F WHITE | 800 ML = .846 QUARTS | FITS 92-04 KX500, 96-07 KX250, 96-05 KX125, 01-12 KX100 KX85, 00-12 KX65, 04-12 KX250F - 92066-1437 | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | FLAT TOP 2 RINGS BOOK SAYS 90-04 KAWI MAN SAYS 83-04 WILL WORK 13001-1327 | 575M08600 FITS 88-04 KX500 86MM STD BORE | 1995 | KX500 | 26T - FITS 88-04 KX500 - 13097-1205 | BOOK SAYS THEY FIT 88-96 KX500 - 39061-1112 39061-1113 BUT KAWI MAN SAYS THEY FIT 88-04 KX500 | GREEN 14037-1099-6W FITS 88-95 KX500, 88-93 KX250, 90-93 KX125, 89-95 KDX200, 91-94 KDX250, 94-95 KLX250 | GREEN – FITS 95 KX500 – 49089-5229-6W | GREEN – FITS 95 KX500 – 49089-5230-6W | 1995 | KX500 | FITS 90-04 KX500, 90-92 KX125 KX250 - 41068-1299 | HYDRAULIC BRAKE | 1995 | FITS 94 KX125 KX250, 94-95 KX500 - 43041-1532 | FITS 94-02 KX125 KX250 KX500, 95-02 KDX200, 97-02 KDX220 KLX300R, 96 KLX650R - 55020-1488-6F | FITS 92-95 KX500, 94 KX125 KX250 - 43044-1111 | 1995 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43001-1239 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43015-1368 | 1995 | KX500 | GREEN - FITS 89-04 KX500, 88-89 KX125, 89 KX250 - 35022-1241-6W | R-1213 OR 1237 - GRAY - 20MM AXLE - BRG TO BRG 130MM - ROTOR OD 220MM – ROTOR BC 6X ON 116MM – 36 SPOKES - FITS 90-94 KDX200, 90-96 KX125 KX250 KX500 - 2 BRG - 41034-1205 | 1995 | KX500 | FITS 90-96 KX125 KX250 KX500 - 92143-1356 - ID 20.26MM, MAJ OD 36.06MM, MINOR OD 25MM, LENGTH 19.63MM | 1995 | KX500 | FITS 88-04 KX500, 91-94 KDX250 - 12021-1070 | PAN STAMP 1531 – FITS 95 & 97 KX500 - KX GURU SAYS IT FITS 89-04 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 94-01 KX125 KX250, 94-04 KX500, 00-09 KX65 - 13156-1347 | FITS 94-04 KX500 - 13161-1203 | 1995 | KX500 | KYB - Spring thickness: 12.0MM OD - Spring Dia: 89MM - BODY DIA 53.5MM - Spring as mounted: 265MM - Upper tab: 20MM - Upper tab hole ID: 10MM - Lower Mount INTERNAL: 22.8MM – LOWER MOUNT EXTERNAL 41.7MM - Lower mount hole ID: 10MM - Eye to Eye: 450MM – FITS AT LEAST 90-04 KX500 | 1186 - FITS 90-04 KX500 - 39007-1186 | FITS 89 KX125 KX250, 89-04 KX500 - 46102-1253 | 1995 | KX500 | FITS 90-04 KX500 - 32037-1532 and 32037-1533 | GREEN - FITS 89-95 KX500, 89 KX125 KX250, 89-94 KDX200 - 36010-5023-6W | GREEN - FITS 90-95 KX500, 89-94 KDX200 - 36010-5187-6W | 1995 | KX500 | (1 COIL STYLE) BOOK SAYS FITS 92-96 KX500 - 21003-1242 - KAWI MAN SAYS 92-04 153-230 OHMS: BLACK/WHITE TO BLACK/YELLOW - 7.9-11.9 OHMS: WHITE/RED TO BLACK/YELLOW | 1995 | KX500 | GRAY FITS 83-04 KX500 - 14031-1220 | ALUMINUM COLOR - FITS 91-02 KX500 - 32160-1170 - KAWI MAN SAYS IT FITS 89-04 | FITS 94-95 KX500 - 33001-1371-TX | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 1995 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 88-04 KX500 - GEARS FIT 90-04 KX500 | 16T - FITS 88-04 KX500 - 13127-1159 | 18T - FITS 90-04 KX500 - 13260-1100 | 1995 | KX500 | 22T - FITS 90-04 KX500 - 13260-1101 | 22T - FITS 89-04 KX500 - 13260-1020 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 88-04 KX500 - 13128-1150 | 1995 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 26T - FITS 90-04 KX500 - 13260-1102 | 1995 | KX500 | 26T - FITS 90-04 KX500 - 13260-1103 | 21T - FITS 89-04 KX500 - 13260-1021 | 19T - FITS 84-86 KL600, 87-96 KLR650, 88-04 KX500 - 13129-1575 | FITS 88-04 KX500 - 16142-1086 | 1995 | KX500 | FITS 88-89 KX250, 88-04 KX500, 88-03 KX60, 89-06 KDX200, FITS 91-94 KDX250 | 1995 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | FITS 88-89 KX250, 88-04 KX500, 89-06 KDX200 - 52014-1067 | 62 LB WITH OIL AND SPARK PLUG, NO CARBURETOR | |||||||||
| 1996 | KX500 | JKAKXVE12TA01XXXX | KX500BE013001 | FITS 89-04 KX500 - set 14001-5258 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 89 KX125 KX250, 90-04 KX500 11011-1304 | 1996 | KX500 | 1360 - FITS 89-04 KX500 - 14073-1360 | FITS 90 KX250, 90-04 KX500 - 54011-1304 | FITS 88-91 KX250, 88-04 KX500, 88 KDX200 - 54012-1341 | KEIHIN PWK G250 FITS 96-04 KX500 - 39MM | 1996 | KX500 | FITS 89-04 KX500 - 16065-1180 | FITS 89-04 KX500 – 21119-1267 - 19 deg BTDC @ 6000 RPM | 1996 | KX500 | FITS 90-92 KX125 KX250, 90-04 KX500 - 33040-1106 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | 1996 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500, 89-93 KDX200, 91-94 KDX250 12053-1240 | BOOK SAYS IT FITS 90 KX250, 90-04 KX500 13102-1107 - IT WILL FIT 88-04 KX500 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 88-04 KX500 - 14032-1245 | FITS 89-04 KX500, 91-94 KDX250 - 13087-1138 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 1996 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | BOOK SAYS 92-04 KX500, KAWAI MAN SAYS 89-04 - 29.95 MM FLY WHEEL SIDE – 30.00 PRIMARY GEAR SIDE – 86MM STD STROKE - 13031-1340 - 9.2LB | FITS 85-04 KX500 - 8148 | FITS 89-04 KX500 – 86MM STD BORE - 11005-1564 | 1996 | KX500 | FITS 88-96 KX500, 93-95 KLX650, 94-96 KLX250 - 52014-1065 | FITS 89-04 KX500 - 32029-1652 | FITS 89-04 KX500 - 32029-1639 | FITS 89-96 KX500 - 18002-1862 | 20055 FITS 88-04 KX500 | 1996 | KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 3 VALVE | FITS 88-92 KX250, 89-04 KX500 - 14024-1588 | FITS 88-04 KX500 - 14024-1611 | 1996 | KX500 | F4T107 71 FITS 92-04 KX500 - 21007-1241 - 2.55lb or 41.6 oz. - 4.370" OD | FITS 92-96 KX125 KX250, 93-04 KX500, 92-94 KDX250, 95-05 KDX200, 97-05 KDX220 - 34028-1332-CE 34028-1365-CE | 1996 | KX500 | FITS 88-04 KX500, 88-96 KX125 KX250, 91 93-94 KDX250, 95-05 KDX200, 97-05 KDX220 | CHROME OD 43MM C/L 37.25" - FITS 96 KX500 | 43MM X 55MM X 9.5/10.5/11 | 1996 | KX500 | FITS 96 KX500 | FITS 96 KX500 - 190MM C/L TO C/L OF FORK TUBES | FITS 96 KX500 44039-1266 | 1996 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1996 | KX500 | FITS 93-98 KX125 & KX250, 94-04 KX500 – 41068-1342 | FITS 93-03 KX125 KX250, 94-04 KX500 - 92143-1581 - 92143-1580 | ML3 3 - FITS 94-96 KX125 & KX250, 94-03 KX500, 95-03 KDX200, 97-03 KDX220, 96 KLX650R, 97-03 KLX300R - 43041-1576 | 1996 | KX500 | NISSIN 555 - FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 - 14079-1097 | FITS 96 KX125 KX250, 96-04 KX500 - 43059-1913 | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | 1996 | KX500 | FITS 96 KX125 KX250 KX500 - 43015-1574 | ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 115MM - FITS KX125 AND 250 92-02 - KX500 94-04 - KLX650R 93-96 - KLX300R 97-07 | 1996 | KX500 | GREEN - FITS 94-02 KX125 KX250, 94-04 KX500 - 35004-1318-6W | F-1249 - AXLE OD 20MM - BRG TO BRG 89.5MM - ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 93-98 KX125 KX250, 94-04 KX500 - 41034-1226 | 1996 | KX500 | VIOLET – FITS 96 KX500 51001-1473-RE (SHOULD FIT 88-04 KX500) | 1996 | KX500 | SET FITS 89-04 KX500 | FITS 92-04 KX500 - 13168-1497 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 89-04 1288 E-2 OR E-1, GASKET SURFACE TO NUT SURFACE .913" - 11001-1288 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 92-97 KX500 - 13064-1165 - KAWI MAN SAYS 86-04 WILL ALL WORK | 1996 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 96-02 KX125 KX250 KX500 58029-1078-6F WHITE | 800 ML = .846 QUARTS | FITS 92-04 KX500, 96-07 KX250, 96-05 KX125, 01-12 KX100 KX85, 00-12 KX65, 04-12 KX250F - 92066-1437 | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | FLAT TOP 2 RINGS BOOK SAYS 90-04 KAWI MAN SAYS 83-04 WILL WORK 13001-1327 | 575M08600 FITS 88-04 KX500 86MM STD BORE | 1996 | KX500 | 26T - FITS 88-04 KX500 - 13097-1205 | BOOK SAYS THEY FIT 88-96 KX500 - 39061-1112 39061-1113 BUT KAWI MAN SAYS THEY FIT 88-04 KX500 | VIOLET 14037-1099-RE FITS 96 KX500 KDX200 | VIOLET – FITS 95 KX500 - 49089-1087-RE | VIOLET – FITS 95 KX500 – 49089-1088-RE | 1996 | KX500 | FITS 90-04 KX500, 90-92 KX125 KX250 - 41068-1299 | HYDRAULIC BRAKE | 1996 | FITS 95-96 KX125 KX250, 96-03 KX500, 96 KLX650R, 97-03 KLX300R - 43041-1577 | FITS 94-02 KX125 KX250 KX500, 95-02 KDX200, 97-02 KDX220 KLX300R, 96 KLX650R - 55020-1488-6F | FITS 95-96 KX125 KX250, 96-04 KX500, 96 KLX650R, 97-07 KLX300R - 14079-1105 | 1996 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43001-1239 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43015-1368 | 1996 | KX500 | GREEN - FITS 89-04 KX500, 88-89 KX125, 89 KX250 - 35022-1241-6W | R-1213 OR 1237 - GRAY - 20MM AXLE - BRG TO BRG 130MM - ROTOR OD 220MM – ROTOR BC 6X ON 116MM – 36 SPOKES - FITS 90-94 KDX200, 90-96 KX125 KX250 KX500 - 2 BRG - 41034-1205 | 1996 | KX500 | FITS 90-96 KX125 KX250 KX500 - 92143-1356 - ID 20.26MM, MAJ OD 36.06MM, MINOR OD 25MM, LENGTH 19.63MM | 1996 | KX500 | FITS 88-04 KX500, 91-94 KDX250 - 12021-1070 | PAN STAMP 1531 – FITS 96 KX500 - KX GURU SAYS IT FITS 89-04 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 94-01 KX125 KX250, 94-04 KX500, 00-09 KX65 - 13156-1347 | FITS 94-04 KX500 - 13161-1203 | 1996 | KX500 | KYB - Spring thickness: 12.0MM OD - Spring Dia: 89MM - BODY DIA 53.5MM - Spring as mounted: 265MM - Upper tab: 20MM - Upper tab hole ID: 10MM - Lower Mount INTERNAL: 22.8MM – LOWER MOUNT EXTERNAL 41.7MM - Lower mount hole ID: 10MM - Eye to Eye: 450MM – FITS AT LEAST 90-04 KX500 | 1186 - FITS 90-04 KX500 - 39007-1186 | FITS 89 KX125 KX250, 89-04 KX500 - 46102-1253 | 1996 | KX500 | FITS 90-04 KX500 - 32037-1532 and 32037-1533 | WHITE – FITS 96-02 KX500 – 36001-1390-6F | WHITE – FITS 96-02 KX500 – 36001-1419-6F | 1996 | KX500 | (1 COIL STYLE) BOOK SAYS FITS 92-96 KX500 - 21003-1242 - KAWI MAN SAYS 92-04 153-230 OHMS: BLACK/WHITE TO BLACK/YELLOW - 7.9-11.9 OHMS: WHITE/RED TO BLACK/YELLOW | 1996 | KX500 | GRAY FITS 83-04 KX500 - 14031-1220 | ALUMINUM COLOR - FITS 91-02 KX500 - 32160-1170 - KAWI MAN SAYS IT FITS 89-04 | FITS 96-02 KX500 - 33001-1496-TX | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 1996 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 88-04 KX500 - GEARS FIT 90-04 KX500 | 16T - FITS 88-04 KX500 - 13127-1159 | 18T - FITS 90-04 KX500 - 13260-1100 | 1996 | KX500 | 22T - FITS 90-04 KX500 - 13260-1101 | 22T - FITS 89-04 KX500 - 13260-1020 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 88-04 KX500 - 13128-1150 | 1996 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 26T - FITS 90-04 KX500 - 13260-1102 | 1996 | KX500 | 26T - FITS 90-04 KX500 - 13260-1103 | 21T - FITS 89-04 KX500 - 13260-1021 | 19T - FITS 84-86 KL600, 87-96 KLR650, 88-04 KX500 - 13129-1575 | FITS 88-04 KX500 - 16142-1086 | 1996 | KX500 | FITS 88-89 KX250, 88-04 KX500, 88-03 KX60, 89-06 KDX200, FITS 91-94 KDX250 | 1996 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | FITS 88-89 KX250, 88-04 KX500, 89-06 KDX200 - 52014-1067 | 62 LB WITH OIL AND SPARK PLUG, NO CARBURETOR | |||||||||||
| 1997 | KX500 | JKAKXVE--VA--XXXX | KX500BE013001 | FITS 89-04 KX500 - set 14001-5258 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 89 KX125 KX250, 90-04 KX500 11011-1304 | 1997 | KX500 | 1360 - FITS 89-04 KX500 - 14073-1360 | FITS 90 KX250, 90-04 KX500 - 54011-1304 | FITS 88-91 KX250, 88-04 KX500, 88 KDX200 - 54012-1341 | KEIHIN PWK G250 FITS 96-04 KX500 - 39MM | 1997 | KX500 | FITS 89-04 KX500 - 16065-1180 | FITS 89-04 KX500 – 21119-1267 - 19 deg BTDC @ 6000 RPM | 1997 | KX500 | FITS 90-92 KX125 KX250, 90-04 KX500 - 33040-1106 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | 1997 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500, 89-93 KDX200, 91-94 KDX250 12053-1240 | BOOK SAYS IT FITS 90 KX250, 90-04 KX500 13102-1107 - IT WILL FIT 88-04 KX500 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 88-04 KX500 - 14032-1245 | FITS 89-04 KX500, 91-94 KDX250 - 13087-1138 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 1997 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | BOOK SAYS 92-04 KX500, KAWAI MAN SAYS 89-04 - 29.95 MM FLY WHEEL SIDE – 30.00 PRIMARY GEAR SIDE – 86MM STD STROKE - 13031-1340 - 9.2LB | FITS 85-04 KX500 - 8148 | FITS 89-04 KX500 – 86MM STD BORE - 11005-1564 | 1997 | KX500 | FITS 97-04 KX500, 93-96 KLX650C, 96 KLX650R, 97-07 KLX300R - 52014-1084 | FITS 89-04 KX500 - 32029-1652 | FITS 89-04 KX500 - 32029-1639 | FITS 97-04 KX500 | 20055 FITS 88-04 KX500 | 1997 | KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 3 VALVE | FITS 88-92 KX250, 89-04 KX500 - 14024-1588 | FITS 88-04 KX500 - 14024-1611 | 1997 | KX500 | F4T107 71 FITS 92-04 KX500 - 21007-1241 - 2.55lb or 41.6 oz. - 4.370" OD | FITS 92-96 KX125 KX250, 93-04 KX500, 92-94 KDX250, 95-05 KDX200, 97-05 KDX220 - 34028-1332-CE 34028-1365-CE | 1997 | KX500 | FITS 88-04 KX500, 88-96 KX125 KX250, 91 93-94 KDX250, 95-05 KDX200, 97-05 KDX220 | USD - KYB - KX94-L KX94-R - CHROME OD 46MM - C/L 37.25" - UPPER 53.8MM - LOWER 58.9MM - BRAKE CALIPER C/L 102MM - FITS 97-02 KX500 | 46MM X 58MM X 10.5 | 1997 | KX500 | WHITE - FITS 94-95, 97-03 KX125 KX250, 97-04 KX500 - LH 55020-1492-RZ - RH 55020-1554-RZ | FITS 97-04 KX500, 97-03 KX125 KX250 | FITS 97-04 KX500 - 190MM C/L TO C/L OF FORK TUBES | FITS 97-99 KX500 44039-1269 | 1997 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1997 | KX500 | FITS 93-98 KX125 & KX250, 94-04 KX500 – 41068-1342 | FITS 93-03 KX125 KX250, 94-04 KX500 - 92143-1581 - 92143-1580 | ML3 3 - FITS 94-96 KX125 & KX250, 94-03 KX500, 95-03 KDX200, 97-03 KDX220, 96 KLX650R, 97-03 KLX300R - 43041-1576 | 1997 | KX500 | NISSIN 555 - FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 - 14079-1097 | FITS 96 KX125 KX250, 96-04 KX500 - 43059-1913 | FITS 97-00 KX100, 97-99 KX125 KX250, 97-03 KX500, 97-00 KX80 46092-1191 | 1997 | KX500 | FITS 97-00 KX500 - 43015-1594 | ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 115MM - FITS KX125 AND 250 92-02 - KX500 94-04 - KLX650R 93-96 - KLX300R 97-07 | 1997 | KX500 | GREEN - FITS 94-02 KX125 KX250, 94-04 KX500 - 35004-1318-6W | F-1249 - AXLE OD 20MM - BRG TO BRG 89.5MM - ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 93-98 KX125 KX250, 94-04 KX500 - 41034-1226 | 1997 | KX500 | GREEN – FITS 97 KX500 51080-5349-6W (SHOULD FIT 88-04 KX500) | 1997 | KX500 | SET FITS 89-04 KX500 | FITS 92-04 KX500 - 13168-1497 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 89-04 1288 E-2 OR E-1, GASKET SURFACE TO NUT SURFACE .913" - 11001-1288 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 92-97 KX500 - 13064-1165 - KAWI MAN SAYS 86-04 WILL ALL WORK | 1997 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 96-02 KX125 KX250 KX500 58029-1078-6F WHITE | 800 ML = .846 QUARTS | FITS 92-04 KX500, 96-07 KX250, 96-05 KX125, 01-12 KX100 KX85, 00-12 KX65, 04-12 KX250F - 92066-1437 | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | FLAT TOP 2 RINGS BOOK SAYS 90-04 KAWI MAN SAYS 83-04 WILL WORK 13001-1327 | 575M08600 FITS 88-04 KX500 86MM STD BORE | 1997 | KX500 | 26T - FITS 88-04 KX500 - 13097-1205 | BOOK SAYS THEY FIT 97-04 KX500 - 39061-1235 39061-1236 BUT KAWI MAN SAYS THEY FIT 88-04 KX500 | WHITE 14037-1099-RZ FITS 97-04 KX500, 97-06 KDX200, 97-05 KDX220, 97-07 KLX300, 06-07 KLX250 | GREEN – FITS 97-04 KX500 – 49089-1087-6W | GREEN – FITS 97-04 KX500 – 49089-1088-6W | 1997 | KX500 | FITS 90-04 KX500, 90-92 KX125 KX250 - 41068-1299 | HYDRAULIC BRAKE | 1997 | FITS 95-96 KX125 KX250, 96-03 KX500, 96 KLX650R, 97-03 KLX300R - 43041-1577 | FITS 94-02 KX125 KX250 KX500, 95-02 KDX200, 97-02 KDX220 KLX300R, 96 KLX650R - 55020-1488-6F | FITS 95-96 KX125 KX250, 96-04 KX500, 96 KLX650R, 97-07 KLX300R - 14079-1105 | 1997 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43001-1239 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43015-1368 | 1997 | KX500 | GREEN - FITS 89-04 KX500, 88-89 KX125, 89 KX250 - 35022-1241-6W | R-1237 - GRAY - 20MM AXLE - BRG TO BRG 130MM - ROTOR OD 220MM - ROTOR BC 6X ON 116MM - 36 SPOKES - SPROCKET BC 6X ON 150MM - 97-98 KX125 & 250, 97-04 KX500 - 3 BRG - 41034-1270 | 1997 | KX500 | FITS 97-02 KX125 KX250, 97-04 KX500 92143-1905 - ID 20.3MM, MAJ OD 39.95MM, MINOR OD 24.92MM, LENGTH 19.84MM | 1997 | KX500 | FITS 88-04 KX500, 91-94 KDX250 - 12021-1070 | PAN STAMP 1531 – FITS 95 & 97 KX500 - KX GURU SAYS IT FITS 89-04 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 94-01 KX125 KX250, 94-04 KX500, 00-09 KX65 - 13156-1347 | FITS 94-04 KX500 - 13161-1203 | 1997 | KX500 | KYB - Spring thickness: 12.0MM OD - Spring Dia: 89MM - BODY DIA 53.5MM - Spring as mounted: 265MM - Upper tab: 20MM - Upper tab hole ID: 10MM - Lower Mount INTERNAL: 22.8MM – LOWER MOUNT EXTERNAL 41.7MM - Lower mount hole ID: 10MM - Eye to Eye: 450MM – FITS AT LEAST 90-04 KX500 | 1186 - FITS 90-04 KX500 - 39007-1186 | FITS 89 KX125 KX250, 89-04 KX500 - 46102-1253 | 1997 | KX500 | FITS 90-04 KX500 - 32037-1532 and 32037-1533 | WHITE – FITS 96-02 KX500 – 36001-1390-6F | WHITE – FITS 96-02 KX500 – 36001-1419-6F | 1997 | KX500 | (1 COIL STYLE) BOOK SAYS FITS 97-04 KX500 - 21003-1307 - KAWI MAN SAYS 92-04 - 153-230 OHMS: BLACK/WHITE TO BLACK/YELLOW - 7.9-11.9 OHMS: WHITE/RED TO BLACK/YELLOW | 1997 | KX500 | GRAY FITS 83-04 KX500 - 14031-1220 | ALUMINUM COLOR - FITS 91-02 KX500 - 32160-1170 - KAWI MAN SAYS IT FITS 89-04 | FITS 96-02 KX500 - 33001-1496-TX | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 1997 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 88-04 KX500 - GEARS FIT 90-04 KX500 | 16T - FITS 88-04 KX500 - 13127-1159 | 18T - FITS 90-04 KX500 - 13260-1100 | 1997 | KX500 | 22T - FITS 90-04 KX500 - 13260-1101 | 22T - FITS 89-04 KX500 - 13260-1020 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 88-04 KX500 - 13128-1150 | 1997 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 26T - FITS 90-04 KX500 - 13260-1102 | 1997 | KX500 | 26T - FITS 90-04 KX500 - 13260-1103 | 21T - FITS 89-04 KX500 - 13260-1021 | 19T - FITS 84-86 KL600, 87-96 KLR650, 88-04 KX500 - 13129-1575 | FITS 88-04 KX500 - 16142-1086 | 1997 | KX500 | FITS 88-89 KX250, 88-04 KX500, 88-03 KX60, 89-06 KDX200, FITS 91-94 KDX250 | 1997 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | FITS 88-89 KX250, 88-04 KX500, 89-06 KDX200 - 52014-1067 | 62 LB WITH OIL AND SPARK PLUG, NO CARBURETOR | ||||||||||
| 1998 | KX500 | JKAKXVE--WA--XXXX | KX500BE013001 | FITS 89-04 KX500 - set 14001-5258 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 89 KX125 KX250, 90-04 KX500 11011-1304 | 1998 | KX500 | 1360 - FITS 89-04 KX500 - 14073-1360 | FITS 90 KX250, 90-04 KX500 - 54011-1304 | FITS 88-91 KX250, 88-04 KX500, 88 KDX200 - 54012-1341 | KEIHIN PWK G250 FITS 96-04 KX500 - 39MM | 1998 | KX500 | FITS 89-04 KX500 - 16065-1180 | FITS 89-04 KX500 – 21119-1267 - 19 deg BTDC @ 6000 RPM | 1998 | KX500 | FITS 90-92 KX125 KX250, 90-04 KX500 - 33040-1106 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | 1998 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500, 89-93 KDX200, 91-94 KDX250 12053-1240 | BOOK SAYS IT FITS 90 KX250, 90-04 KX500 13102-1107 - IT WILL FIT 88-04 KX500 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 88-04 KX500 - 14032-1245 | FITS 89-04 KX500, 91-94 KDX250 - 13087-1138 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 1998 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | BOOK SAYS 92-04 KX500, KAWAI MAN SAYS 89-04 - 29.95 MM FLY WHEEL SIDE – 30.00 PRIMARY GEAR SIDE – 86MM STD STROKE - 13031-1340 - 9.2LB | FITS 85-04 KX500 - 8148 | FITS 89-04 KX500 – 86MM STD BORE - 11005-1564 | 1998 | KX500 | FITS 97-04 KX500, 93-96 KLX650C, 96 KLX650R, 97-07 KLX300R - 52014-1084 | FITS 89-04 KX500 - 32029-1652 | FITS 89-04 KX500 - 32029-1639 | FITS 97-04 KX500 | 20055 FITS 88-04 KX500 | 1998 | KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 3 VALVE | FITS 88-92 KX250, 89-04 KX500 - 14024-1588 | FITS 88-04 KX500 - 14024-1611 | 1998 | KX500 | F4T107 71 FITS 92-04 KX500 - 21007-1241 - 2.55lb or 41.6 oz. - 4.370" OD | FITS 92-96 KX125 KX250, 93-04 KX500, 92-94 KDX250, 95-05 KDX200, 97-05 KDX220 - 34028-1332-CE 34028-1365-CE | 1998 | KX500 | FITS 88-04 KX500, 88-96 KX125 KX250, 91 93-94 KDX250, 95-05 KDX200, 97-05 KDX220 | USD - KYB - KX94-L KX94-R - CHROME OD 46MM - C/L 37.25" - UPPER 53.8MM - LOWER 58.9MM - BRAKE CALIPER C/L 102MM - FITS 97-02 KX500 | 46MM X 58MM X 10.5 | 1998 | KX500 | WHITE - FITS 94-95, 97-03 KX125 KX250, 97-04 KX500 - LH 55020-1492-RZ - RH 55020-1554-RZ | FITS 97-04 KX500, 97-03 KX125 KX250 | FITS 97-04 KX500 - 190MM C/L TO C/L OF FORK TUBES | FITS 97-99 KX500 44039-1269 | 1998 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1998 | KX500 | FITS 93-98 KX125 & KX250, 94-04 KX500 – 41068-1342 | FITS 93-03 KX125 KX250, 94-04 KX500 - 92143-1581 - 92143-1580 | ML3 3 - FITS 94-96 KX125 & KX250, 94-03 KX500, 95-03 KDX200, 97-03 KDX220, 96 KLX650R, 97-03 KLX300R - 43041-1576 | 1998 | KX500 | NISSIN 555 - FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 - 14079-1097 | FITS 96 KX125 KX250, 96-04 KX500 - 43059-1913 | FITS 97-00 KX100, 97-99 KX125 KX250, 97-03 KX500, 97-00 KX80 46092-1191 | 1998 | KX500 | FITS 97-00 KX500 - 43015-1594 | ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 115MM - FITS KX125 AND 250 92-02 - KX500 94-04 - KLX650R 93-96 - KLX300R 97-07 | 1998 | KX500 | GREEN - FITS 94-02 KX125 KX250, 94-04 KX500 - 35004-1318-6W | F-1249 - AXLE OD 20MM - BRG TO BRG 89.5MM - ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 93-98 KX125 KX250, 94-04 KX500 - 41034-1226 | 1998 | KX500 | GREEN – FITS 98 KX500 51080-5428-6W (SHOULD FIT 88-04 KX500) | 1998 | KX500 | SET FITS 89-04 KX500 | FITS 92-04 KX500 - 13168-1497 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 89-04 1288 E-2 OR E-1, GASKET SURFACE TO NUT SURFACE .913" - 11001-1288 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 98-04 KX500 - 13064-1201 - KAWI MAN SAYS 86-04 WILL ALL WORK | 1998 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 96-02 KX125 KX250 KX500 58029-1078-6F WHITE | 800 ML = .846 QUARTS | FITS 92-04 KX500, 96-07 KX250, 96-05 KX125, 01-12 KX100 KX85, 00-12 KX65, 04-12 KX250F - 92066-1437 | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | FLAT TOP 2 RINGS BOOK SAYS 90-04 KAWI MAN SAYS 83-04 WILL WORK 13001-1327 | 575M08600 FITS 88-04 KX500 86MM STD BORE | 1998 | KX500 | 26T - FITS 88-04 KX500 - 13097-1205 | BOOK SAYS THEY FIT 97-04 KX500 - 39061-1235 39061-1236 BUT KAWI MAN SAYS THEY FIT 88-04 KX500 | WHITE 14037-1099-RZ FITS 97-04 KX500, 97-06 KDX200, 97-05 KDX220, 97-07 KLX300, 06-07 KLX250 | GREEN – FITS 97-04 KX500 – 49089-1087-6W | GREEN – FITS 97-04 KX500 – 49089-1088-6W | 1998 | KX500 | FITS 90-04 KX500, 90-92 KX125 KX250 - 41068-1299 | HYDRAULIC BRAKE | 1998 | FITS 95-96 KX125 KX250, 96-03 KX500, 96 KLX650R, 97-03 KLX300R - 43041-1577 | FITS 94-02 KX125 KX250 KX500, 95-02 KDX200, 97-02 KDX220 KLX300R, 96 KLX650R - 55020-1488-6F | FITS 95-96 KX125 KX250, 96-04 KX500, 96 KLX650R, 97-07 KLX300R - 14079-1105 | 1998 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43001-1239 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43015-1368 | 1998 | KX500 | GREEN - FITS 89-04 KX500, 88-89 KX125, 89 KX250 - 35022-1241-6W | R-1237 - GRAY - 20MM AXLE - BRG TO BRG 130MM - ROTOR OD 220MM - ROTOR BC 6X ON 116MM - 36 SPOKES - SPROCKET BC 6X ON 150MM - 97-98 KX125 & 250, 97-04 KX500 - 3 BRG - 41034-1270 | 1998 | KX500 | FITS 97-02 KX125 KX250, 97-04 KX500 92143-1905 - ID 20.3MM, MAJ OD 39.95MM, MINOR OD 24.92MM, LENGTH 19.84MM | 1998 | KX500 | FITS 88-04 KX500, 91-94 KDX250 - 12021-1070 | PAN STAMP 1531 – FITS 98-00 KX500 - KX GURU SAYS IT FITS 89-04 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 94-01 KX125 KX250, 94-04 KX500, 00-09 KX65 - 13156-1347 | FITS 94-04 KX500 - 13161-1203 | 1998 | KX500 | KYB - Spring thickness: 12.0MM OD - Spring Dia: 89MM - BODY DIA 53.5MM - Spring as mounted: 265MM - Upper tab: 20MM - Upper tab hole ID: 10MM - Lower Mount INTERNAL: 22.8MM – LOWER MOUNT EXTERNAL 41.7MM - Lower mount hole ID: 10MM - Eye to Eye: 450MM – FITS AT LEAST 90-04 KX500 | 1186 - FITS 90-04 KX500 - 39007-1186 | FITS 89 KX125 KX250, 89-04 KX500 - 46102-1253 | 1998 | KX500 | FITS 90-04 KX500 - 32037-1532 and 32037-1533 | WHITE – FITS 96-02 KX500 – 36001-1390-6F | WHITE – FITS 96-02 KX500 – 36001-1419-6F | 1998 | KX500 | (1 COIL STYLE) BOOK SAYS FITS 97-04 KX500 - 21003-1307 - KAWI MAN SAYS 92-04 - 153-230 OHMS: BLACK/WHITE TO BLACK/YELLOW - 7.9-11.9 OHMS: WHITE/RED TO BLACK/YELLOW | 1998 | KX500 | GRAY FITS 83-04 KX500 - 14031-1220 | ALUMINUM COLOR - FITS 91-02 KX500 - 32160-1170 - KAWI MAN SAYS IT FITS 89-04 | FITS 96-02 KX500 - 33001-1496-TX | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 1998 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 88-04 KX500 - GEARS FIT 90-04 KX500 | 16T - FITS 88-04 KX500 - 13127-1159 | 18T - FITS 90-04 KX500 - 13260-1100 | 1998 | KX500 | 22T - FITS 90-04 KX500 - 13260-1101 | 22T - FITS 89-04 KX500 - 13260-1020 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 88-04 KX500 - 13128-1150 | 1998 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 26T - FITS 90-04 KX500 - 13260-1102 | 1998 | KX500 | 26T - FITS 90-04 KX500 - 13260-1103 | 21T - FITS 89-04 KX500 - 13260-1021 | 19T - FITS 84-86 KL600, 87-96 KLR650, 88-04 KX500 - 13129-1575 | FITS 88-04 KX500 - 16142-1086 | 1998 | KX500 | FITS 88-89 KX250, 88-04 KX500, 88-03 KX60, 89-06 KDX200, FITS 91-94 KDX250 | 1998 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | FITS 88-89 KX250, 88-04 KX500, 89-06 KDX200 - 52014-1067 | 62 LB WITH OIL AND SPARK PLUG, NO CARBURETOR | ||||||||||
| 1999 | KX500 | JKAKXVE--XA--XXXX | KX500BE013001 | FITS 89-04 KX500 - set 14001-5258 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 89 KX125 KX250, 90-04 KX500 11011-1304 | 1999 | KX500 | 1360 - FITS 89-04 KX500 - 14073-1360 | FITS 90 KX250, 90-04 KX500 - 54011-1304 | FITS 88-91 KX250, 88-04 KX500, 88 KDX200 - 54012-1341 | KEIHIN PWK G250 FITS 96-04 KX500 - 39MM | 1999 | KX500 | FITS 89-04 KX500 - 16065-1180 | FITS 89-04 KX500 – 21119-1267 - 19 deg BTDC @ 6000 RPM | 1999 | KX500 | FITS 90-92 KX125 KX250, 90-04 KX500 - 33040-1106 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | 1999 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500, 89-93 KDX200, 91-94 KDX250 12053-1240 | BOOK SAYS IT FITS 90 KX250, 90-04 KX500 13102-1107 - IT WILL FIT 88-04 KX500 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 88-04 KX500 - 14032-1245 | FITS 89-04 KX500, 91-94 KDX250 - 13087-1138 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 1999 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | BOOK SAYS 92-04 KX500, KAWAI MAN SAYS 89-04 - 29.95 MM FLY WHEEL SIDE – 30.00 PRIMARY GEAR SIDE – 86MM STD STROKE - 13031-1340 - 9.2LB | FITS 85-04 KX500 - 8148 | FITS 89-04 KX500 – 86MM STD BORE - 11005-1564 | 1999 | KX500 | FITS 97-04 KX500, 93-96 KLX650C, 96 KLX650R, 97-07 KLX300R - 52014-1084 | FITS 89-04 KX500 - 32029-1652 | FITS 89-04 KX500 - 32029-1639 | FITS 97-04 KX500 | 20055 FITS 88-04 KX500 | 1999 | KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 3 VALVE | FITS 88-92 KX250, 89-04 KX500 - 14024-1588 | FITS 88-04 KX500 - 14024-1611 | 1999 | KX500 | F4T107 71 FITS 92-04 KX500 - 21007-1241 - 2.55lb or 41.6 oz. - 4.370" OD | FITS 92-96 KX125 KX250, 93-04 KX500, 92-94 KDX250, 95-05 KDX200, 97-05 KDX220 - 34028-1332-CE 34028-1365-CE | 1999 | KX500 | FITS 88-04 KX500, 88-96 KX125 KX250, 91 93-94 KDX250, 95-05 KDX200, 97-05 KDX220 | USD - KYB - KX94-L KX94-R - CHROME OD 46MM - C/L 37.25" - UPPER 53.8MM - LOWER 58.9MM - BRAKE CALIPER C/L 102MM - FITS 97-02 KX500 | 46MM X 58MM X 10.5 | 1999 | KX500 | WHITE - FITS 94-95, 97-03 KX125 KX250, 97-04 KX500 - LH 55020-1492-RZ - RH 55020-1554-RZ | FITS 97-04 KX500, 97-03 KX125 KX250 | FITS 97-04 KX500 - 190MM C/L TO C/L OF FORK TUBES | FITS 97-99 KX500 44039-1269 | 1999 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 1999 | KX500 | FITS 93-98 KX125 & KX250, 94-04 KX500 – 41068-1342 | FITS 93-03 KX125 KX250, 94-04 KX500 - 92143-1581 - 92143-1580 | ML3 3 - FITS 94-96 KX125 & KX250, 94-03 KX500, 95-03 KDX200, 97-03 KDX220, 96 KLX650R, 97-03 KLX300R - 43041-1576 | 1999 | KX500 | NISSIN 555 - FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 - 14079-1097 | FITS 96 KX125 KX250, 96-04 KX500 - 43059-1913 | FITS 97-00 KX100, 97-99 KX125 KX250, 97-03 KX500, 97-00 KX80 46092-1191 | 1999 | KX500 | FITS 97-00 KX500 - 43015-1594 | ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 115MM - FITS KX125 AND 250 92-02 - KX500 94-04 - KLX650R 93-96 - KLX300R 97-07 | 1999 | KX500 | GREEN - FITS 94-02 KX125 KX250, 94-04 KX500 - 35004-1318-6W | F-1249 - AXLE OD 20MM - BRG TO BRG 89.5MM - ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 93-98 KX125 KX250, 94-04 KX500 - 41034-1226 | 1999 | KX500 | GREEN – FITS 99 KX500 51081-5070-6W (SHOULD FIT 88-04 KX500) | 1999 | KX500 | SET FITS 89-04 KX500 | FITS 92-04 KX500 - 13168-1497 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 89-04 1288 E-2 OR E-1, GASKET SURFACE TO NUT SURFACE .913" - 11001-1288 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 98-04 KX500 - 13064-1201 - KAWI MAN SAYS 86-04 WILL ALL WORK | 1999 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 96-02 KX125 KX250 KX500 58029-1078-6F WHITE | 800 ML = .846 QUARTS | FITS 92-04 KX500, 96-07 KX250, 96-05 KX125, 01-12 KX100 KX85, 00-12 KX65, 04-12 KX250F - 92066-1437 | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | FLAT TOP 2 RINGS BOOK SAYS 90-04 KAWI MAN SAYS 83-04 WILL WORK 13001-1327 | 575M08600 FITS 88-04 KX500 86MM STD BORE | 1999 | KX500 | 26T - FITS 88-04 KX500 - 13097-1205 | BOOK SAYS THEY FIT 97-04 KX500 - 39061-1235 39061-1236 BUT KAWI MAN SAYS THEY FIT 88-04 KX500 | WHITE 14037-1099-RZ FITS 97-04 KX500, 97-06 KDX200, 97-05 KDX220, 97-07 KLX300, 06-07 KLX250 | GREEN – FITS 97-04 KX500 – 49089-1087-6W | GREEN – FITS 97-04 KX500 – 49089-1088-6W | 1999 | KX500 | FITS 90-04 KX500, 90-92 KX125 KX250 - 41068-1299 | HYDRAULIC BRAKE | 1999 | FITS 95-96 KX125 KX250, 96-03 KX500, 96 KLX650R, 97-03 KLX300R - 43041-1577 | FITS 94-02 KX125 KX250 KX500, 95-02 KDX200, 97-02 KDX220 KLX300R, 96 KLX650R - 55020-1488-6F | FITS 95-96 KX125 KX250, 96-04 KX500, 96 KLX650R, 97-07 KLX300R - 14079-1105 | 1999 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43001-1239 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43015-1368 | 1999 | KX500 | GREEN - FITS 89-04 KX500, 88-89 KX125, 89 KX250 - 35022-1241-6W | R-1237 - GRAY - 20MM AXLE - BRG TO BRG 130MM - ROTOR OD 220MM - ROTOR BC 6X ON 116MM - 36 SPOKES - SPROCKET BC 6X ON 150MM - 97-98 KX125 & 250, 97-04 KX500 - 3 BRG - 41034-1270 | 1999 | KX500 | FITS 97-02 KX125 KX250, 97-04 KX500 92143-1905 - ID 20.3MM, MAJ OD 39.95MM, MINOR OD 24.92MM, LENGTH 19.84MM | 1999 | KX500 | FITS 88-04 KX500, 91-94 KDX250 - 12021-1070 | PAN STAMP 1531 – FITS 98-00 KX500 - KX GURU SAYS IT FITS 89-04 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 94-01 KX125 KX250, 94-04 KX500, 00-09 KX65 - 13156-1347 | FITS 94-04 KX500 - 13161-1203 | 1999 | KX500 | KYB - Spring thickness: 12.0MM OD - Spring Dia: 89MM - BODY DIA 53.5MM - Spring as mounted: 265MM - Upper tab: 20MM - Upper tab hole ID: 10MM - Lower Mount INTERNAL: 22.8MM – LOWER MOUNT EXTERNAL 41.7MM - Lower mount hole ID: 10MM - Eye to Eye: 450MM – FITS AT LEAST 90-04 KX500 | 1186 - FITS 90-04 KX500 - 39007-1186 | FITS 89 KX125 KX250, 89-04 KX500 - 46102-1253 | 1999 | KX500 | FITS 90-04 KX500 - 32037-1532 and 32037-1533 | WHITE – FITS 96-02 KX500 – 36001-1390-6F | WHITE – FITS 96-02 KX500 – 36001-1419-6F | 1999 | KX500 | (1 COIL STYLE) BOOK SAYS FITS 97-04 KX500 - 21003-1307 - KAWI MAN SAYS 92-04 - 153-230 OHMS: BLACK/WHITE TO BLACK/YELLOW - 7.9-11.9 OHMS: WHITE/RED TO BLACK/YELLOW | 1999 | KX500 | GRAY FITS 83-04 KX500 - 14031-1220 | ALUMINUM COLOR - FITS 91-02 KX500 - 32160-1170 - KAWI MAN SAYS IT FITS 89-04 | FITS 96-02 KX500 - 33001-1496-TX | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 1999 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 88-04 KX500 - GEARS FIT 90-04 KX500 | 16T - FITS 88-04 KX500 - 13127-1159 | 18T - FITS 90-04 KX500 - 13260-1100 | 1999 | KX500 | 22T - FITS 90-04 KX500 - 13260-1101 | 22T - FITS 89-04 KX500 - 13260-1020 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 88-04 KX500 - 13128-1150 | 1999 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 26T - FITS 90-04 KX500 - 13260-1102 | 1999 | KX500 | 26T - FITS 90-04 KX500 - 13260-1103 | 21T - FITS 89-04 KX500 - 13260-1021 | 19T - FITS 84-86 KL600, 87-96 KLR650, 88-04 KX500 - 13129-1575 | FITS 88-04 KX500 - 16142-1086 | 1999 | KX500 | FITS 88-89 KX250, 88-04 KX500, 88-03 KX60, 89-06 KDX200, FITS 91-94 KDX250 | 1999 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | FITS 88-89 KX250, 88-04 KX500, 89-06 KDX200 - 52014-1067 | 62 LB WITH OIL AND SPARK PLUG, NO CARBURETOR | ||||||||||
| 2000 | KX500 | JKAKXVEC7YA02XXXX | KX500BE013001 | FITS 89-04 KX500 - set 14001-5258 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 89 KX125 KX250, 90-04 KX500 11011-1304 | 2000 | KX500 | 1360 - FITS 89-04 KX500 - 14073-1360 | FITS 90 KX250, 90-04 KX500 - 54011-1304 | FITS 88-91 KX250, 88-04 KX500, 88 KDX200 - 54012-1341 | KEIHIN PWK G250 FITS 96-04 KX500 - 39MM | 2000 | KX500 | FITS 89-04 KX500 - 16065-1180 | FITS 89-04 KX500 – 21119-1267 - 19 deg BTDC @ 6000 RPM | 2000 | KX500 | FITS 90-92 KX125 KX250, 90-04 KX500 - 33040-1106 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | 2000 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500, 89-93 KDX200, 91-94 KDX250 12053-1240 | BOOK SAYS IT FITS 90 KX250, 90-04 KX500 13102-1107 - IT WILL FIT 88-04 KX500 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 88-04 KX500 - 14032-1245 | FITS 89-04 KX500, 91-94 KDX250 - 13087-1138 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 2000 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | BOOK SAYS 92-04 KX500, KAWAI MAN SAYS 89-04 - 29.95 MM FLY WHEEL SIDE – 30.00 PRIMARY GEAR SIDE – 86MM STD STROKE - 13031-1340 - 9.2LB | FITS 85-04 KX500 - 8148 | FITS 89-04 KX500 – 86MM STD BORE - 11005-1564 | 2000 | KX500 | FITS 97-04 KX500, 93-96 KLX650C, 96 KLX650R, 97-07 KLX300R - 52014-1084 | FITS 89-04 KX500 - 32029-1652 | FITS 89-04 KX500 - 32029-1639 | FITS 97-04 KX500 | 20055 FITS 88-04 KX500 | 2000 | KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 3 VALVE | FITS 88-92 KX250, 89-04 KX500 - 14024-1588 | FITS 88-04 KX500 - 14024-1611 | 2000 | KX500 | F4T107 71 FITS 92-04 KX500 - 21007-1241 - 2.55lb or 41.6 oz. - 4.370" OD | FITS 92-96 KX125 KX250, 93-04 KX500, 92-94 KDX250, 95-05 KDX200, 97-05 KDX220 - 34028-1332-CE 34028-1365-CE | 2000 | KX500 | FITS 88-04 KX500, 88-96 KX125 KX250, 91 93-94 KDX250, 95-05 KDX200, 97-05 KDX220 | USD - KYB - KX94-L KX94-R - CHROME OD 46MM - C/L 37.25" - UPPER 53.8MM - LOWER 58.9MM - BRAKE CALIPER C/L 102MM - FITS 97-02 KX500 | 46MM X 58MM X 10.5 | 2000 | KX500 | WHITE - FITS 94-95, 97-03 KX125 KX250, 97-04 KX500 - LH 55020-1492-RZ - RH 55020-1554-RZ | FITS 97-04 KX500, 97-03 KX125 KX250 | FITS 97-04 KX500 - 190MM C/L TO C/L OF FORK TUBES | FITS 00-04 KX500 44039-1295 | 2000 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 2000 | KX500 | FITS 93-98 KX125 & KX250, 94-04 KX500 – 41068-1342 | FITS 93-03 KX125 KX250, 94-04 KX500 - 92143-1581 - 92143-1580 | ML3 3 - FITS 94-96 KX125 & KX250, 94-03 KX500, 95-03 KDX200, 97-03 KDX220, 96 KLX650R, 97-03 KLX300R - 43041-1576 | 2000 | KX500 | NISSIN 555 - FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 - 14079-1097 | FITS 96 KX125 KX250, 96-04 KX500 - 43059-1913 | FITS 97-00 KX100, 97-99 KX125 KX250, 97-03 KX500, 97-00 KX80 46092-1191 | 2000 | KX500 | FITS 97-00 KX500 - 43015-1594 | ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 115MM - FITS KX125 AND 250 92-02 - KX500 94-04 - KLX650R 93-96 - KLX300R 97-07 | 2000 | KX500 | GREEN - FITS 94-02 KX125 KX250, 94-04 KX500 - 35004-1318-6W | F-1249 - AXLE OD 20MM - BRG TO BRG 89.5MM - ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 93-98 KX125 KX250, 94-04 KX500 - 41034-1226 | 2000 | KX500 | GREEN – FITS 00 KX500 51081-5199-6W (SHOULD FIT 88-04 KX500) | 2000 | KX500 | SET FITS 89-04 KX500 | FITS 92-04 KX500 - 13168-1497 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 89-04 1288 E-2 OR E-1, GASKET SURFACE TO NUT SURFACE .913" - 11001-1288 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 98-04 KX500 - 13064-1201 - KAWI MAN SAYS 86-04 WILL ALL WORK | 2000 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 96-02 KX125 KX250 KX500 58029-1078-6F WHITE | 800 ML = .846 QUARTS | FITS 92-04 KX500, 96-07 KX250, 96-05 KX125, 01-12 KX100 KX85, 00-12 KX65, 04-12 KX250F - 92066-1437 | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | FLAT TOP 2 RINGS BOOK SAYS 90-04 KAWI MAN SAYS 83-04 WILL WORK 13001-1327 | 575M08600 FITS 88-04 KX500 86MM STD BORE | 2000 | KX500 | 26T - FITS 88-04 KX500 - 13097-1205 | BOOK SAYS THEY FIT 97-04 KX500 - 39061-1235 39061-1236 BUT KAWI MAN SAYS THEY FIT 88-04 KX500 | WHITE 14037-1099-RZ FITS 97-04 KX500, 97-06 KDX200, 97-05 KDX220, 97-07 KLX300, 06-07 KLX250 | GREEN – FITS 97-04 KX500 – 49089-1087-6W | GREEN – FITS 97-04 KX500 – 49089-1088-6W | 2000 | KX500 | FITS 90-04 KX500, 90-92 KX125 KX250 - 41068-1299 | HYDRAULIC BRAKE | 2000 | FITS 95-96 KX125 KX250, 96-03 KX500, 96 KLX650R, 97-03 KLX300R - 43041-1577 | FITS 94-02 KX125 KX250 KX500, 95-02 KDX200, 97-02 KDX220 KLX300R, 96 KLX650R - 55020-1488-6F | FITS 95-96 KX125 KX250, 96-04 KX500, 96 KLX650R, 97-07 KLX300R - 14079-1105 | 2000 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43001-1239 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43015-1368 | 2000 | KX500 | GREEN - FITS 89-04 KX500, 88-89 KX125, 89 KX250 - 35022-1241-6W | R-1237 - GRAY - 20MM AXLE - BRG TO BRG 130MM - ROTOR OD 220MM - ROTOR BC 6X ON 116MM - 36 SPOKES - SPROCKET BC 6X ON 150MM - 97-98 KX125 & 250, 97-04 KX500 - 3 BRG - 41034-1270 | 2000 | KX500 | FITS 97-02 KX125 KX250, 97-04 KX500 92143-1905 - ID 20.3MM, MAJ OD 39.95MM, MINOR OD 24.92MM, LENGTH 19.84MM | 2000 | KX500 | FITS 88-04 KX500, 91-94 KDX250 - 12021-1070 | PAN STAMP 1531 – FITS 98-00 KX500 - KX GURU SAYS IT FITS 89-04 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 94-01 KX125 KX250, 94-04 KX500, 00-09 KX65 - 13156-1347 | FITS 94-04 KX500 - 13161-1203 | 2000 | KX500 | KYB - Spring thickness: 12.0MM OD - Spring Dia: 89MM - BODY DIA 53.5MM - Spring as mounted: 265MM - Upper tab: 20MM - Upper tab hole ID: 10MM - Lower Mount INTERNAL: 22.8MM – LOWER MOUNT EXTERNAL 41.7MM - Lower mount hole ID: 10MM - Eye to Eye: 450MM – FITS AT LEAST 90-04 KX500 | 1186 - FITS 90-04 KX500 - 39007-1186 | FITS 89 KX125 KX250, 89-04 KX500 - 46102-1253 | 2000 | KX500 | FITS 90-04 KX500 - 32037-1532 and 32037-1533 | WHITE – FITS 96-02 KX500 – 36001-1390-6F | WHITE – FITS 96-02 KX500 – 36001-1419-6F | 2000 | KX500 | (1 COIL STYLE) BOOK SAYS FITS 97-04 KX500 - 21003-1307 - KAWI MAN SAYS 92-04 - 153-230 OHMS: BLACK/WHITE TO BLACK/YELLOW - 7.9-11.9 OHMS: WHITE/RED TO BLACK/YELLOW | 2000 | KX500 | GRAY FITS 83-04 KX500 - 14031-1220 | ALUMINUM COLOR - FITS 91-02 KX500 - 32160-1170 - KAWI MAN SAYS IT FITS 89-04 | FITS 96-02 KX500 - 33001-1496-TX | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 2000 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 88-04 KX500 - GEARS FIT 90-04 KX500 | 16T - FITS 88-04 KX500 - 13127-1159 | 18T - FITS 90-04 KX500 - 13260-1100 | 2000 | KX500 | 22T - FITS 90-04 KX500 - 13260-1101 | 22T - FITS 89-04 KX500 - 13260-1020 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 88-04 KX500 - 13128-1150 | 2000 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 26T - FITS 90-04 KX500 - 13260-1102 | 2000 | KX500 | 26T - FITS 90-04 KX500 - 13260-1103 | 21T - FITS 89-04 KX500 - 13260-1021 | 19T - FITS 84-86 KL600, 87-96 KLR650, 88-04 KX500 - 13129-1575 | FITS 88-04 KX500 - 16142-1086 | 2000 | KX500 | FITS 88-89 KX250, 88-04 KX500, 88-03 KX60, 89-06 KDX200, FITS 91-94 KDX250 | 2000 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | FITS 88-89 KX250, 88-04 KX500, 89-06 KDX200 - 52014-1067 | 62 LB WITH OIL AND SPARK PLUG, NO CARBURETOR | ||||||||||
| 2001 | KX500 | JKAKXMLC91A02XXXX | KX500BE013001 | FITS 89-04 KX500 - set 14001-5258 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 89 KX125 KX250, 90-04 KX500 11011-1304 | 2001 | KX500 | 1360 - FITS 89-04 KX500 - 14073-1360 | FITS 90 KX250, 90-04 KX500 - 54011-1304 | FITS 88-91 KX250, 88-04 KX500, 88 KDX200 - 54012-1341 | KEIHIN PWK G250 FITS 96-04 KX500 - 39MM | 2001 | KX500 | FITS 89-04 KX500 - 16065-1180 | FITS 89-04 KX500 – 21119-1267 - 19 deg BTDC @ 6000 RPM | 2001 | KX500 | FITS 90-92 KX125 KX250, 90-04 KX500 - 33040-1106 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | 2001 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500, 89-93 KDX200, 91-94 KDX250 12053-1240 | BOOK SAYS IT FITS 90 KX250, 90-04 KX500 13102-1107 - IT WILL FIT 88-04 KX500 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 88-04 KX500 - 14032-1245 | FITS 89-04 KX500, 91-94 KDX250 - 13087-1138 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 2001 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | BOOK SAYS 92-04 KX500, KAWAI MAN SAYS 89-04 - 29.95 MM FLY WHEEL SIDE – 30.00 PRIMARY GEAR SIDE – 86MM STD STROKE - 13031-1340 - 9.2LB | FITS 85-04 KX500 - 8148 | FITS 89-04 KX500 – 86MM STD BORE - 11005-1564 | 2001 | KX500 | FITS 97-04 KX500, 93-96 KLX650C, 96 KLX650R, 97-07 KLX300R - 52014-1084 | FITS 89-04 KX500 - 32029-1652 | FITS 89-04 KX500 - 32029-1639 | FITS 97-04 KX500 | 20055 FITS 88-04 KX500 | 2001 | KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 3 VALVE | FITS 88-92 KX250, 89-04 KX500 - 14024-1588 | FITS 88-04 KX500 - 14024-1611 | 2001 | KX500 | F4T107 71 FITS 92-04 KX500 - 21007-1241 - 2.55lb or 41.6 oz. - 4.370" OD | FITS 92-96 KX125 KX250, 93-04 KX500, 92-94 KDX250, 95-05 KDX200, 97-05 KDX220 - 34028-1332-CE 34028-1365-CE | 2001 | KX500 | FITS 88-04 KX500, 88-96 KX125 KX250, 91 93-94 KDX250, 95-05 KDX200, 97-05 KDX220 | USD - KYB - KX94-L KX94-R - CHROME OD 46MM - C/L 37.25" - UPPER 53.8MM - LOWER 58.9MM - BRAKE CALIPER C/L 102MM - FITS 97-02 KX500 | 46MM X 58MM X 10.5 | 2001 | KX500 | WHITE - FITS 94-95, 97-03 KX125 KX250, 97-04 KX500 - LH 55020-1492-RZ - RH 55020-1554-RZ | FITS 97-04 KX500, 97-03 KX125 KX250 | FITS 97-04 KX500 - 190MM C/L TO C/L OF FORK TUBES | FITS 00-04 KX500 44039-1295 | 2001 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 2001 | KX500 | FITS 93-98 KX125 & KX250, 94-04 KX500 – 41068-1342 | FITS 93-03 KX125 KX250, 94-04 KX500 - 92143-1581 - 92143-1580 | ML3 3 - FITS 94-96 KX125 & KX250, 94-03 KX500, 95-03 KDX200, 97-03 KDX220, 96 KLX650R, 97-03 KLX300R - 43041-1576 | 2001 | KX500 | NISSIN 555 - FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 - 14079-1097 | FITS 96 KX125 KX250, 96-04 KX500 - 43059-1913 | FITS 97-00 KX100, 97-99 KX125 KX250, 97-03 KX500, 97-00 KX80 46092-1191 | 2001 | KX500 | FITS 01-03 KX500 - 43015-1657 | ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 115MM - FITS KX125 AND 250 92-02 - KX500 94-04 - KLX650R 93-96 - KLX300R 97-07 | 2001 | KX500 | GREEN - FITS 94-02 KX125 KX250, 94-04 KX500 - 35004-1318-6W | F-1249 - AXLE OD 20MM - BRG TO BRG 89.5MM - ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 93-98 KX125 KX250, 94-04 KX500 - 41034-1226 | 2001 | KX500 | GREEN – FITS 01 KX500 51081-5379-6W (SHOULD FIT 88-04 KX500) | 2001 | KX500 | SET FITS 89-04 KX500 | FITS 92-04 KX500 - 13168-1497 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 89-04 1288 E-2 OR E-1, GASKET SURFACE TO NUT SURFACE .913" - 11001-1288 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 98-04 KX500 - 13064-1201 - KAWI MAN SAYS 86-04 WILL ALL WORK | 2001 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 96-02 KX125 KX250 KX500 58029-1078-6F WHITE | 800 ML = .846 QUARTS | FITS 92-04 KX500, 96-07 KX250, 96-05 KX125, 01-12 KX100 KX85, 00-12 KX65, 04-12 KX250F - 92066-1437 | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | FLAT TOP 2 RINGS BOOK SAYS 90-04 KAWI MAN SAYS 83-04 WILL WORK 13001-1327 | 575M08600 FITS 88-04 KX500 86MM STD BORE | 2001 | KX500 | 26T - FITS 88-04 KX500 - 13097-1205 | BOOK SAYS THEY FIT 97-04 KX500 - 39061-1235 39061-1236 BUT KAWI MAN SAYS THEY FIT 88-04 KX500 | WHITE 14037-1099-RZ FITS 97-04 KX500, 97-06 KDX200, 97-05 KDX220, 97-07 KLX300, 06-07 KLX250 | GREEN – FITS 97-04 KX500 – 49089-1087-6W | GREEN – FITS 97-04 KX500 – 49089-1088-6W | 2001 | KX500 | FITS 90-04 KX500, 90-92 KX125 KX250 - 41068-1299 | HYDRAULIC BRAKE | 2001 | FITS 95-96 KX125 KX250, 96-03 KX500, 96 KLX650R, 97-03 KLX300R - 43041-1577 | FITS 94-02 KX125 KX250 KX500, 95-02 KDX200, 97-02 KDX220 KLX300R, 96 KLX650R - 55020-1488-6F | FITS 95-96 KX125 KX250, 96-04 KX500, 96 KLX650R, 97-07 KLX300R - 14079-1105 | 2001 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43001-1239 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43015-1368 | 2001 | KX500 | GREEN - FITS 89-04 KX500, 88-89 KX125, 89 KX250 - 35022-1241-6W | R-1237 - GRAY - 20MM AXLE - BRG TO BRG 130MM - ROTOR OD 220MM - ROTOR BC 6X ON 116MM - 36 SPOKES - SPROCKET BC 6X ON 150MM - 97-98 KX125 & 250, 97-04 KX500 - 3 BRG - 41034-1270 | 2001 | KX500 | FITS 97-02 KX125 KX250, 97-04 KX500 92143-1905 - ID 20.3MM, MAJ OD 39.95MM, MINOR OD 24.92MM, LENGTH 19.84MM | 2001 | KX500 | FITS 88-04 KX500, 91-94 KDX250 - 12021-1070 | PAN STAMP 1531 – FITS 01-02 KX500 - KX GURU SAYS IT FITS 89-04 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 94-01 KX125 KX250, 94-04 KX500, 00-09 KX65 - 13156-1347 | FITS 94-04 KX500 - 13161-1203 | 2001 | KX500 | KYB - Spring thickness: 12.0MM OD - Spring Dia: 89MM - BODY DIA 53.5MM - Spring as mounted: 265MM - Upper tab: 20MM - Upper tab hole ID: 10MM - Lower Mount INTERNAL: 22.8MM – LOWER MOUNT EXTERNAL 41.7MM - Lower mount hole ID: 10MM - Eye to Eye: 450MM – FITS AT LEAST 90-04 KX500 | 1186 - FITS 90-04 KX500 - 39007-1186 | FITS 89 KX125 KX250, 89-04 KX500 - 46102-1253 | 2001 | KX500 | FITS 90-04 KX500 - 32037-1532 and 32037-1533 | WHITE – FITS 96-02 KX500 – 36001-1390-6F | WHITE – FITS 96-02 KX500 – 36001-1419-6F | 2001 | KX500 | (1 COIL STYLE) BOOK SAYS FITS 97-04 KX500 - 21003-1307 - KAWI MAN SAYS 92-04 - 153-230 OHMS: BLACK/WHITE TO BLACK/YELLOW - 7.9-11.9 OHMS: WHITE/RED TO BLACK/YELLOW | 2001 | KX500 | GRAY FITS 83-04 KX500 - 14031-1220 | ALUMINUM COLOR - FITS 91-02 KX500 - 32160-1170 - KAWI MAN SAYS IT FITS 89-04 | FITS 96-02 KX500 - 33001-1496-TX | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 2001 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 88-04 KX500 - GEARS FIT 90-04 KX500 | 16T - FITS 88-04 KX500 - 13127-1159 | 18T - FITS 90-04 KX500 - 13260-1100 | 2001 | KX500 | 22T - FITS 90-04 KX500 - 13260-1101 | 22T - FITS 89-04 KX500 - 13260-1020 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 88-04 KX500 - 13128-1150 | 2001 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 26T - FITS 90-04 KX500 - 13260-1102 | 2001 | KX500 | 26T - FITS 90-04 KX500 - 13260-1103 | 21T - FITS 89-04 KX500 - 13260-1021 | 19T - FITS 84-86 KL600, 87-96 KLR650, 88-04 KX500 - 13129-1575 | FITS 88-04 KX500 - 16142-1086 | 2001 | KX500 | FITS 88-89 KX250, 88-04 KX500, 88-03 KX60, 89-06 KDX200, FITS 91-94 KDX250 | 2001 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | FITS 88-89 KX250, 88-04 KX500, 89-06 KDX200 - 52014-1067 | 62 LB WITH OIL AND SPARK PLUG, NO CARBURETOR | ||||||||||
| 2002 | KX500 | JKAKX----2----XXXX | KX500BE013001 | FITS 89-04 KX500 - set 14001-5258 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 89 KX125 KX250, 90-04 KX500 11011-1304 | 2002 | KX500 | 1360 - FITS 89-04 KX500 - 14073-1360 | FITS 90 KX250, 90-04 KX500 - 54011-1304 | FITS 88-91 KX250, 88-04 KX500, 88 KDX200 - 54012-1341 | KEIHIN PWK G250 FITS 96-04 KX500 - 39MM | 2002 | KX500 | FITS 89-04 KX500 - 16065-1180 | FITS 89-04 KX500 – 21119-1267 - 19 deg BTDC @ 6000 RPM | 2002 | KX500 | FITS 90-92 KX125 KX250, 90-04 KX500 - 33040-1106 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | 2002 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500, 89-93 KDX200, 91-94 KDX250 12053-1240 | BOOK SAYS IT FITS 90 KX250, 90-04 KX500 13102-1107 - IT WILL FIT 88-04 KX500 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 88-04 KX500 - 14032-1245 | FITS 89-04 KX500, 91-94 KDX250 - 13087-1138 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 2002 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | BOOK SAYS 92-04 KX500, KAWAI MAN SAYS 89-04 - 29.95 MM FLY WHEEL SIDE – 30.00 PRIMARY GEAR SIDE – 86MM STD STROKE - 13031-1340 - 9.2LB | FITS 85-04 KX500 - 8148 | FITS 89-04 KX500 – 86MM STD BORE - 11005-1564 | 2002 | KX500 | FITS 97-04 KX500, 93-96 KLX650C, 96 KLX650R, 97-07 KLX300R - 52014-1084 | FITS 89-04 KX500 - 32029-1652 | FITS 89-04 KX500 - 32029-1639 | FITS 97-04 KX500 | 20055 FITS 88-04 KX500 | 2002 | KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 3 VALVE | FITS 88-92 KX250, 89-04 KX500 - 14024-1588 | FITS 88-04 KX500 - 14024-1611 | 2002 | KX500 | F4T107 71 FITS 92-04 KX500 - 21007-1241 - 2.55lb or 41.6 oz. - 4.370" OD | FITS 92-96 KX125 KX250, 93-04 KX500, 92-94 KDX250, 95-05 KDX200, 97-05 KDX220 - 34028-1332-CE 34028-1365-CE | 2002 | KX500 | FITS 88-04 KX500, 88-96 KX125 KX250, 91 93-94 KDX250, 95-05 KDX200, 97-05 KDX220 | USD - KYB - KX94-L KX94-R - CHROME OD 46MM - C/L 37.25" - UPPER 53.8MM - LOWER 58.9MM - BRAKE CALIPER C/L 102MM - FITS 97-02 KX500 | 46MM X 58MM X 10.5 | 2002 | KX500 | WHITE - FITS 94-95, 97-03 KX125 KX250, 97-04 KX500 - LH 55020-1492-RZ - RH 55020-1554-RZ | FITS 97-04 KX500, 97-03 KX125 KX250 | FITS 97-04 KX500 - 190MM C/L TO C/L OF FORK TUBES | FITS 00-04 KX500 44039-1295 | 2002 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 2002 | KX500 | FITS 93-98 KX125 & KX250, 94-04 KX500 – 41068-1342 | FITS 93-03 KX125 KX250, 94-04 KX500 - 92143-1581 - 92143-1580 | ML3 3 - FITS 94-96 KX125 & KX250, 94-03 KX500, 95-03 KDX200, 97-03 KDX220, 96 KLX650R, 97-03 KLX300R - 43041-1576 | 2002 | KX500 | NISSIN 555 - FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 - 14079-1097 | FITS 96 KX125 KX250, 96-04 KX500 - 43059-1913 | FITS 97-00 KX100, 97-99 KX125 KX250, 97-03 KX500, 97-00 KX80 46092-1191 | 2002 | KX500 | FITS 01-03 KX500 - 43015-1657 | ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 115MM - FITS KX125 AND 250 92-02 - KX500 94-04 - KLX650R 93-96 - KLX300R 97-07 | 2002 | KX500 | GREEN - FITS 94-02 KX125 KX250, 94-04 KX500 - 35004-1318-6W | F-1249 - AXLE OD 20MM - BRG TO BRG 89.5MM - ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 93-98 KX125 KX250, 94-04 KX500 - 41034-1226 | 2002 | KX500 | GREEN – FITS 02 KX500 51082-5067-6W (SHOULD FIT 88-04 KX500) | 2002 | KX500 | SET FITS 89-04 KX500 | FITS 92-04 KX500 - 13168-1497 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 89-04 1288 E-2 OR E-1, GASKET SURFACE TO NUT SURFACE .913" - 11001-1288 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 98-04 KX500 - 13064-1201 - KAWI MAN SAYS 86-04 WILL ALL WORK | 2002 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 96-02 KX125 KX250 KX500 58029-1078-6F WHITE | 800 ML = .846 QUARTS | FITS 92-04 KX500, 96-07 KX250, 96-05 KX125, 01-12 KX100 KX85, 00-12 KX65, 04-12 KX250F - 92066-1437 | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | FLAT TOP 2 RINGS BOOK SAYS 90-04 KAWI MAN SAYS 83-04 WILL WORK 13001-1327 | 575M08600 FITS 88-04 KX500 86MM STD BORE | 2002 | KX500 | 26T - FITS 88-04 KX500 - 13097-1205 | BOOK SAYS THEY FIT 97-04 KX500 - 39061-1235 39061-1236 BUT KAWI MAN SAYS THEY FIT 88-04 KX500 | WHITE 14037-1099-RZ FITS 97-04 KX500, 97-06 KDX200, 97-05 KDX220, 97-07 KLX300, 06-07 KLX250 | GREEN – FITS 97-04 KX500 – 49089-1087-6W | GREEN – FITS 97-04 KX500 – 49089-1088-6W | 2002 | KX500 | FITS 90-04 KX500, 90-92 KX125 KX250 - 41068-1299 | HYDRAULIC BRAKE | 2002 | FITS 95-96 KX125 KX250, 96-03 KX500, 96 KLX650R, 97-03 KLX300R - 43041-1577 | FITS 94-02 KX125 KX250 KX500, 95-02 KDX200, 97-02 KDX220 KLX300R, 96 KLX650R - 55020-1488-6F | FITS 95-96 KX125 KX250, 96-04 KX500, 96 KLX650R, 97-07 KLX300R - 14079-1105 | 2002 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43001-1239 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43015-1368 | 2002 | KX500 | GREEN - FITS 89-04 KX500, 88-89 KX125, 89 KX250 - 35022-1241-6W | R-1237 - GRAY - 20MM AXLE - BRG TO BRG 130MM - ROTOR OD 220MM - ROTOR BC 6X ON 116MM - 36 SPOKES - SPROCKET BC 6X ON 150MM - 97-98 KX125 & 250, 97-04 KX500 - 3 BRG - 41034-1270 | 2002 | KX500 | FITS 97-02 KX125 KX250, 97-04 KX500 92143-1905 - ID 20.3MM, MAJ OD 39.95MM, MINOR OD 24.92MM, LENGTH 19.84MM | 2002 | KX500 | FITS 88-04 KX500, 91-94 KDX250 - 12021-1070 | PAN STAMP 1531 – FITS 01-02 KX500 - KX GURU SAYS IT FITS 89-04 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 94-01 KX125 KX250, 94-04 KX500, 00-09 KX65 - 13156-1347 | FITS 94-04 KX500 - 13161-1203 | 2002 | KX500 | KYB - Spring thickness: 12.0MM OD - Spring Dia: 89MM - BODY DIA 53.5MM - Spring as mounted: 265MM - Upper tab: 20MM - Upper tab hole ID: 10MM - Lower Mount INTERNAL: 22.8MM – LOWER MOUNT EXTERNAL 41.7MM - Lower mount hole ID: 10MM - Eye to Eye: 450MM – FITS AT LEAST 90-04 KX500 | 1186 - FITS 90-04 KX500 - 39007-1186 | FITS 89 KX125 KX250, 89-04 KX500 - 46102-1253 | 2002 | KX500 | FITS 90-04 KX500 - 32037-1532 and 32037-1533 | WHITE – FITS 96-02 KX500 – 36001-1390-6F | WHITE – FITS 96-02 KX500 – 36001-1419-6F | 2002 | KX500 | (1 COIL STYLE) BOOK SAYS FITS 97-04 KX500 - 21003-1307 - KAWI MAN SAYS 92-04 - 153-230 OHMS: BLACK/WHITE TO BLACK/YELLOW - 7.9-11.9 OHMS: WHITE/RED TO BLACK/YELLOW | 2002 | KX500 | GRAY FITS 83-04 KX500 - 14031-1220 | ALUMINUM COLOR - FITS 91-02 KX500 - 32160-1170 - KAWI MAN SAYS IT FITS 89-04 | FITS 96-02 KX500 - 33001-1496-TX | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 2002 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 88-04 KX500 - GEARS FIT 90-04 KX500 | 16T - FITS 88-04 KX500 - 13127-1159 | 18T - FITS 90-04 KX500 - 13260-1100 | 2002 | KX500 | 22T - FITS 90-04 KX500 - 13260-1101 | 22T - FITS 89-04 KX500 - 13260-1020 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 88-04 KX500 - 13128-1150 | 2002 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 26T - FITS 90-04 KX500 - 13260-1102 | 2002 | KX500 | 26T - FITS 90-04 KX500 - 13260-1103 | 21T - FITS 89-04 KX500 - 13260-1021 | 19T - FITS 84-86 KL600, 87-96 KLR650, 88-04 KX500 - 13129-1575 | FITS 88-04 KX500 - 16142-1086 | 2002 | KX500 | FITS 88-89 KX250, 88-04 KX500, 88-03 KX60, 89-06 KDX200, FITS 91-94 KDX250 | 2002 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | FITS 88-89 KX250, 88-04 KX500, 89-06 KDX200 - 52014-1067 | 62 LB WITH OIL AND SPARK PLUG, NO CARBURETOR | ||||||||||
| 2003 | KX500 | JKAKXVECO3AO3XXXX | KX500BE013001 | FITS 89-04 KX500 - set 14001-5258 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 89 KX125 KX250, 90-04 KX500 11011-1304 | 2003 | KX500 | 1360 - FITS 89-04 KX500 - 14073-1360 | FITS 90 KX250, 90-04 KX500 - 54011-1304 | FITS 88-91 KX250, 88-04 KX500, 88 KDX200 - 54012-1341 | KEIHIN PWK G250 FITS 96-04 KX500 - 39MM | 2003 | KX500 | FITS 89-04 KX500 - 16065-1180 | FITS 89-04 KX500 – 21119-1267 - 19 deg BTDC @ 6000 RPM | 2003 | KX500 | FITS 90-92 KX125 KX250, 90-04 KX500 - 33040-1106 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | 2003 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500, 89-93 KDX200, 91-94 KDX250 12053-1240 | BOOK SAYS IT FITS 90 KX250, 90-04 KX500 13102-1107 - IT WILL FIT 88-04 KX500 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 88-04 KX500 - 14032-1245 | FITS 89-04 KX500, 91-94 KDX250 - 13087-1138 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 2003 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | BOOK SAYS 92-04 KX500, KAWAI MAN SAYS 89-04 - 29.95 MM FLY WHEEL SIDE – 30.00 PRIMARY GEAR SIDE – 86MM STD STROKE - 13031-1340 - 9.2LB | FITS 85-04 KX500 - 8148 | FITS 89-04 KX500 – 86MM STD BORE - 11005-1564 | 2003 | KX500 | FITS 97-04 KX500, 93-96 KLX650C, 96 KLX650R, 97-07 KLX300R - 52014-1084 | FITS 89-04 KX500 - 32029-1652 | FITS 89-04 KX500 - 32029-1639 | FITS 97-04 KX500 | 20055 FITS 88-04 KX500 | 2003 | KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 3 VALVE | FITS 88-92 KX250, 89-04 KX500 - 14024-1588 | FITS 88-04 KX500 - 14024-1611 | 2003 | KX500 | F4T107 71 FITS 92-04 KX500 - 21007-1241 - 2.55lb or 41.6 oz. - 4.370" OD | FITS 92-96 KX125 KX250, 93-04 KX500, 92-94 KDX250, 95-05 KDX200, 97-05 KDX220 - 34028-1332-CE 34028-1365-CE | 2003 | KX500 | FITS 88-04 KX500, 88-96 KX125 KX250, 91 93-94 KDX250, 95-05 KDX200, 97-05 KDX220 | CHROME OD 46MM C/L 37.25" - UPPER 53.8MM - LOWER 58.9MM - BRAKE CALIPER C/L 102MM - FITS 03-04 KX500 | 46MM X 58MM X 10.5 | 2003 | KX500 | WHITE - FITS 94-95, 97-03 KX125 KX250, 97-04 KX500 - LH 55020-1492-RZ - RH 55020-1554-RZ | FITS 97-04 KX500, 97-03 KX125 KX250 | FITS 97-04 KX500 - 190MM C/L TO C/L OF FORK TUBES | FITS 00-04 KX500 44039-1295 | 2003 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 2003 | KX500 | FITS 93-98 KX125 & KX250, 94-04 KX500 – 41068-1342 | FITS 93-03 KX125 KX250, 94-04 KX500 - 92143-1581 - 92143-1580 | ML3 3 - FITS 94-96 KX125 & KX250, 94-03 KX500, 95-03 KDX200, 97-03 KDX220, 96 KLX650R, 97-03 KLX300R - 43041-1576 | 2003 | KX500 | NISSIN 555 - FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 - 14079-1097 | FITS 96 KX125 KX250, 96-04 KX500 - 43059-1913 | FITS 97-00 KX100, 97-99 KX125 KX250, 97-03 KX500, 97-00 KX80 46092-1191 | 2003 | KX500 | FITS 01-03 KX500 - 43015-1657 | ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 115MM - FITS KX125 AND 250 92-02 - KX500 94-04 - KLX650R 93-96 - KLX300R 97-07 | 2003 | KX500 | GREEN - FITS 94-02 KX125 KX250, 94-04 KX500 - 35004-1318-6W | F-1249 - AXLE OD 20MM - BRG TO BRG 89.5MM - ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 93-98 KX125 KX250, 94-04 KX500 - 41034-1226 | 2003 | KX500 | BLACK – FITS 03 KX500 51082-5386-6Z (SHOULD FIT 88-04 KX500) | 2003 | KX500 | SET FITS 89-04 KX500 | FITS 92-04 KX500 - 13168-1497 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 89-04 1288 E-2 OR E-1, GASKET SURFACE TO NUT SURFACE .913" - 11001-1288 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 98-04 KX500 - 13064-1201 - KAWI MAN SAYS 86-04 WILL ALL WORK | 2003 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 03-04 KX500 58029-1078-266 WHITE | 800 ML = .846 QUARTS | FITS 92-04 KX500, 96-07 KX250, 96-05 KX125, 01-12 KX100 KX85, 00-12 KX65, 04-12 KX250F - 92066-1437 | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | FLAT TOP 2 RINGS BOOK SAYS 90-04 KAWI MAN SAYS 83-04 WILL WORK 13001-1327 | 575M08600 FITS 88-04 KX500 86MM STD BORE | 2003 | KX500 | 26T - FITS 88-04 KX500 - 13097-1205 | BOOK SAYS THEY FIT 97-04 KX500 - 39061-1235 39061-1236 BUT KAWI MAN SAYS THEY FIT 88-04 KX500 | WHITE 14037-1099-RZ FITS 97-04 KX500, 97-06 KDX200, 97-05 KDX220, 97-07 KLX300, 06-07 KLX250 | GREEN – FITS 97-04 KX500 – 49089-1087-6W | GREEN – FITS 97-04 KX500 – 49089-1088-6W | 2003 | KX500 | FITS 90-04 KX500, 90-92 KX125 KX250 - 41068-1299 | HYDRAULIC BRAKE | 2003 | FITS 95-96 KX125 KX250, 96-03 KX500, 96 KLX650R, 97-03 KLX300R - 43041-1577 | FITS 95-96 KX125 KX250, 96-04 KX500, 96 KLX650R, 97-07 KLX300R - 14079-1105 | 2003 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43001-1239 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43015-1368 | 2003 | KX500 | GREEN - FITS 89-04 KX500, 88-89 KX125, 89 KX250 - 35022-1241-6W | R-1237 - GRAY - 20MM AXLE - BRG TO BRG 130MM - ROTOR OD 220MM - ROTOR BC 6X ON 116MM - 36 SPOKES - SPROCKET BC 6X ON 150MM - 97-98 KX125 & 250, 97-04 KX500 - 3 BRG - 41034-1270 | 2003 | KX500 | FITS 97-02 KX125 KX250, 97-04 KX500 92143-1905 - ID 20.3MM, MAJ OD 39.95MM, MINOR OD 24.92MM, LENGTH 19.84MM | 2003 | KX500 | FITS 88-04 KX500, 91-94 KDX250 - 12021-1070 | PAN STAMP 1531 – FITS 03-04 KX500 - KX GURU SAYS IT FITS 89-04 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 94-01 KX125 KX250, 94-04 KX500, 00-09 KX65 - 13156-1347 | FITS 94-04 KX500 - 13161-1203 | 2003 | KX500 | KYB - Spring thickness: 12.0MM OD - Spring Dia: 89MM - BODY DIA 53.5MM - Spring as mounted: 265MM - Upper tab: 20MM - Upper tab hole ID: 10MM - Lower Mount INTERNAL: 22.8MM – LOWER MOUNT EXTERNAL 41.7MM - Lower mount hole ID: 10MM - Eye to Eye: 450MM – FITS AT LEAST 90-04 KX500 | 1186 - FITS 90-04 KX500 - 39007-1186 | FITS 89 KX125 KX250, 89-04 KX500 - 46102-1253 | 2003 | KX500 | FITS 90-04 KX500 - 32037-1532 and 32037-1533 | WHITE – FITS 03-04 KX500 - 36001-1390-266 | WHITE – FITS 03-04 KX500 – 36001-1419-266 | 2003 | KX500 | (1 COIL STYLE) BOOK SAYS FITS 97-04 KX500 - 21003-1307 - KAWI MAN SAYS 92-04 - 153-230 OHMS: BLACK/WHITE TO BLACK/YELLOW - 7.9-11.9 OHMS: WHITE/RED TO BLACK/YELLOW | 2003 | KX500 | GRAY FITS 83-04 KX500 - 14031-1220 | GRAY - FITS 03-04 KX500 - 32160-1807-GD - KAWAI MAN SAYS IT FITS 89-04 | FITS 03-04 KX500 - 33001-1496-CE | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 2003 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 88-04 KX500 - GEARS FIT 90-04 KX500 | 16T - FITS 88-04 KX500 - 13127-1159 | 18T - FITS 90-04 KX500 - 13260-1100 | 2003 | KX500 | 22T - FITS 90-04 KX500 - 13260-1101 | 22T - FITS 89-04 KX500 - 13260-1020 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 88-04 KX500 - 13128-1150 | 2003 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 26T - FITS 90-04 KX500 - 13260-1102 | 2003 | KX500 | 26T - FITS 90-04 KX500 - 13260-1103 | 21T - FITS 89-04 KX500 - 13260-1021 | 19T - FITS 84-86 KL600, 87-96 KLR650, 88-04 KX500 - 13129-1575 | FITS 88-04 KX500 - 16142-1086 | 2003 | KX500 | FITS 88-89 KX250, 88-04 KX500, 88-03 KX60, 89-06 KDX200, FITS 91-94 KDX250 | 2003 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | FITS 88-89 KX250, 88-04 KX500, 89-06 KDX200 - 52014-1067 | 62 LB WITH OIL AND SPARK PLUG, NO CARBURETOR | |||||||||||
| 2004 | KX500 | JKAKX----4----XXXX | KX500BE013001 | FITS 89-04 KX500 - set 14001-5258 | FITS 87- 89 KX125 KX250, 87-04 KX500, 89-06 KDX200, 97-05 KDX220, 91-94 KDX250, 93-96 KLX650, 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S - 13091-1454 | FITS 89 KX125 KX250, 90-04 KX500 11011-1304 | 2004 | KX500 | 1360 - FITS 89-04 KX500 - 14073-1360 | FITS 90 KX250, 90-04 KX500 - 54011-1304 | FITS 88-91 KX250, 88-04 KX500, 88 KDX200 - 54012-1341 | KEIHIN PWK G250 FITS 96-04 KX500 - 39MM | 2004 | KX500 | FITS 89-04 KX500 - 16065-1180 | FITS 89-04 KX500 – 21119-1267 - 19 deg BTDC @ 6000 RPM | 2004 | KX500 | FITS 90-92 KX125 KX250, 90-04 KX500 - 33040-1106 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | 2004 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500, 89-93 KDX200, 91-94 KDX250 12053-1240 | BOOK SAYS IT FITS 90 KX250, 90-04 KX500 13102-1107 - IT WILL FIT 88-04 KX500 | 17T & 66T - FITS 87-04 KX500 - 13095-1196 | FITS 88-04 KX500 - 14032-1245 | FITS 89-04 KX500, 91-94 KDX250 - 13087-1138 - 6 bolt posts | FITS 87-91 kx250, 87-04 kx500, 91-94 kdx250, 87-88 KXF250 - 13187-1060 | 2004 | KX500 | F6T536 FITS 83-04 KX500 - 21121-1186 - 2.6-3.6 K ohms | BOOK SAYS 92-04 KX500, KAWAI MAN SAYS 89-04 - 29.95 MM FLY WHEEL SIDE – 30.00 PRIMARY GEAR SIDE – 86MM STD STROKE - 13031-1340 - 9.2LB | FITS 85-04 KX500 - 8148 | FITS 89-04 KX500 – 86MM STD BORE - 11005-1564 | 2004 | KX500 | FITS 97-04 KX500, 93-96 KLX650C, 96 KLX650R, 97-07 KLX300R - 52014-1084 | FITS 89-04 KX500 - 32029-1652 | FITS 89-04 KX500 - 32029-1639 | FITS 97-04 KX500 | 20055 FITS 88-04 KX500 | 2004 | KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 | FITS 89-04 KX500 3 VALVE | FITS 88-92 KX250, 89-04 KX500 - 14024-1588 | FITS 88-04 KX500 - 14024-1611 | 2004 | KX500 | F4T107 71 FITS 92-04 KX500 - 21007-1241 - 2.55lb or 41.6 oz. - 4.370" OD | FITS 92-96 KX125 KX250, 93-04 KX500, 92-94 KDX250, 95-05 KDX200, 97-05 KDX220 - 34028-1332-CE 34028-1365-CE | 2004 | KX500 | FITS 88-04 KX500, 88-96 KX125 KX250, 91 93-94 KDX250, 95-05 KDX200, 97-05 KDX220 | CHROME OD 46MM C/L 37.25" - UPPER 53.8MM - LOWER 58.9MM - BRAKE CALIPER C/L 102MM - FITS 03-04 KX500 | 46MM X 58MM X 10.5 | 2004 | KX500 | WHITE - FITS 94-95, 97-03 KX125 KX250, 97-04 KX500 - LH 55020-1492-RZ - RH 55020-1554-RZ | FITS 97-04 KX500, 97-03 KX125 KX250 | FITS 97-04 KX500 - 190MM C/L TO C/L OF FORK TUBES | FITS 00-04 KX500 44039-1295 | 2004 | KX500 | FITS 74-76 78-91 KX250, 80-81 KX420, 83-04 KX500, 83-94 KDX200, 81-84 KDX250, 84-87 KXT250 - 92116-1008 | FITS 84-87 KXT250, 74-76 78-91 KX125 KX250, 83-04 KX500, 75-76 KX400, 80-81 KX420, 78-84 KL250, 80-84 91-94 KDX250, 83-06 KDX200, 97-05 KDX200, 79-80 94-96 06-10 KLX250, 93-96 KLX650R & C - 92047-017 | 2004 | KX500 | FITS 93-98 KX125 & KX250, 94-04 KX500 – 41068-1342 | FITS 93-03 KX125 KX250, 94-04 KX500 - 92143-1581 - 92143-1580 | 2004 | KX500 | NISSIN 555 - FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 - 14079-1097 | FITS 96 KX125 KX250, 96-04 KX500 - 43059-1913 | FITS 00-05, 00-04 KX250, 04 KX500, 00-05 08-11 KX65, 01-05 08-09 11 KX100, 01-05 08-11 KX85, 04-11 KX250F, 06-11 KX450F - 13236-1346 | 2004 | KX500 | NISSIN 304 - FITS 01-05 08-09 KX85 KX100, 01-05 KX125, 00-04 KX250, 04 KX500, 04-09 KX250F, 06-09 KX450F - 43015-1674 | 2004 | KX500 | GREEN - FITS 94-02 KX125 KX250, 94-04 KX500 - 35004-1318-6W | F-1249 - AXLE OD 20MM - BRG TO BRG 89.5MM - ROTOR OD 250MM ID 100.5MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 93-98 KX125 KX250, 94-04 KX500 - 41034-1226 | 2004 | KX500 | BLACK – FITS 04 KX500 51083-5077-6Z (SHOULD FIT 88-04 KX500) | 2004 | KX500 | SET FITS 89-04 KX500 | FITS 92-04 KX500 - 13168-1497 | FITS 86-04 KX500, 87-92 KX250, 88-05 KX125, 88-06 KDX200, 97-05 KDX220 - 49114-1058 | FITS 85-04 KX500 - 59051-1129 | FITS 87-04 KX500 - 49111-1052 | FITS 89-04 1288 E-2 OR E-1, GASKET SURFACE TO NUT SURFACE .913" - 11001-1288 | 26T - FITS 86-04 KX500 - 59051-1150 - CLICKI HERE FOR MEASURMENTS | FITS 98-04 KX500 - 13064-1201 - KAWI MAN SAYS 86-04 WILL ALL WORK | 2004 | KX500 | FITS 85-04 KX500 - 13066-1056 | FITS 86-89 KX125, 87-89 KX250, 87-04 KX500, 89-94 KDX200 - 35019-1159 | FITS 03-04 KX500 58029-1078-266 WHITE | 800 ML = .846 QUARTS | FITS 92-04 KX500, 96-07 KX250, 96-05 KX125, 01-12 KX100 KX85, 00-12 KX65, 04-12 KX250F - 92066-1437 | FITS 74-91 KX125 KX250, 83-04 KX500 - 51023-1115 | FLAT TOP 2 RINGS BOOK SAYS 90-04 KAWI MAN SAYS 83-04 WILL WORK 13001-1327 | 575M08600 FITS 88-04 KX500 86MM STD BORE | 2004 | KX500 | 26T - FITS 88-04 KX500 - 13097-1205 | BOOK SAYS THEY FIT 97-04 KX500 - 39061-1235 39061-1236 BUT KAWI MAN SAYS THEY FIT 88-04 KX500 | WHITE 14037-1099-RZ FITS 97-04 KX500, 97-06 KDX200, 97-05 KDX220, 97-07 KLX300, 06-07 KLX250 | GREEN – FITS 97-04 KX500 – 49089-1087-6W | GREEN – FITS 97-04 KX500 – 49089-1088-6W | 2004 | KX500 | FITS 90-04 KX500, 90-92 KX125 KX250 - 41068-1299 | HYDRAULIC BRAKE | 2004 | FITS 04-07 KLR300R, 4 KX500, 06-07 KLX250S | FITS 95-96 KX125 KX250, 96-04 KX500, 96 KLX650R, 97-07 KLX300R - 14079-1105 | 2004 | KX500 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43001-1239 | FITS 88-89 KX125 KX250, 88-04 KX500 - 43015-1368 | 2004 | KX500 | GREEN - FITS 89-04 KX500, 88-89 KX125, 89 KX250 - 35022-1241-6W | R-1237 - GRAY - 20MM AXLE - BRG TO BRG 130MM - ROTOR OD 220MM - ROTOR BC 6X ON 116MM - 36 SPOKES - SPROCKET BC 6X ON 150MM - 97-98 KX125 & 250, 97-04 KX500 - 3 BRG - 41034-1270 | 2004 | KX500 | FITS 97-02 KX125 KX250, 97-04 KX500 92143-1905 - ID 20.3MM, MAJ OD 39.95MM, MINOR OD 24.92MM, LENGTH 19.84MM | 2004 | KX500 | FITS 88-04 KX500, 91-94 KDX250 - 12021-1070 | PAN STAMP 1531 – FITS 03-04 KX500 - KX GURU SAYS IT FITS 89-04 KX500 | FITS 87-04 KX500 - 13239-1143 | FITS 86-04 KX500 - 13140-1058, 13140-1059, 13140-1142 | FITS 94-01 KX125 KX250, 94-04 KX500, 00-09 KX65 - 13156-1347 | FITS 94-04 KX500 - 13161-1203 | 2004 | KX500 | 1186 - FITS 90-04 KX500 - 39007-1186 | FITS 89 KX125 KX250, 89-04 KX500 - 46102-1253 | 2004 | KX500 | FITS 90-04 KX500 - 32037-1532 and 32037-1533 | WHITE – FITS 03-04 KX500 - 36001-1390-266 | WHITE – FITS 03-04 KX500 – 36001-1419-266 | 2004 | KX500 | (1 COIL STYLE) BOOK SAYS FITS 97-04 KX500 - 21003-1307 - KAWI MAN SAYS 92-04 - 153-230 OHMS: BLACK/WHITE TO BLACK/YELLOW - 7.9-11.9 OHMS: WHITE/RED TO BLACK/YELLOW | 2004 | KX500 | GRAY FITS 83-04 KX500 - 14031-1220 | GRAY - FITS 03-04 KX500 - 32160-1807-GD - KAWAI MAN SAYS IT FITS 89-04 | FITS 03-04 KX500 - 33001-1496-CE | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 2004 | KX500 | FITS 82-91 KX125, 83-91 KX250, 83-04 KX500 - 46019-1054 14025-1646 32099-1044 32099-1036 | SHAFTS FIT 88-04 KX500 - GEARS FIT 90-04 KX500 | 16T - FITS 88-04 KX500 - 13127-1159 | 18T - FITS 90-04 KX500 - 13260-1100 | 2004 | KX500 | 22T - FITS 90-04 KX500 - 13260-1101 | 22T - FITS 89-04 KX500 - 13260-1020 | 24T - FITS 86-04 KX500 - 13129-1744 | FITS 88-04 KX500 - 13128-1150 | 2004 | KX500 | 32T - FITS 80-81 KX420, 83-04 KX500 - 13129-1180 | 26T - FITS 90-04 KX500 - 13260-1102 | 2004 | KX500 | 26T - FITS 90-04 KX500 - 13260-1103 | 21T - FITS 89-04 KX500 - 13260-1021 | 19T - FITS 84-86 KL600, 87-96 KLR650, 88-04 KX500 - 13129-1575 | FITS 88-04 KX500 - 16142-1086 | 2004 | KX500 | FITS 88-89 KX250, 88-04 KX500, 88-03 KX60, 89-06 KDX200, FITS 91-94 KDX250 | 2004 | KX500 | FITS 91-05 KX125, 92-04 KX250, 87-04 KX500, 04-11 KX250F - 59256-1065 | FITS 88-89 KX250, 88-04 KX500, 89-06 KDX200 - 52014-1067 | 62 LB WITH OIL AND SPARK PLUG, NO CARBURETOR | ||||||||||||||
| YEAR | TYPE | VIN FRAME USA | ENGINE ID | ENGINE CASES | AIR BOX CAGE ELEMENT HOLDER | AIR BOX NO BOOT (DUCT) | YEAR | TYPE | AIR BOX BOOT JOINT DUCT | CABLE CLUTCH | CABLE THROTTLE | CARBURETOR | YEAR | TYPE | CARBURETOR FLOAT VALVE | CARBURETOR BOOT | CDI | YEAR | TYPE | CHAIN ADJUSTER BLOCKS | CHAIN GUIDE | YEAR | TYPE | CHAIN SLIDE | CLUTCH ARM | CLUTCH BASKET | CLUTCH FRICTION PLATES | CLUTCH COVER | CLUTCH HUB (INNER) | CLUTCH PRESSURE PLATE (OUTER) | YEAR | TYPE | COIL | COUNTER SPROCKET GUARD PLASTIC | CRANK SHAFT | CRANK SHAFT ROD KIT HOT RODS | CYLINDER | YEAR | TYPE | CYLINDER WATER NECK ELBOW | ENGINE MOUNTS FRONT | ENGINE MOUNTS UPPER | EXHAUST PIPE | EXHAUST PIPE FMF GNARLY | YEAR | TYPE | EXHAUST PIPE PRO CIRCUIT PLATINUM | EXHAUST PIPE PRO CIRCUIT PLATINUM 2 | EXHAUST PIPE PRO CIRCUIT WORKS | EXHAUST VALVE | EXHAUST VALVE COVER FRONT | EXHAUST VALVE COVER RIGHT | YEAR | TYPE | FLY WHEEL | FOOT PEGS | YEAR | TYPE | FOOT PEG SPRINGS | FORK | FORK SEAL SIZES | YEAR | TYPE | FORK GUARDS | FORK GUARD MOUNTS | FORK UNDER HOLDER (STEERING STEM LOWER CLAMP) TRIPLE TREE | FORK UPPER HOLDER (TOP CLAMP) TRIPLE TREE | YEAR | TYPE | FORK HOLDER BEARINGS (LOWER) | FORK HOLDER BEARINGS (UPPER) | YEAR | TYPE | FRONT AXLE | FRONT AXLE HOLDER | FRONT AXLE SPACERS COLLARS | FRONT BRAKE CALIPER | YEAR | TYPE | FRONT BRAKE CALIPER MOUNT | FRONT BRAKE HOSE | FRONT BRAKE LEVER | YEAR | TYPE | FRONT BRAKE MASTER CYLINDER | FRONT BRAKE ROTOR | YEAR | TYPE | FRONT BRAKE ROTOR GUARD | FRONT FENDER | FRONT HUB | YEAR | TYPE | FUEL/GAS TANK | GAS TANK CAP | YEAR | TYPE | GOVERNOR | GOVERNOR LEVER | GOVERNOR SHAFT | GOVERNOR WATER PUMP SPUR GEAR | GOVERNOR WEIGHT HOLDER | HEAD | KICK IDLER GEAR | KICK LEVER | YEAR | TYPE | KICK LEVER SHAFT | MUD FLAP | NUMBER PLATE | OIL CAPACITY | OIL DRAIN PLUG | PETCOCK FUEL VALVE TAP | PISTON | WISECO STD PISTON | YEAR | TYPE | PRIMARY CRANK GEAR | RADIATORS | RADIATOR SCREENS | RADIATOR SHROUDS | RADIATOR SHROUD RIGHT | YEAR | TYPE | REAR AXLE | REAR BRAKE BACKING PLATE | YEAR | REAR BRAKE CALIPER | REAR BRAKE CALIPER GUARD | REAR BRAKE CALIPER GUARD | REAR BRAKE CALIPER MOUNT | REAR BRAKE HOSE | YEAR | TYPE | REAR BRAKE ROTOR | REAR BRAKE LEVER | REAR BRAKE MASTER CYLINDER | YEAR | TYPE | REAR FENDER | REAR HUB | YEAR | TYPE | REAR WHEEL SPACERS | YEAR | TYPE | REED VALVE | SEAT | SHIFT DRUM | SHIFT FORKS | SHIFT LEVER | SHIFT SHAFT | YEAR | TYPE | SHOCK | SHOCK ARM LINKAGE UNI TRAK | SHOCK ARM SUSPENSION RODS (DOG BONES) | YEAR | TYPE | SHOCK BRACKETS | SIDE COVER LEFT | SIDE COVER RIGHT | YEAR | TYPE | STATOR | YEAR | TYPE | STATOR COVER | SUB FRAME | SWING ARM | SWING ARM PIVOT PIN | YEAR | TYPE | THROTTLE ASY | TRANSMISSION | TRANSMISSION INPUT SHAFT | TRANSMISSION INPUT 2ND GEAR | YEAR | TYPE | TRANSMISSION INPUT 3RD GEAR | TRANSMISSION INPUT 4TH GEAR | TRANSMISSION INPUT 5TH GEAR | TRANSMISSION OUTPUT SHAFT | TRANSMISSION OUTPUT SHAFT NUT | YEAR | TYPE | TRANSMISSION OUTPUT 1ST GEAR | TRANSMISSION OUTPUT 2ND GEAR | YEAR | TYPE | TRANSMISSION OUTPUT 3RD GEAR | TRANSMISSION OUTPUT 4TH GEAR | TRANSMISSION OUTPUT 5TH GEAR | WATER PUMP COVER | YEAR | TYPE | WATER PUMP COVER NECK | YEAR | TYPE | WATER PUMP IMPELLER | WATER PUMP NECK ELBOW | KX500 ENGINE WEIGHT |
