Kawasaki KLX ENGINE, PARTS, AND FRAME
Identification page
In an effort to help fellow bikers properly ID their bike
I have provided the following information on VIN ( Vehicle Identification
Number ) , Engine ID and part identification.
All the information provided is to the best of my knowledge correct.
As we part more bikes out we will add more information to this chart.
If you find something that is not accurate, please let us know and we will
fix it.
This information is not intended for use outside of this web site or for
publication.
In other words, use this information at your own risk.
Scroll to the right as there is a lot of data :-)
| YEAR | TYPE | VIN FRAME USA ONLY | ENGINE ID | ENGINE CASES | AIR BOX | YEAR | TYPE | CAM SHAFT EXHAUST | CAM SHAFT INTAKE | CARBURETOR | YEAR | TYPE | CDI | CHAIN GUIDE | CHAIN SLIDE | YEAR | TYPE | CLUTCH BASKET | COIL | YEAR | TYPE | CONDENSOR | CRANK SHAFT | CYLINDER | EXHAUST HEADER | EXHAUST MUFFLER | FLY WHEEL ROTOR | YEAR | TYPE | FOOT PEGS PASSENGER | FOOT PEG PASSENGER MOUNTS | YEAR | TYPE | FORK | FORK GUARDS | YEAR | TYPE | FORK GUARD MOUNTS | FRONT AXLE | FRONT BRAKE CALIPER | YEAR | TYPE | FRONT BRAKE CALIPER MOUNT | FRONT BRAKE LEVER | FRONT BRAKE MASTER CYLINDER | YEAR | TYPE | FRONT BRAKE ROTOR | FRONT HUB | HEAD | HEAD LIGHT BODY | KICK IDLER GEAR | YEAR | TYPE | KICK LEVER | KICK LEVER SHAFT | YEAR | TYPE | LEFT CONTROL SWITCH | ONE WAY CLUTCH GEAR | PISTON | PRIMARY CRANK GEAR | RADIATOR LEFT | RADIATOR RIGHT | REAR AXLE | YEAR | TYPE | RADIATOR SHROUDS | REAR HUB | YEAR | TYPE | REAR BRAKE CALIPER | REAR BRAKE HOSE | YEAR | TYPE | REAR BRAKE MASTER CYLINDER | REAR BRAKE ROTOR | REAR WHEEL SPACERS | YEAR | TYPE | SHOCK | SIDE STAND | YEAR | TYPE | STATOR | SWING ARM | SWING ARM PIN / AXLE | YEAR | TYPE | TIMING CHAIN TENSIONER | YEAR | TYPE | TRANSMISSION | YEAR | TYPE | TRANSMISSION OUT PUT SHAFT | TRIPLE TREE BOTTOM | YEAR | TYPE | TRIPLE TREE TOP | VOLTAGE REGULATOR | WIRE HARNESS | WATER PUMP IMPELLER | YEAR | TYPE |
| 1993 | KLX250R | 1993 | KLX250R | 1993 | KLX250R | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 1993 | KLX250R | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 1993 | KLX250R | 1993 | KLX250R | 1993 | KLX250R | 1993 | KLX250R | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | 1993 | KLX250R | 1993 | KLX250R | 1993 | KLX250R | FITS 93-05 KLR250, 94-96 KLX250R, 97-07 KLX300R - 13066-1088 | 1993 | KLX250R | 22T - FITS 93-96 KLX250R, 97-07 KLX300R - 13097-1296 | 1993 | KLX250R | 1993 | KLX250R | 1993 | KLX250R | 1993 | KLX250R | 1993 | KLX250R | 1993 | KLX250R | 1993 | KLX250R | 1993 | KLX250R | 1993 | KLX250R | 1993 | KLX250R | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 1994 | KLX250R | 1994 | KLX250R | FITS 94-96 KLX250R, 97-07 KLX300R, 06--12 KLX250S - 12044-1327 | KEIHIN CVK G188 32.5MM | 1994 | KLX250R | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 1994 | KLX250R | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 1994 | KLX250R | 1994 | KLX250R | 1994 | KLX250R | FITS 93-94 KDX200 KDX250, 93-95 KLX650R, 93-96 KLX650C, 94-96 KLX250R, 97-03 KLX300R, LH 55020-1363-RZ, RH 55020-1423-RZ | 1994 | KLX250R | FITS 93-94 KDX200 KDX250, 93-95 KLX650R KLX250R, RH 13070-1264, LH 13070-1263 | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | 1994 | KLX250R | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | FITS 93-95 KLX650R, 94-95 KLX250R, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 1994 | KLX250R | OD: 9 7/8" - ID 4" - 4 HOLES ON A 4 9/16" BC - FITS KX125 AND 250 92-02 - KX500 94-04 - KLX650R 93-96 - KLX300R 97-07 | FITS 94-96 KLX250R, 97-07 KLX300R | 29T - FITS 85-05 KLR250, 94-96 KLX250, 97-02 KLX300 - 59051-1120 | 1994 | KLX250R | FITS 93-05 KLR250, 94-96 KLX250R, 97-07 KLX300R - 13066-1088 | 1994 | KLX250R | 22T - FITS 93-96 KLX250R, 97-07 KLX300R - 13097-1296 | 1994 | KLX250R | 1994 | KLX250R | FITS 93-96 KLX650C, 93-95 KLX650R, 94 & 96 KLX250R | 1994 | KLX250R | 1994 | KLX250R | FITS 94-96 KLX250R, 97-98 KLX300R | 1994 | KLX250R | FITS 94-96 KLX250 | 1994 | KLX250R | FITS 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S | 1994 | KLX250R | 1994 | KLX250R | FITS 96-96 KLX250R, 97-02 KLX300R - 13128-1213 | 1994 | KLX250R | FITS 94-96 KLX250R, 97-07 KLX300R - 26030-1165 | 1994 | KLX250R | |||||||||||||||||||||||||||||||||||||||||
| 1995 | KLX250R | JKALXMD12SA00---- | LX250DE111111 | 1995 | KLX250R | FITS 94-96 KLX250R, 97-07 KLX300R, 06--12 KLX250S - 12044-1327 | KEIHIN CVK G188 32.5MM | 1995 | KLX250R | 21119-1376 071000-0520 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 1995 | KLX250R | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 1995 | KLX250R | 1995 | KLX250R | 1995 | KLX250R | FITS 93-94 KDX200 KDX250, 93-95 KLX650R, 93-96 KLX650C, 94-96 KLX250R, 97-03 KLX300R, LH 55020-1363-RZ, RH 55020-1423-RZ | 1995 | KLX250R | FITS 93-94 KDX200 KDX250, 93-95 KLX650R KLX250R, RH 13070-1264, LH 13070-1263 | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | FITS 93-95 KLX650R, 93-96 KLX650C, 95-96 KLX250R | 1995 | KLX250R | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | FITS 93-95 KLX650R, 94-95 KLX250R, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 1995 | KLX250R | FITS 94-96 KLX250R, 97-07 KLX300R | 29T - FITS 85-05 KLR250, 94-96 KLX250, 97-02 KLX300 - 59051-1120 | 1995 | KLX250R | FITS 93-05 KLR250, 94-96 KLX250R, 97-07 KLX300R - 13066-1088 | 1995 | KLX250R | 22T - FITS 93-96 KLX250R, 97-07 KLX300R - 13097-1296 | 1995 | KLX250R | R-1237 - AXLE DIA 20MM - BRG TO BRG 128-129MM - ROTOR BC 6 ON 116MM - SPROCKET BC 6 ON 150MM - FITS 91-94 KDX250, 93-96 KLX650R, 94-96 KLX250R, 95-06 KDX200 | 1995 | KLX250R | 1995 | KLX250R | 1995 | KLX250R | FITS 94-96 KLX250R, 97-98 KLX300R | 1995 | KLX250R | FITS 94-96 KLX250 | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 1995 | KLX250R | FITS 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S | 1995 | KLX250R | 1995 | KLX250R | FITS 96-96 KLX250R, 97-02 KLX300R - 13128-1213 | 1995 | KLX250R | SH623-12 | FITS 94-96 KLX250R, 97-07 KLX300R - 26030-1165 | 1995 | KLX250R | ||||||||||||||||||||||||||||||||||||
| 1996 | KLX250R | 1996 | KLX250R | FITS 94-96 KLX250R, 97-07 KLX300R, 06--12 KLX250S - 12044-1327 | KEIHIN CVK G188 32.5MM | 1996 | KLX250R | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 1996 | KLX250R | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 1996 | KLX250R | 1996 | KLX250R | 1996 | KLX250R | USD K328-L K328-R - 43MM CHROME OD - C/L 36" - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 102MM - AXLE 22MM & 15MM | FITS 93-94 KDX200 KDX250, 93-95 KLX650R, 93-96 KLX650C, 94-96 KLX250R, 97-03 KLX300R, LH 55020-1363-RZ, RH 55020-1423-RZ | 1996 | KLX250R | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | FITS 93-95 KLX650R, 93-96 KLX650C, 95-96 KLX250R | 1996 | KLX250R | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | 1996 | KLX250R | FITS 94-96 KLX250R, 97-07 KLX300R | 29T - FITS 85-05 KLR250, 94-96 KLX250, 97-02 KLX300 - 59051-1120 | 1996 | KLX250R | FITS 93-05 KLR250, 94-96 KLX250R, 97-07 KLX300R - 13066-1088 | 1996 | KLX250R | 22T - FITS 93-96 KLX250R, 97-07 KLX300R - 13097-1296 | 1996 | KLX250R | 1996 | KLX250R | FITS 93-96 KLX650C, 93-95 KLX650R, 94 & 96 KLX250R | 1996 | KLX250R | 1996 | KLX250R | FITS 94-96 KLX250R, 97-98 KLX300R | 1996 | KLX250R | FITS 96 KLX250, 97-07 KLX300 | FITS 94-96 KLX250 | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 1996 | KLX250R | FITS 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S | 1996 | KLX250R | 1996 | KLX250R | FITS 96-96 KLX250R, 97-02 KLX300R - 13128-1213 | 1996 | KLX250R | FITS 94-96 KLX250R, 97-07 KLX300R - 26030-1165 | 1996 | KLX250R | ||||||||||||||||||||||||||||||||||||||||
| YEAR | TYPE | VIN FRAME USA ONLY | ENGINE ID | ENGINE CASES | AIR BOX | YEAR | TYPE | CAM SHAFT EXHAUST | CAM SHAFT INTAKE | CARBURETOR | YEAR | TYPE | CDI | CHAIN GUIDE | CHAIN SLIDE | YEAR | TYPE | CLUTCH BASKET | COIL | YEAR | TYPE | CONDENSOR | CRANK SHAFT | CYLINDER | EXHAUST HEADER | EXHAUST MUFFLER | FLY WHEEL ROTOR | YEAR | TYPE | FOOT PEGS PASSENGER | FOOT PEG PASSENGER MOUNTS | YEAR | TYPE | FORK | FORK GUARDS | YEAR | TYPE | FORK GUARD MOUNTS | FRONT AXLE | FRONT BRAKE CALIPER | YEAR | TYPE | FRONT BRAKE CALIPER MOUNT | FRONT BRAKE LEVER | FRONT BRAKE MASTER CYLINDER | YEAR | TYPE | FRONT BRAKE ROTOR | FRONT HUB | HEAD | HEAD LIGHT BODY | KICK IDLER GEAR | YEAR | TYPE | KICK LEVER | KICK LEVER SHAFT | YEAR | TYPE | LEFT CONTROL SWITCH | ONE WAY CLUTCH GEAR | PISTON | PRIMARY CRANK GEAR | RADIATOR LEFT | RADIATOR RIGHT | REAR AXLE | YEAR | TYPE | RADIATOR SHROUDS | REAR HUB | YEAR | TYPE | REAR BRAKE CALIPER | REAR BRAKE HOSE | YEAR | TYPE | REAR BRAKE MASTER CYLINDER | REAR BRAKE ROTOR | REAR WHEEL SPACERS | YEAR | TYPE | SHOCK | SIDE STAND | YEAR | TYPE | STATOR | SWING ARM | SWING ARM PIN / AXLE | YEAR | TYPE | TIMING CHAIN TENSIONER | YEAR | TYPE | TRANSMISSION | YEAR | TYPE | TRANSMISSION OUT PUT SHAFT | TRIPLE TREE BOTTOM | YEAR | TYPE | TRIPLE TREE TOP | VOLTAGE REGULATOR | WIRE HARNESS | WATER PUMP IMPELLER | YEAR | TYPE |
| 1997 | KLX300R | 1997 | KLX300R | FITS 97-02 KLX300R, 06-10 KLX250S - 12044-1365 | FITS 94-96 KLX250R, 97-07 KLX300R, 06--12 KLX250S - 12044-1327 | FITS 97-06 KLX300R - 15003-1260 | 1997 | KLX300R | Denso 21119-1479 071000-1090 FITS 97-2007 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 1997 | KLX300R | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 1997 | KLX300R | 1997 | KLX300R | 1997 | KLX300R | USD K328-L K328-R - 43MM CHROME OD - C/L 36" - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 102MM - AXLE 22MM & 15MM - FITS 97-02 KLX300R | FITS 93-94 KDX200 KDX250, 93-95 KLX650R, 93-96 KLX650C, 94-96 KLX250R, 97-03 KLX300R, LH 55020-1363-RZ, RH 55020-1423-RZ | 1997 | KLX300R | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | FITS 94-96 KX125 KX250, 94-03 KX500, 95-03 KDX200, 96 KLX650R, 97-03 KDX220, 97-03 KLX300 | 1997 | KLX300R | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | FITS 93-95 KLX650R, 94-95 KLX250R, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 1997 | KLX300R | 92-94 KDX250, 92-02 KX125 KX250, 93-96 KLX650R, 94-04 KX500, 95-96 KLX250R, 97-07 KLX300R | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R | 29T - FITS 85-05 KLR250, 94-96 KLX250, 97-02 KLX300 - 59051-1120 | 1997 | KLX300R | FITS 93-05 KLR250, 94-96 KLX250R, 97-07 KLX300R - 13066-1088 | 1997 | KLX300R | 22T - FITS 93-96 KLX250R, 97-07 KLX300R - 13097-1296 | 1997 | KLX300R | R-1237 20mm AXLE DIA - BRG TO BRG 129mm - FITS KDX200 95-06, KDX250 91-94, KLR650R 93-96, KLX250R 94-96, KLX300R 97-07, KDX220 97-05 | 1997 | KLX300R | FITS 95-96 KX125 & KX250, 96KLX650R, 96-03 KX500, 97-03 KLX300R | 1997 | KLX300R | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 1997 | KLX300R | Spring thickness: 11.5MM OD - Spring Diameter: 88.5MM - Spring length as mounted: 250MM - Upper mount tab thickness: 27MM - Upper mount tab hole ID: 10MM - Lower Mount Internal Width: 22.6MM - Lower mount hole ID: 10MM - Eye to Eye: 430MM FITS 97-04 KLX300R | FITS 94-96 KLX250R, 97-98 KLX300R | 1997 | KLX300R | FITS 96 KLX250, 97-07 KLX300 | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 1997 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S | 1997 | KLX300R | Everything fits 97-07 KLX300R except the output shaft which fits 97-2002 | 1997 | KLX300R | FITS 96-96 KLX250R, 97-02 KLX300R - 13128-1213 | 1997 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R - 26030-1165 | 1997 | KLX300R | |||||||||||||||||||||||||||||||
| 1998 | KLX300R | 1998 | KLX300R | FITS 97-02 KLX300R, 06-10 KLX250S - 12044-1365 | FITS 94-96 KLX250R, 97-07 KLX300R, 06--12 KLX250S - 12044-1327 | FITS 97-06 KLX300R - 15003-1260 | 1998 | KLX300R | Denso 21119-1479 071000-1090 FITS 97-2007 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 1998 | KLX300R | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 1998 | KLX300R | 1998 | KLX300R | 1998 | KLX300R | USD K328-L K328-R - 43MM CHROME OD - C/L 36" - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 102MM - AXLE 22MM & 15MM - FITS 97-02 KLX300R | FITS 93-94 KDX200 KDX250, 93-95 KLX650R, 93-96 KLX650C, 94-96 KLX250R, 97-03 KLX300R, LH 55020-1363-RZ, RH 55020-1423-RZ | 1998 | KLX300R | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | FITS 94-96 KX125 KX250, 94-03 KX500, 95-03 KDX200, 96 KLX650R, 97-03 KDX220, 97-03 KLX300 | 1998 | KLX300R | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | FITS 93-95 KLX650R, 94-95 KLX250R, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 1998 | KLX300R | 92-94 KDX250, 92-02 KX125 KX250, 93-96 KLX650R, 94-04 KX500, 95-96 KLX250R, 97-07 KLX300R | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R | 29T - FITS 85-05 KLR250, 94-96 KLX250, 97-02 KLX300 - 59051-1120 | 1998 | KLX300R | FITS 93-05 KLR250, 94-96 KLX250R, 97-07 KLX300R - 13066-1088 | 1998 | KLX300R | 22T - FITS 93-96 KLX250R, 97-07 KLX300R - 13097-1296 | 1998 | KLX300R | R-1237 20mm AXLE DIA - BRG TO BRG 129mm - FITS KDX200 95-06, KDX250 91-94, KLR650R 93-96, KLX250R 94-96, KLX300R 97-07, KDX220 97-05 | 1998 | KLX300R | FITS 95-96 KX125 & KX250, 96KLX650R, 96-03 KX500, 97-03 KLX300R | 1998 | KLX300R | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 1998 | KLX300R | Spring thickness: 11.5MM OD - Spring Diameter: 88.5MM - Spring length as mounted: 250MM - Upper mount tab thickness: 27MM - Upper mount tab hole ID: 10MM - Lower Mount Internal Width: 22.6MM - Lower mount hole ID: 10MM - Eye to Eye: 430MM FITS 97-04 KLX300R | FITS 94-96 KLX250R, 97-98 KLX300R | 1998 | KLX300R | FITS 96 KLX250, 97-07 KLX300 | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 1998 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S | 1998 | KLX300R | Everything fits 97-07 KLX300R except the output shaft which fits 97-2002 | 1998 | KLX300R | FITS 96-96 KLX250R, 97-02 KLX300R - 13128-1213 | 1998 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R - 26030-1165 | 1998 | KLX300R | |||||||||||||||||||||||||||||||
| 1999 | KLX300R | 1999 | KLX300R | FITS 97-02 KLX300R, 06-10 KLX250S - 12044-1365 | FITS 94-96 KLX250R, 97-07 KLX300R, 06--12 KLX250S - 12044-1327 | FITS 97-06 KLX300R - 15003-1260 | 1999 | KLX300R | Denso 21119-1479 071000-1090 FITS 97-2007 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 1999 | KLX300R | 1119 1KX250D-A201 | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 1999 | KLX300R | 1999 | KLX300R | 1999 | KLX300R | USD K328-L K328-R - 43MM CHROME OD - C/L 36" - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 102MM - AXLE 22MM & 15MM - FITS 97-02 KLX300R | FITS 93-94 KDX200 KDX250, 93-95 KLX650R, 93-96 KLX650C, 94-96 KLX250R, 97-03 KLX300R, LH 55020-1363-RZ, RH 55020-1423-RZ | 1999 | KLX300R | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | FITS 94-96 KX125 KX250, 94-03 KX500, 95-03 KDX200, 96 KLX650R, 97-03 KDX220, 97-03 KLX300 | 1999 | KLX300R | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | FITS 93-95 KLX650R, 94-95 KLX250R, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 1999 | KLX300R | 92-94 KDX250, 92-02 KX125 KX250, 93-96 KLX650R, 94-04 KX500, 95-96 KLX250R, 97-07 KLX300R | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R | 29T - FITS 85-05 KLR250, 94-96 KLX250, 97-02 KLX300 - 59051-1120 | 1999 | KLX300R | FITS 93-05 KLR250, 94-96 KLX250R, 97-07 KLX300R - 13066-1088 | 1999 | KLX300R | 22T - FITS 93-96 KLX250R, 97-07 KLX300R - 13097-1296 | 1999 | KLX300R | R-1237 20mm AXLE DIA - BRG TO BRG 129mm - FITS KDX200 95-06, KDX250 91-94, KLR650R 93-96, KLX250R 94-96, KLX300R 97-07, KDX220 97-05 | 1999 | KLX300R | FITS 95-96 KX125 & KX250, 96KLX650R, 96-03 KX500, 97-03 KLX300R | 1999 | KLX300R | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 1999 | KLX300R | Spring thickness: 11.5MM OD - Spring Diameter: 88.5MM - Spring length as mounted: 250MM - Upper mount tab thickness: 27MM - Upper mount tab hole ID: 10MM - Lower Mount Internal Width: 22.6MM - Lower mount hole ID: 10MM - Eye to Eye: 430MM FITS 97-04 KLX300R | 1999 | KLX300R | FITS 96 KLX250, 97-07 KLX300 | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 1999 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S | 1999 | KLX300R | Everything fits 97-07 KLX300R except the output shaft which fits 97-2002 | 1999 | KLX300R | FITS 96-96 KLX250R, 97-02 KLX300R - 13128-1213 | 1999 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R - 26030-1165 | 1999 | KLX300R | |||||||||||||||||||||||||||||||
| 2000 | KLX300R | 2000 | KLX300R | FITS 97-02 KLX300R, 06-10 KLX250S - 12044-1365 | FITS 94-96 KLX250R, 97-07 KLX300R, 06--12 KLX250S - 12044-1327 | FITS 97-06 KLX300R - 15003-1260 | 2000 | KLX300R | Denso 21119-1479 071000-1090 FITS 97-2007 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 2000 | KLX300R | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 2000 | KLX300R | 2000 | KLX300R | 2000 | KLX300R | USD K328-L K328-R - 43MM CHROME OD - C/L 36" - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 102MM - AXLE 22MM & 15MM - FITS 97-02 KLX300R | FITS 93-94 KDX200 KDX250, 93-95 KLX650R, 93-96 KLX650C, 94-96 KLX250R, 97-03 KLX300R, LH 55020-1363-RZ, RH 55020-1423-RZ | 2000 | KLX300R | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | FITS 94-96 KX125 KX250, 94-03 KX500, 95-03 KDX200, 96 KLX650R, 97-03 KDX220, 97-03 KLX300 | 2000 | KLX300R | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | FITS 93-95 KLX650R, 94-95 KLX250R, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 2000 | KLX300R | 92-94 KDX250, 92-02 KX125 KX250, 93-96 KLX650R, 94-04 KX500, 95-96 KLX250R, 97-07 KLX300R | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R | 29T - FITS 85-05 KLR250, 94-96 KLX250, 97-02 KLX300 - 59051-1120 | 2000 | KLX300R | FITS 93-05 KLR250, 94-96 KLX250R, 97-07 KLX300R - 13066-1088 | 2000 | KLX300R | 22T - FITS 93-96 KLX250R, 97-07 KLX300R - 13097-1296 | FITS 99-05 KDX220, 00-06 KDX200, 00-07 KLX300R, 06-07 KLX250S | 2000 | KLX300R | R-1237 20mm AXLE DIA - BRG TO BRG 129mm - FITS KDX200 95-06, KDX250 91-94, KLR650R 93-96, KLX250R 94-96, KLX300R 97-07, KDX220 97-05 | 2000 | KLX300R | FITS 95-96 KX125 & KX250, 96KLX650R, 96-03 KX500, 97-03 KLX300R | 2000 | KLX300R | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 2000 | KLX300R | Spring thickness: 11.5MM OD - Spring Diameter: 88.5MM - Spring length as mounted: 250MM - Upper mount tab thickness: 27MM - Upper mount tab hole ID: 10MM - Lower Mount Internal Width: 22.6MM - Lower mount hole ID: 10MM - Eye to Eye: 430MM FITS 97-04 KLX300R | 2000 | KLX300R | FITS 96 KLX250, 97-07 KLX300 | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 2000 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S | 2000 | KLX300R | Everything fits 97-07 KLX300R except the output shaft which fits 97-2002 | 2000 | KLX300R | FITS 96-96 KLX250R, 97-02 KLX300R - 13128-1213 | 2000 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R - 26030-1165 | 2000 | KLX300R | |||||||||||||||||||||||||||||||
| 2001 | KLX300R | 2001 | KLX300R | FITS 97-02 KLX300R, 06-10 KLX250S - 12044-1365 | FITS 94-96 KLX250R, 97-07 KLX300R, 06--12 KLX250S - 12044-1327 | FITS 97-06 KLX300R - 15003-1260 | 2001 | KLX300R | Denso 21119-1479 071000-1090 FITS 97-2007 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 2001 | KLX300R | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 2001 | KLX300R | 2001 | KLX300R | 2001 | KLX300R | USD K328-L K328-R - 43MM CHROME OD - C/L 36" - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 102MM - AXLE 22MM & 15MM - FITS 97-02 KLX300R | FITS 93-94 KDX200 KDX250, 93-95 KLX650R, 93-96 KLX650C, 94-96 KLX250R, 97-03 KLX300R, LH 55020-1363-RZ, RH 55020-1423-RZ | 2001 | KLX300R | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | FITS 94-96 KX125 KX250, 94-03 KX500, 95-03 KDX200, 96 KLX650R, 97-03 KDX220, 97-03 KLX300 | 2001 | KLX300R | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | FITS 93-95 KLX650R, 94-95 KLX250R, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 2001 | KLX300R | 92-94 KDX250, 92-02 KX125 KX250, 93-96 KLX650R, 94-04 KX500, 95-96 KLX250R, 97-07 KLX300R | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R | 29T - FITS 85-05 KLR250, 94-96 KLX250, 97-02 KLX300 - 59051-1120 | 2001 | KLX300R | FITS 93-05 KLR250, 94-96 KLX250R, 97-07 KLX300R - 13066-1088 | 2001 | KLX300R | 22T - FITS 93-96 KLX250R, 97-07 KLX300R - 13097-1296 | FITS 99-05 KDX220, 00-06 KDX200, 00-07 KLX300R, 06-07 KLX250S | 2001 | KLX300R | R-1237 20mm AXLE DIA - BRG TO BRG 129mm - FITS KDX200 95-06, KDX250 91-94, KLR650R 93-96, KLX250R 94-96, KLX300R 97-07, KDX220 97-05 | 2001 | KLX300R | FITS 95-96 KX125 & KX250, 96KLX650R, 96-03 KX500, 97-03 KLX300R | 2001 | KLX300R | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 2001 | KLX300R | Spring thickness: 11.5MM OD - Spring Diameter: 88.5MM - Spring length as mounted: 250MM - Upper mount tab thickness: 27MM - Upper mount tab hole ID: 10MM - Lower Mount Internal Width: 22.6MM - Lower mount hole ID: 10MM - Eye to Eye: 430MM FITS 97-04 KLX300R | 2001 | KLX300R | FITS 96 KLX250, 97-07 KLX300 | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 2001 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S | 2001 | KLX300R | Everything fits 97-07 KLX300R except the output shaft which fits 97-2002 | 2001 | KLX300R | FITS 96-96 KLX250R, 97-02 KLX300R - 13128-1213 | 2001 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R - 26030-1165 | 2001 | KLX300R | |||||||||||||||||||||||||||||||
| 2002 | KLX300R | 2002 | KLX300R | FITS 97-02 KLX300R, 06-10 KLX250S - 12044-1365 | FITS 94-96 KLX250R, 97-07 KLX300R, 06--12 KLX250S - 12044-1327 | FITS 97-06 KLX300R - 15003-1260 | 2002 | KLX300R | Denso 21119-1479 071000-1090 FITS 97-2007 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 2002 | KLX300R | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 2002 | KLX300R | 2002 | KLX300R | 2002 | KLX300R | USD K328-L K328-R - 43MM CHROME OD - C/L 36" - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 102MM - AXLE 22MM & 15MM - FITS 97-02 KLX300R | FITS 93-94 KDX200 KDX250, 93-95 KLX650R, 93-96 KLX650C, 94-96 KLX250R, 97-03 KLX300R, LH 55020-1363-RZ, RH 55020-1423-RZ | 2002 | KLX300R | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | FITS 94-96 KX125 KX250, 94-03 KX500, 95-03 KDX200, 96 KLX650R, 97-03 KDX220, 97-03 KLX300 | 2002 | KLX300R | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | FITS 93-95 KLX650R, 94-95 KLX250R, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 2002 | KLX300R | 92-94 KDX250, 92-02 KX125 KX250, 93-96 KLX650R, 94-04 KX500, 95-96 KLX250R, 97-07 KLX300R | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R | 29T - FITS 85-05 KLR250, 94-96 KLX250, 97-02 KLX300 - 59051-1120 | 2002 | KLX300R | FITS 93-05 KLR250, 94-96 KLX250R, 97-07 KLX300R - 13066-1088 | 2002 | KLX300R | 22T - FITS 93-96 KLX250R, 97-07 KLX300R - 13097-1296 | FITS 99-05 KDX220, 00-06 KDX200, 00-07 KLX300R, 06-07 KLX250S | 2002 | KLX300R | R-1237 20mm AXLE DIA - BRG TO BRG 129mm - FITS KDX200 95-06, KDX250 91-94, KLR650R 93-96, KLX250R 94-96, KLX300R 97-07, KDX220 97-05 | 2002 | KLX300R | FITS 95-96 KX125 & KX250, 96KLX650R, 96-03 KX500, 97-03 KLX300R | 2002 | KLX300R | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 2002 | KLX300R | Spring thickness: 11.5MM OD - Spring Diameter: 88.5MM - Spring length as mounted: 250MM - Upper mount tab thickness: 27MM - Upper mount tab hole ID: 10MM - Lower Mount Internal Width: 22.6MM - Lower mount hole ID: 10MM - Eye to Eye: 430MM FITS 97-04 KLX300R | 2002 | KLX300R | FITS 96 KLX250, 97-07 KLX300 | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 2002 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S | 2002 | KLX300R | Everything fits 97-07 KLX300R except the output shaft which fits 97-2002 | 2002 | KLX300R | FITS 96-96 KLX250R, 97-02 KLX300R - 13128-1213 | 2002 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R - 26030-1165 | 2002 | KLX300R | |||||||||||||||||||||||||||||||
| 2003 | KLX300R | 2003 | KLX300R | FITS 03-07 KLX300R - 12044-1487 | FITS 94-96 KLX250R, 97-07 KLX300R, 06--12 KLX250S - 12044-1327 | FITS 97-06 KLX300R - 15003-1260 | 2003 | KLX300R | Denso 21119-1479 071000-1090 FITS 97-2007 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 2003 | KLX300R | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 2003 | KLX300R | 2003 | KLX300R | 2003 | KLX300R | FITS 93-94 KDX200 KDX250, 93-95 KLX650R, 93-96 KLX650C, 94-96 KLX250R, 97-03 KLX300R, LH 55020-1363-RZ, RH 55020-1423-RZ | 2003 | KLX300R | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | FITS 94-96 KX125 KX250, 94-03 KX500, 95-03 KDX200, 96 KLX650R, 97-03 KDX220, 97-03 KLX300 | 2003 | KLX300R | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | FITS 93-95 KLX650R, 94-95 KLX250R, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 2003 | KLX300R | 92-94 KDX250, 92-02 KX125 KX250, 93-96 KLX650R, 94-04 KX500, 95-96 KLX250R, 97-07 KLX300R | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R | 28T - FITS 03-07 KLX300R - 59051-1400 / 29T FITS 85-05 KLR250, 94-96 KLX250, 97-02 KLX300 - 59051-1120 | 2003 | KLX300R | FITS 93-05 KLR250, 94-96 KLX250R, 97-07 KLX300R - 13066-1088 | 2003 | KLX300R | 22T - FITS 93-96 KLX250R, 97-07 KLX300R - 13097-1296 | FITS 99-05 KDX220, 00-06 KDX200, 00-07 KLX300R, 06-07 KLX250S | 2003 | KLX300R | R-1237 20mm AXLE DIA - BRG TO BRG 129mm - FITS KDX200 95-06, KDX250 91-94, KLR650R 93-96, KLX250R 94-96, KLX300R 97-07, KDX220 97-05 | 2003 | KLX300R | FITS 95-96 KX125 & KX250, 96KLX650R, 96-03 KX500, 97-03 KLX300R | 2003 | KLX300R | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 2003 | KLX300R | Spring thickness: 11.5MM OD - Spring Diameter: 88.5MM - Spring length as mounted: 250MM - Upper mount tab thickness: 27MM - Upper mount tab hole ID: 10MM - Lower Mount Internal Width: 22.6MM - Lower mount hole ID: 10MM - Eye to Eye: 430MM FITS 97-04 KLX300R | 2003 | KLX300R | FITS 96 KLX250, 97-07 KLX300 | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 2003 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S | 2003 | KLX300R | Everything fits 97-07 KLX300R except the output shaft which fits 97-2002 | 2003 | KLX300R | 2003 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R - 26030-1165 | 2003 | KLX300R | |||||||||||||||||||||||||||||||||
| 2004 | KLX300R | 2004 | KLX300R | FITS 03-07 KLX300R - 12044-1487 | FITS 94-96 KLX250R, 97-07 KLX300R, 06--12 KLX250S - 12044-1327 | FITS 97-06 KLX300R - 15003-1260 | 2004 | KLX300R | Denso 21119-1479 071000-1090 FITS 97-2007 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 2004 | KLX300R | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 2004 | KLX300R | 2004 | KLX300R | 2004 | KLX300R | 2004 | KLX300R | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | 2004 | KLX300R | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | FITS 93-95 KLX650R, 94-95 KLX250R, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 2004 | KLX300R | 92-94 KDX250, 92-02 KX125 KX250, 93-96 KLX650R, 94-04 KX500, 95-96 KLX250R, 97-07 KLX300R | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R | 28T - FITS 03-07 KLX300R - 59051-1400 / 29T FITS 85-05 KLR250, 94-96 KLX250, 97-02 KLX300 - 59051-1120 | 2004 | KLX300R | FITS 93-05 KLR250, 94-96 KLX250R, 97-07 KLX300R - 13066-1088 | 2004 | KLX300R | 22T - FITS 93-96 KLX250R, 97-07 KLX300R - 13097-1296 | FITS 99-05 KDX220, 00-06 KDX200, 00-07 KLX300R, 06-07 KLX250S | 2004 | KLX300R | R-1237 20mm AXLE DIA - BRG TO BRG 129mm - FITS KDX200 95-06, KDX250 91-94, KLR650R 93-96, KLX250R 94-96, KLX300R 97-07, KDX220 97-05 | 2004 | KLX300R | FITS 04-07 KLR300R, 4 KX500, 06-07 KLX250S | 2004 | KLX300R | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 2004 | KLX300R | Spring thickness: 11.5MM OD - Spring Diameter: 88.5MM - Spring length as mounted: 250MM - Upper mount tab thickness: 27MM - Upper mount tab hole ID: 10MM - Lower Mount Internal Width: 22.6MM - Lower mount hole ID: 10MM - Eye to Eye: 430MM FITS 97-04 KLX300R | SIDE STAND | 2004 | KLX300R | FITS 96 KLX250, 97-07 KLX300 | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 2004 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S | 2004 | KLX300R | Everything fits 97-07 KLX300R except the output shaft which fits 97-2002 | 2004 | KLX300R | 2004 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R - 26030-1165 | 2004 | KLX300R | ||||||||||||||||||||||||||||||||||
| 2005 | KLX300R | 2005 | KLX300R | FITS 03-07 KLX300R - 12044-1487 | FITS 94-96 KLX250R, 97-07 KLX300R, 06--12 KLX250S - 12044-1327 | FITS 97-06 KLX300R - 15003-1260 | 2005 | KLX300R | Denso 21119-1479 071000-1090 FITS 97-2007 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 2005 | KLX300R | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 2005 | KLX300R | 2005 | KLX300R | 2005 | KLX300R | 2005 | KLX300R | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | 2005 | KLX300R | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | FITS 93-95 KLX650R, 94-95 KLX250R, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 2005 | KLX300R | 92-94 KDX250, 92-02 KX125 KX250, 93-96 KLX650R, 94-04 KX500, 95-96 KLX250R, 97-07 KLX300R | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R | 28T - FITS 03-07 KLX300R - 59051-1400 / 29T FITS 85-05 KLR250, 94-96 KLX250, 97-02 KLX300 - 59051-1120 | 2005 | KLX300R | FITS 93-05 KLR250, 94-96 KLX250R, 97-07 KLX300R - 13066-1088 | 2005 | KLX300R | 22T - FITS 93-96 KLX250R, 97-07 KLX300R - 13097-1296 | FITS 99-05 KDX220, 00-06 KDX200, 00-07 KLX300R, 06-07 KLX250S | 2005 | KLX300R | R-1237 20mm AXLE DIA - BRG TO BRG 129mm - FITS KDX200 95-06, KDX250 91-94, KLR650R 93-96, KLX250R 94-96, KLX300R 97-07, KDX220 97-05 | 2005 | KLX300R | FITS 04-07 KLR300R, 4 KX500, 06-07 KLX250S | 2005 | KLX300R | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 2005 | KLX300R | 2005 | KLX300R | FITS 96 KLX250, 97-07 KLX300 | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 2005 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S | 2005 | KLX300R | Everything fits 97-07 KLX300R except the output shaft which fits 97-2002 | 2005 | KLX300R | 2005 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R - 26030-1165 | 2005 | KLX300R | ||||||||||||||||||||||||||||||||||||
| 2006 | KLX300R | 2006 | KLX300R | FITS 03-07 KLX300R - 12044-1487 | FITS 94-96 KLX250R, 97-07 KLX300R, 06--12 KLX250S - 12044-1327 | FITS 97-06 KLX300R - 15003-1260 | 2006 | KLX300R | Denso 21119-1479 071000-1090 FITS 97-2007 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 2006 | KLX300R | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 2006 | KLX300R | 2006 | KLX300R | 2006 | KLX300R | 2006 | KLX300R | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | 2006 | KLX300R | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | FITS 93-95 KLX650R, 94-95 KLX250R, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 2006 | KLX300R | 92-94 KDX250, 92-02 KX125 KX250, 93-96 KLX650R, 94-04 KX500, 95-96 KLX250R, 97-07 KLX300R | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R | 28T - FITS 03-07 KLX300R - 59051-1400 / 29T FITS 85-05 KLR250, 94-96 KLX250, 97-02 KLX300 - 59051-1120 | 2006 | KLX300R | FITS 93-05 KLR250, 94-96 KLX250R, 97-07 KLX300R - 13066-1088 | 2006 | KLX300R | 22T - FITS 93-96 KLX250R, 97-07 KLX300R - 13097-1296 | FITS 99-05 KDX220, 00-06 KDX200, 00-07 KLX300R, 06-07 KLX250S | 2006 | KLX300R | R-1237 20mm AXLE DIA - BRG TO BRG 129mm - FITS KDX200 95-06, KDX250 91-94, KLR650R 93-96, KLX250R 94-96, KLX300R 97-07, KDX220 97-05 | 2006 | KLX300R | FITS 04-07 KLR300R, 4 KX500, 06-07 KLX250S | 2006 | KLX300R | 2006 | KLX300R | 2006 | KLX300R | FITS 96 KLX250, 97-07 KLX300 | FITS 88-91 KX125 KX250, 88-04 KX500, 89-06 KDX200, 91-94 KDX250, 94-96 KLX250, 97-06 KLX300, 06-07 KLX 250S - 33032-1137 | 2006 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S | 2006 | KLX300R | Everything fits 97-07 KLX300R except the output shaft which fits 97-2002 | 2006 | KLX300R | 2006 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R - 26030-1165 | 2006 | KLX300R | |||||||||||||||||||||||||||||||||||||
| 2007 | KLX300R | 2007 | KLX300R | FITS 03-07 KLX300R - 12044-1487 | FITS 94-96 KLX250R, 97-07 KLX300R, 06--12 KLX250S - 12044-1327 | 2007 | KLX300R | Denso 21119-1479 071000-1090 FITS 97-2007 | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 2007 | KLX300R | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 2007 | KLX300R | 2007 | KLX300R | 2007 | KLX300R | 2007 | KLX300R | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | 2007 | KLX300R | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | FITS 93-95 KLX650R, 94-95 KLX250R, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 2007 | KLX300R | 92-94 KDX250, 92-02 KX125 KX250, 93-96 KLX650R, 94-04 KX500, 95-96 KLX250R, 97-07 KLX300R | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R | 28T - FITS 03-07 KLX300R - 59051-1400 / 29T FITS 85-05 KLR250, 94-96 KLX250, 97-02 KLX300 - 59051-1120 | 2007 | KLX300R | FITS 93-05 KLR250, 94-96 KLX250R, 97-07 KLX300R - 13066-1088 | 2007 | KLX300R | 22T - FITS 93-96 KLX250R, 97-07 KLX300R - 13097-1296 | FITS 99-05 KDX220, 00-06 KDX200, 00-07 KLX300R, 06-07 KLX250S | 2007 | KLX300R | R-1237 20mm AXLE DIA - BRG TO BRG 129mm - FITS KDX200 95-06, KDX250 91-94, KLR650R 93-96, KLX250R 94-96, KLX300R 97-07, KDX220 97-05 | 2007 | KLX300R | FITS 04-07 KLR300R, 4 KX500, 06-07 KLX250S | 2007 | KLX300R | 2007 | KLX300R | 2007 | KLX300R | FITS 96 KLX250, 97-07 KLX300 | 2007 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R, 06-07 KLX250S | 2007 | KLX300R | Everything fits 97-07 KLX300R except the output shaft which fits 97-2002 | 2007 | KLX300R | 2007 | KLX300R | FITS 94-96 KLX250R, 97-07 KLX300R - 26030-1165 | 2007 | KLX300R | |||||||||||||||||||||||||||||||||||||||
| YEAR | TYPE | VIN FRAME USA ONLY | ENGINE ID | ENGINE CASES | AIR BOX | YEAR | TYPE | CAM SHAFT EXHAUST | CAM SHAFT INTAKE | CARBURETOR | YEAR | TYPE | CDI | CHAIN GUIDE | CHAIN SLIDE | YEAR | TYPE | CLUTCH BASKET | COIL | YEAR | TYPE | CONDENSOR | CRANK SHAFT | CYLINDER | EXHAUST HEADER | EXHAUST MUFFLER | FLY WHEEL ROTOR | YEAR | TYPE | FOOT PEGS PASSENGER | FOOT PEG PASSENGER MOUNTS | YEAR | TYPE | FORK | FORK GUARDS | YEAR | TYPE | FORK GUARD MOUNTS | FRONT AXLE | FRONT BRAKE CALIPER | YEAR | TYPE | FRONT BRAKE CALIPER MOUNT | FRONT BRAKE LEVER | FRONT BRAKE MASTER CYLINDER | YEAR | TYPE | FRONT BRAKE ROTOR | FRONT HUB | HEAD | HEAD LIGHT BODY | KICK IDLER GEAR | YEAR | TYPE | KICK LEVER | KICK LEVER SHAFT | YEAR | TYPE | LEFT CONTROL SWITCH | ONE WAY CLUTCH GEAR | PISTON | PRIMARY CRANK GEAR | RADIATOR LEFT | RADIATOR RIGHT | REAR AXLE | YEAR | TYPE | RADIATOR SHROUDS | REAR HUB | YEAR | TYPE | REAR BRAKE CALIPER | REAR BRAKE HOSE | YEAR | TYPE | REAR BRAKE MASTER CYLINDER | REAR BRAKE ROTOR | REAR WHEEL SPACERS | YEAR | TYPE | SHOCK | SIDE STAND | YEAR | TYPE | STATOR | SWING ARM | SWING ARM PIN / AXLE | YEAR | TYPE | TIMING CHAIN TENSIONER | YEAR | TYPE | TRANSMISSION | YEAR | TYPE | TRANSMISSION OUT PUT SHAFT | TRIPLE TREE BOTTOM | YEAR | TYPE | TRIPLE TREE TOP | VOLTAGE REGULATOR | WIRE HARNESS | WATER PUMP IMPELLER | YEAR | TYPE |
| 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | FITS 05 KX250F, 06-08 KX450F, 08-09 KLX450R - 21121-0016 | 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | 2008 | KLX450R | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | FITS 05 KX250F, 06-08 KX450F, 08-09 KLX450R - 21121-0016 | 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | 2009 | KLX450R | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| YEAR | TYPE | VIN FRAME USA ONLY | ENGINE ID | ENGINE CASES | AIR BOX | YEAR | TYPE | CAM SHAFT EXHAUST | CAM SHAFT INTAKE | CARBURETOR | YEAR | TYPE | CDI | CHAIN GUIDE | CHAIN SLIDE | YEAR | TYPE | CLUTCH BASKET | COIL | YEAR | TYPE | CONDENSOR | CRANK SHAFT | CYLINDER | EXHAUST HEADER | EXHAUST MUFFLER | FLY WHEEL ROTOR | YEAR | TYPE | FOOT PEGS PASSENGER | FOOT PEG PASSENGER MOUNTS | YEAR | TYPE | FORK | FORK GUARDS | YEAR | TYPE | FORK GUARD MOUNTS | FRONT AXLE | FRONT BRAKE CALIPER | YEAR | TYPE | FRONT BRAKE CALIPER MOUNT | FRONT BRAKE LEVER | FRONT BRAKE MASTER CYLINDER | YEAR | TYPE | FRONT BRAKE ROTOR | FRONT HUB | HEAD | HEAD LIGHT BODY | KICK IDLER GEAR | YEAR | TYPE | KICK LEVER | KICK LEVER SHAFT | YEAR | TYPE | LEFT CONTROL SWITCH | ONE WAY CLUTCH GEAR | PISTON | PRIMARY CRANK GEAR | RADIATOR LEFT | RADIATOR RIGHT | REAR AXLE | YEAR | TYPE | RADIATOR SHROUDS | REAR HUB | YEAR | TYPE | REAR BRAKE CALIPER | REAR BRAKE HOSE | YEAR | TYPE | REAR BRAKE MASTER CYLINDER | REAR BRAKE ROTOR | REAR WHEEL SPACERS | YEAR | TYPE | SHOCK | SIDE STAND | YEAR | TYPE | STATOR | SWING ARM | SWING ARM PIN / AXLE | YEAR | TYPE | TIMING CHAIN TENSIONER | YEAR | TYPE | TRANSMISSION | YEAR | TYPE | TRANSMISSION OUT PUT SHAFT | TRIPLE TREE BOTTOM | YEAR | TYPE | TRIPLE TREE TOP | VOLTAGE REGULATOR | WIRE HARNESS | WATER PUMP IMPELLER | YEAR | TYPE |
| 1993 | KLX650R | LX650AE01XXXX | FITS 93-96 KLX650R | 1993 | KLX650R | KEIHIN CVK 792 40MM - 15001-1792 - FITS 93-96 KLX650R | 1993 | KLX650R | DENSO 21119-1368/1361 070000-2410/071000-0510 FITS 93-96 KLX650R – 21119-1361 - G/W TO W/Y IS 90-170 OHM | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 1993 | KLX650R | FITS 93-96 KLX650R – 13095-1256 | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 1993 | KLX650R | FITS 93-96 KLX650R - 21013-1051 | FITS 93 KLX650R ONLY 13031-1377 | FITS 93-96 KLX650R – 11005-1719 – 100MM STD BORE | FITS 93-96 KLX650R - 18049-1664 | FITS 93-96 KLX650R - 18090-1300 | 1993 | KLX650R | 1993 | KLX650R | KYB - USD - K328-L K328-R - CHROME OD 43MM - C/L 36 1/8" - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 102MM - AXLE OD 15MM & 22MM - FITS 93-96 KLX650R | FITS 93-94 KDX200 KDX250, 93-95 KLX650R, 93-96 KLX650C, 94-96 KLX250R, 97-03 KLX300R, LH 55020-1363-RZ, RH 55020-1423-RZ | 1993 | KLX650R | FITS 93-94 KDX200 KDX250, 93-95 KLX650R KLX250R, RH 13070-1264, LH 13070-1263 | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | FITS 93-95 KLX650R, 93-96 KLX650C, 95-96 KLX250R | 1993 | KLX650R | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | FITS 93-95 KLX650R, 94-95 KLX250R, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 1993 | KLX650R | ROTOR OD 250MM - ROTOR BOLT CIRCLE 4 ON 116MM | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 93-96 KLX650R – 11008-1270 | 1993 | KLX650R | FITS 93-96 KLX650R - 13064-1171 - SPLINE ID APPROX 19.75MM | 1993 | KLX650R | FITS 93-94 KLX650R – 13001-1417 | FITS 93-96 KLX650R KLX650C - 39061-1188 - BOTH OUTLETS ARE 20MM OD, CORE W5.25 X H9.5 X T1.25 | FITS 93 KLX650R, 93-96 KLX650C - 39061-1189 | 1993 | KLX650R | GREEN FITS 93-94 KLX650R - LH 49089-5170-6W, RH 49089-5209-6W | R-1237 20mm AXLE DIA - BRG TO BRG 129mm - FITS KDX200 95-06, KDX250 91-94, KLR650R 93-96, KLX250R 94-96, KLX300R 97-07, KDX220 97-05 | 1993 | KLX650R | FITS 93-96 KLX650C, 93-95 KLX650R, 94 & 96 KLX250R | FITS 90-96 KX125 KX250, 91-94 KDX250, 93-96 KLX650C KLX650R, 95-06 KDX200, 97-05 KDX220 43059-1561 | 1993 | KLX650R | FITS 91-93 KX125 KX250 KDX250, 93-95 KLX650R | ROTOR OD 230MM - ID 100MM - ROTOR 6 ON A 115MM BC - FITS 93-96 KLX650C, 93-95 KLX650R - 41080-1368 | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 1993 | KLX650R | KYB - Spring thickness: 12.3MM OD - Spring Diameter: 88.5MM - Spring length as mounted: 240MM - Upper mount tab thickness: 26.8MM - Upper mount tab hole ID: 10MM - Lower Mount Internal Width: 22.7MM - Lower mount hole ID: 10MM - Eye to Eye: 432MM - FITS 93-96 KLX650R | 1993 | KLX650R | FITS 93-96 KLX650R - 21003-1252 - yellow to yellow wires .3-1.0 ohm - pickup coil 100-148 OHM | FITS 92-93 KX125 KX250, 93-96 KLX650R | 1993 | KLX650R | FITS 93-96 KLX650 C & R | 1993 | KLX650R | 1993 | KLX650R | FITS 93-96 KLX650R (I SEE VERY LITTLE DIFFERENCE IN THIS BOTTOM AND THE KLX650C 93-96) | 1993 | KLX650R | FITS 93-96 KLX650R (THE KLX650C WILL ALSO FIT BUT IT HAS THE IGNITION MOUNT) | 1993 | KLX650R | |||||||||||||||||||||
| 1994 | KLX650R | LX650AE01XXXX | FITS 93-96 KLX650R | 1994 | KLX650R | KEIHIN CVK 792 40MM - 15001-1792 - FITS 93-96 KLX650R | 1994 | KLX650R | DENSO 21119-1368/1361 070000-2410/071000-0510 FITS 93-96 KLX650R – 21119-1361 - G/W TO W/Y IS 90-170 OHM | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 1994 | KLX650R | FITS 93-96 KLX650R – 13095-1256 | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 1994 | KLX650R | FITS 93-96 KLX650R - 21013-1051 | FITS 94-96 KLX650R 13031-1380 | FITS 93-96 KLX650R – 11005-1719 – 100MM STD BORE | FITS 93-96 KLX650R - 18049-1664 | FITS 93-96 KLX650R - 18090-1300 | 1994 | KLX650R | 1994 | KLX650R | KYB - USD - K328-L K328-R - CHROME OD 43MM - C/L 36 1/8" - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 102MM - AXLE OD 15MM & 22MM - FITS 93-96 KLX650R | FITS 93-94 KDX200 KDX250, 93-95 KLX650R, 93-96 KLX650C, 94-96 KLX250R, 97-03 KLX300R, LH 55020-1363-RZ, RH 55020-1423-RZ | 1994 | KLX650R | FITS 93-94 KDX200 KDX250, 93-95 KLX650R KLX250R, RH 13070-1264, LH 13070-1263 | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | FITS 93-95 KLX650R, 93-96 KLX650C, 95-96 KLX250R | 1994 | KLX650R | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | FITS 93-95 KLX650R, 94-95 KLX250R, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 1994 | KLX650R | ROTOR OD 250MM - ROTOR BOLT CIRCLE 4 ON 116MM | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 93-96 KLX650R – 11008-1270 | 1994 | KLX650R | FITS 93-96 KLX650R - 13064-1171 - SPLINE ID APPROX 19.75MM | 1994 | KLX650R | FITS 93-94 KLX650R – 13001-1417 | FITS 93-96 KLX650R KLX650C - 39061-1188 - BOTH OUTLETS ARE 20MM OD, CORE W5.25 X H9.5 X T1.25 | FITS 94-96 KLX650R - 39061-1208 | 1994 | KLX650R | GREEN FITS 93-94 KLX650R - LH 49089-5170-6W, RH 49089-5209-6W | R-1237 20mm AXLE DIA - BRG TO BRG 129mm - FITS KDX200 95-06, KDX250 91-94, KLR650R 93-96, KLX250R 94-96, KLX300R 97-07, KDX220 97-05 | 1994 | KLX650R | FITS 93-96 KLX650C, 93-95 KLX650R, 94 & 96 KLX250R | FITS 90-96 KX125 KX250, 91-94 KDX250, 93-96 KLX650C KLX650R, 95-06 KDX200, 97-05 KDX220 43059-1561 | 1994 | KLX650R | FITS 91-93 KX125 KX250 KDX250, 93-95 KLX650R | ROTOR OD 230MM - ID 100MM - ROTOR 6 ON A 115MM BC - FITS 93-96 KLX650C, 93-95 KLX650R - 41080-1368 | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 1994 | KLX650R | KYB - Spring thickness: 12.3MM OD - Spring Diameter: 88.5MM - Spring length as mounted: 240MM - Upper mount tab thickness: 26.8MM - Upper mount tab hole ID: 10MM - Lower Mount Internal Width: 22.7MM - Lower mount hole ID: 10MM - Eye to Eye: 432MM - FITS 93-96 KLX650R | 1994 | KLX650R | FITS 93-96 KLX650R - 21003-1252 - yellow to yellow wires .3-1.0 ohm - pickup coil 100-148 OHM | FITS 92-93 KX125 KX250, 93-96 KLX650R | 1994 | KLX650R | FITS 93-96 KLX650 C & R | 1994 | KLX650R | 1994 | KLX650R | FITS 93-96 KLX650R (I SEE VERY LITTLE DIFFERENCE IN THIS BOTTOM AND THE KLX650C 93-96) | 1994 | KLX650R | FITS 93-96 KLX650R (THE KLX650C WILL ALSO FIT BUT IT HAS THE IGNITION MOUNT) | 1994 | KLX650R | |||||||||||||||||||||
| 1995 | KLX650R | JKALXEA18SA00XXXX | LX650AE01XXXX | FITS 93-96 KLX650R | 1995 | KLX650R | KEIHIN CVK 792 40MM - 15001-1792 - FITS 93-96 KLX650R | 1995 | KLX650R | DENSO 21119-1368/1361 070000-2410/071000-0510 FITS 93-96 KLX650R – 21119-1361 - G/W TO W/Y IS 90-170 OHM | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 1995 | KLX650R | FITS 93-96 KLX650R – 13095-1256 | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 1995 | KLX650R | FITS 93-96 KLX650R - 21013-1051 | FITS 94-96 KLX650R 13031-1380 | FITS 93-96 KLX650R – 11005-1719 – 100MM STD BORE | FITS 93-96 KLX650R - 18049-1664 | FITS 93-96 KLX650R - 18090-1300 | DENSO 0320008261 | 1995 | KLX650R | 1995 | KLX650R | KYB - USD - K328-L K328-R - CHROME OD 43MM - C/L 36 1/8" - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 102MM - AXLE OD 15MM & 22MM - FITS 93-96 KLX650R | FITS 93-94 KDX200 KDX250, 93-95 KLX650R, 93-96 KLX650C, 94-96 KLX250R, 97-03 KLX300R, LH 55020-1363-RZ, RH 55020-1423-RZ | 1995 | KLX650R | FITS 93-94 KDX200 KDX250, 93-95 KLX650R KLX250R, RH 13070-1264, LH 13070-1263 | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | FITS 93-95 KLX650R, 93-96 KLX650C, 95-96 KLX250R | 1995 | KLX650R | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | FITS 94-96 KX125 KX250 KX500 KX80 KLX250 KLX650, 95-06 KDX200, 97-05 KDX220, 95-96 KX100, KLX300 97-07, 46092-1186 | FITS 93-95 KLX650R, 94-95 KLX250R, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 1995 | KLX650R | ROTOR OD 250MM - ROTOR BOLT CIRCLE 4 ON 116MM | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 93-96 KLX650R – 11008-1270 | 1995 | KLX650R | FITS 93-96 KLX650R - 13064-1171 - SPLINE ID APPROX 19.75MM | 1995 | KLX650R | FITS 95-96 KLX650R – 13001-1438 | FITS 93-96 KLX650R KLX650C - 39061-1188 - BOTH OUTLETS ARE 20MM OD, CORE W5.25 X H9.5 X T1.25 | FITS 94-96 KLX650R - 39061-1208 | 1995 | KLX650R | GREEN FITS 95 KLX650R - LH 49089-5172-6W, RH 49089-5210-6W | R-1237 20mm AXLE DIA - BRG TO BRG 129mm - FITS KDX200 95-06, KDX250 91-94, KLR650R 93-96, KLX250R 94-96, KLX300R 97-07, KDX220 97-05 | 1995 | KLX650R | FITS 93-96 KLX650C, 93-95 KLX650R, 94 & 96 KLX250R | FITS 90-96 KX125 KX250, 91-94 KDX250, 93-96 KLX650C KLX650R, 95-06 KDX200, 97-05 KDX220 43059-1561 | 1995 | KLX650R | FITS 91-93 KX125 KX250 KDX250, 93-95 KLX650R | ROTOR OD 230MM - ID 100MM - ROTOR 6 ON A 115MM BC - FITS 93-96 KLX650C, 93-95 KLX650R - 41080-1368 | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 1995 | KLX650R | KYB - Spring thickness: 12.3MM OD - Spring Diameter: 88.5MM - Spring length as mounted: 240MM - Upper mount tab thickness: 26.8MM - Upper mount tab hole ID: 10MM - Lower Mount Internal Width: 22.7MM - Lower mount hole ID: 10MM - Eye to Eye: 432MM - FITS 93-96 KLX650R | 1995 | KLX650R | FITS 93-96 KLX650R - 21003-1252 - yellow to yellow wires .3-1.0 ohm - pickup coil 100-148 OHM | FITS 92-93 KX125 KX250, 93-96 KLX650R | 1995 | KLX650R | FITS 93-96 KLX650 C & R | 1995 | KLX650R | 1995 | KLX650R | FITS 93-96 KLX650R (I SEE VERY LITTLE DIFFERENCE IN THIS BOTTOM AND THE KLX650C 93-96) | 1995 | KLX650R | FITS 93-96 KLX650R (THE KLX650C WILL ALSO FIT BUT IT HAS THE IGNITION MOUNT) | 1995 | KLX650R | |||||||||||||||||||
| 1996 | KLX650R | LX650AE01XXXX | FITS 93-96 KLX650R | 1996 | KLX650R | KEIHIN CVK 792 40MM - 15001-1792 - FITS 93-96 KLX650R | 1996 | KLX650R | DENSO 21119-1368/1361 070000-2410/071000-0510 FITS 93-96 KLX650R – 21119-1361 - G/W TO W/Y IS 90-170 OHM | FITS 90-96 KX125 KX250, 90-04 KX500, 95-06 KDX200, 97-05 KDX220, 93-96 KLX650R, 94-96 KLX250, 97-07 KLX300 | FITS 93-96 KLX650R KLX250R, 97-07 KLX300R, 95-06 KDX200, 97-05 KDX220, 06-10 KLX250S - 12053-1328 | 1996 | KLX650R | FITS 93-96 KLX650R – 13095-1256 | 129700 - FITS 87-07 KLR650, 93-96 KLX650R KLX650C, 94-96 KLX250R, 97-07 KLX300R - 21121-1152 | 1996 | KLX650R | FITS 93-96 KLX650R - 21013-1051 | FITS 94-96 KLX650R 13031-1380 | FITS 93-96 KLX650R – 11005-1719 – 100MM STD BORE | FITS 93-96 KLX650R - 18049-1664 | FITS 93-96 KLX650R - 18090-1300 | 1996 | KLX650R | 1996 | KLX650R | KYB - USD - K328-L K328-R - CHROME OD 43MM - C/L 36 1/8" - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 102MM - AXLE OD 15MM & 22MM - FITS 93-96 KLX650R | 1996 | KLX650R | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | FITS 94-96 KX125 KX250, 94-03 KX500, 95-03 KDX200, 96 KLX650R, 97-03 KDX220, 97-03 KLX300 | 1996 | KLX650R | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 1996 | KLX650R | ROTOR OD 250MM - ROTOR BOLT CIRCLE 4 ON 116MM | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 93-96 KLX650R – 11008-1270 | 1996 | KLX650R | FITS 93-96 KLX650R - 13064-1171 - SPLINE ID APPROX 19.75MM | 1996 | KLX650R | FITS 95-96 KLX650R – 13001-1438 | FITS 93-96 KLX650R KLX650C - 39061-1188 - BOTH OUTLETS ARE 20MM OD, CORE W5.25 X H9.5 X T1.25 | FITS 94-96 KLX650R - 39061-1208 | 1996 | KLX650R | GREEN FITS 96 KLX650R - LH 49089-5269-6W, RH 49089-5270-6W | R-1237 20mm AXLE DIA - BRG TO BRG 129mm - FITS KDX200 95-06, KDX250 91-94, KLR650R 93-96, KLX250R 94-96, KLX300R 97-07, KDX220 97-05 | 1996 | KLX650R | FITS 95-96 KX125 & KX250, 96KLX650R, 96-03 KX500, 97-03 KLX300R | FITS 90-96 KX125 KX250, 91-94 KDX250, 93-96 KLX650C KLX650R, 95-06 KDX200, 97-05 KDX220 43059-1561 | 1996 | KLX650R | 92-94 KDX250, 92-02 KX125 KX250, 93-96 KLX650R, 94-04 KX500, 95-96 KLX250R, 97-07 KLX300R | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 1996 | KLX650R | KYB - Spring thickness: 12.3MM OD - Spring Diameter: 88.5MM - Spring length as mounted: 240MM - Upper mount tab thickness: 26.8MM - Upper mount tab hole ID: 10MM - Lower Mount Internal Width: 22.7MM - Lower mount hole ID: 10MM - Eye to Eye: 432MM - FITS 93-96 KLX650R | 1996 | KLX650R | FITS 93-96 KLX650R - 21003-1252 - yellow to yellow wires .3-1.0 ohm - pickup coil 100-148 OHM | FITS 92-93 KX125 KX250, 93-96 KLX650R | 1996 | KLX650R | FITS 93-96 KLX650 C & R | 1996 | KLX650R | 1996 | KLX650R | FITS 93-96 KLX650R (I SEE VERY LITTLE DIFFERENCE IN THIS BOTTOM AND THE KLX650C 93-96) | 1996 | KLX650R | FITS 93-96 KLX650R (THE KLX650C WILL ALSO FIT BUT IT HAS THE IGNITION MOUNT) | 1996 | KLX650R | ||||||||||||||||||||||||||
| YEAR | TYPE | VIN FRAME USA ONLY | ENGINE ID | ENGINE CASES | AIR BOX | YEAR | TYPE | CAM SHAFT EXHAUST | CAM SHAFT INTAKE | CARBURETOR | YEAR | TYPE | CDI | CHAIN GUIDE | CHAIN SLIDE | YEAR | TYPE | CLUTCH BASKET | COIL | YEAR | TYPE | CONDENSOR | CRANK SHAFT | CYLINDER | EXHAUST HEADER | EXHAUST MUFFLER | FLY WHEEL ROTOR | YEAR | TYPE | FOOT PEGS PASSENGER | FOOT PEG PASSENGER MOUNTS | YEAR | TYPE | FORK | FORK GUARDS | YEAR | TYPE | FORK GUARD MOUNTS | FRONT AXLE | FRONT BRAKE CALIPER | YEAR | TYPE | FRONT BRAKE CALIPER MOUNT | FRONT BRAKE LEVER | FRONT BRAKE MASTER CYLINDER | YEAR | TYPE | FRONT BRAKE ROTOR | FRONT HUB | HEAD | HEAD LIGHT BODY | KICK IDLER GEAR | YEAR | TYPE | KICK LEVER | KICK LEVER SHAFT | YEAR | TYPE | LEFT CONTROL SWITCH | ONE WAY CLUTCH GEAR | PISTON | PRIMARY CRANK GEAR | RADIATOR LEFT | RADIATOR RIGHT | REAR AXLE | YEAR | TYPE | RADIATOR SHROUDS | REAR HUB | YEAR | TYPE | REAR BRAKE CALIPER | REAR BRAKE HOSE | YEAR | TYPE | REAR BRAKE MASTER CYLINDER | REAR BRAKE ROTOR | REAR WHEEL SPACERS | YEAR | TYPE | SHOCK | SIDE STAND | YEAR | TYPE | STATOR | SWING ARM | SWING ARM PIN / AXLE | YEAR | TYPE | TIMING CHAIN TENSIONER | YEAR | TYPE | TRANSMISSION | YEAR | TYPE | TRANSMISSION OUT PUT SHAFT | TRIPLE TREE BOTTOM | YEAR | TYPE | TRIPLE TREE TOP | VOLTAGE REGULATOR | WIRE HARNESS | WATER PUMP IMPELLER | YEAR | TYPE |
| 1993 | KLX650C | LX650AE00XXXX | 1993 | KLX650C | CVK V327 | 1993 | KLX650C | 1993 | KLX650C | FITS 93-96 KLX650C – 13095-1274 | 1993 | KLX650C | FITS 93-96 KLX650C 13031-1378 | 1993 | KLX650C | 1993 | KLX650C | KYB - USD - K328-R K555-L - CHROME OD 43MM - C/L 36" - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 102MM - AXLE OD 15MM & 22MM - FITS 93-96 KLX650C | FITS 93-94 KDX200 KDX250, 93-95 KLX650R, 93-96 KLX650C, 94-96 KLX250R, 97-03 KLX300R, LH 55020-1363-RZ, RH 55020-1423-RZ | 1993 | KLX650C | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | FITS 93-95 KLX650R, 93-96 KLX650C, 95-96 KLX250R | 1993 | KLX650C | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 1993 | KLX650C | ROTOR OD 290MM - ROTOR ID - 100MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 93-96 KLX650C | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 84-86 KL600, 87-07 KLR650, 85-05 KLR250, 09-10 KL250, 93-96 KLX650C - 23005-1052 | FITS 93-96 KLX650R | 1993 | KLX650C | 1993 | KLX650C | FITS KLX650C 1993-1996 | FITS 93-96 KLX650R KLX650C - 39061-1188 - BOTH OUTLETS ARE 20MM OD, CORE W5.25 X H9.5 X T1.25 | FITS 93 KLX650R, 93-96 KLX650C - 39061-1189 | 1993 | KLX650C | R-1250 - AXLE DIA 20MM - BRG TO BRG 138MM - ROTOR 6 ON A 115MM BC - 36 SPOKES - FITS 93 KLX650C ONLY | 1993 | KLX650C | FITS 93-96 KLX650C, 93-95 KLX650R, 94 & 96 KLX250R | FITS 90-96 KX125 KX250, 91-94 KDX250, 93-96 KLX650C KLX650R, 95-06 KDX200, 97-05 KDX220 43059-1561 | 1993 | KLX650C | ROTOR OD 230MM - ID 100MM - ROTOR 6 ON A 115MM BC - FITS 93-96 KLX650C, 93-95 KLX650R - 41080-1368 | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 1993 | KLX650C | 1993 | KLX650C | FITS 93-96 KLX650C - 21003-1255 | 1993 | KLX650C | FITS 93-96 KLX650 C & R | 1993 | KLX650C | 1993 | KLX650C | FITS 93-96 KLX650C (I SEE VERY LITTLE DIFFERENCE IN THIS BOTTOM AND THE KLX650R 93-96) | 1993 | KLX650C | FITS 93-96 KLX650C (THE KLX650R 93-96 WILL FIT BUT THERE IS NO IGNITION MOUNT) | 1993 | KLX650C | |||||||||||||||||||||||||||||||||||||
| 1994 | KLX650C | LX650AE00XXXX | 1994 | KLX650C | 1994 | KLX650C | 1994 | KLX650C | FITS 93-96 KLX650C – 13095-1274 | 1994 | KLX650C | FITS 93-96 KLX650C 13031-1378 | 1994 | KLX650C | 1994 | KLX650C | KYB - USD - K328-R K555-L - CHROME OD 43MM - C/L 36" - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 102MM - AXLE OD 15MM & 22MM - FITS 93-96 KLX650C | FITS 93-94 KDX200 KDX250, 93-95 KLX650R, 93-96 KLX650C, 94-96 KLX250R, 97-03 KLX300R, LH 55020-1363-RZ, RH 55020-1423-RZ | 1994 | KLX650C | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | FITS 93-95 KLX650R, 93-96 KLX650C, 95-96 KLX250R | 1994 | KLX650C | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 1994 | KLX650C | ROTOR OD 290MM - ROTOR ID - 100MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 93-96 KLX650C | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 84-86 KL600, 87-07 KLR650, 85-05 KLR250, 09-10 KL250, 93-96 KLX650C - 23005-1052 | FITS 93-96 KLX650R | 1994 | KLX650C | 1994 | KLX650C | FITS KLX650C 1993-1996 | FITS 93-96 KLX650R KLX650C - 39061-1188 - BOTH OUTLETS ARE 20MM OD, CORE W5.25 X H9.5 X T1.25 | FITS 93 KLX650R, 93-96 KLX650C - 39061-1189 | 1994 | KLX650C | R-1250 - AXLE DIA 20MM - BRG TO BRG 111MM - ROTOR 6 ON A 115MM BC - 36 SPOKES - FITS 94-96 KLX650C - 41034-1234 | 1994 | KLX650C | FITS 93-96 KLX650C, 93-95 KLX650R, 94 & 96 KLX250R | FITS 90-96 KX125 KX250, 91-94 KDX250, 93-96 KLX650C KLX650R, 95-06 KDX200, 97-05 KDX220 43059-1561 | 1994 | KLX650C | ROTOR OD 230MM - ID 100MM - ROTOR 6 ON A 115MM BC - FITS 93-96 KLX650C, 93-95 KLX650R - 41080-1368 | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 1994 | KLX650C | 1994 | KLX650C | FITS 93-96 KLX650C - 21003-1255 | 1994 | KLX650C | FITS 93-96 KLX650 C & R | 1994 | KLX650C | 1994 | KLX650C | FITS 93-96 KLX650C (I SEE VERY LITTLE DIFFERENCE IN THIS BOTTOM AND THE KLX650R 93-96) | 1994 | KLX650C | FITS 93-96 KLX650C (THE KLX650R 93-96 WILL FIT BUT THERE IS NO IGNITION MOUNT) | 1994 | KLX650C | ||||||||||||||||||||||||||||||||||||||
| 1995 | KLX650C | LX650AE00XXXX | 1995 | KLX650C | 1995 | KLX650C | 1995 | KLX650C | FITS 93-96 KLX650C – 13095-1274 | 1995 | KLX650C | FITS 93-96 KLX650C 13031-1378 | 1995 | KLX650C | 1995 | KLX650C | KYB - USD - K328-R K555-L - CHROME OD 43MM - C/L 36" - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 102MM - AXLE OD 15MM & 22MM - FITS 93-96 KLX650C | FITS 93-94 KDX200 KDX250, 93-95 KLX650R, 93-96 KLX650C, 94-96 KLX250R, 97-03 KLX300R, LH 55020-1363-RZ, RH 55020-1423-RZ | 1995 | KLX650C | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | FITS 93-95 KLX650R, 93-96 KLX650C, 95-96 KLX250R | 1995 | KLX650C | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 1995 | KLX650C | ROTOR OD 290MM - ROTOR ID - 100MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 93-96 KLX650C | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 84-86 KL600, 87-07 KLR650, 85-05 KLR250, 09-10 KL250, 93-96 KLX650C - 23005-1052 | FITS 93-96 KLX650R | 1995 | KLX650C | 1995 | KLX650C | FITS KLX650C 1993-1996 | FITS 93-96 KLX650R KLX650C - 39061-1188 - BOTH OUTLETS ARE 20MM OD, CORE W5.25 X H9.5 X T1.25 | FITS 93 KLX650R, 93-96 KLX650C - 39061-1189 | 1995 | KLX650C | R-1250 - AXLE DIA 20MM - BRG TO BRG 111MM - ROTOR 6 ON A 115MM BC - 36 SPOKES - FITS 94-96 KLX650C - 41034-1234 | 1995 | KLX650C | FITS 93-96 KLX650C, 93-95 KLX650R, 94 & 96 KLX250R | FITS 90-96 KX125 KX250, 91-94 KDX250, 93-96 KLX650C KLX650R, 95-06 KDX200, 97-05 KDX220 43059-1561 | 1995 | KLX650C | ROTOR OD 230MM - ID 100MM - ROTOR 6 ON A 115MM BC - FITS 93-96 KLX650C, 93-95 KLX650R - 41080-1368 | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 1995 | KLX650C | 1995 | KLX650C | FITS 93-96 KLX650C - 21003-1255 | 1995 | KLX650C | FITS 93-96 KLX650 C & R | 1995 | KLX650C | 1995 | KLX650C | FITS 93-96 KLX650C (I SEE VERY LITTLE DIFFERENCE IN THIS BOTTOM AND THE KLX650R 93-96) | 1995 | KLX650C | FITS 93-96 KLX650C (THE KLX650R 93-96 WILL FIT BUT THERE IS NO IGNITION MOUNT) | 1995 | KLX650C | ||||||||||||||||||||||||||||||||||||||
| 1996 | KLX650C | LX650AE00XXXX | 1996 | KLX650C | 1996 | KLX650C | DENSO 21119-1368 07000-2410 | 1996 | KLX650C | FITS 93-96 KLX650C – 13095-1274 | 1996 | KLX650C | FITS 93-96 KLX650C 13031-1378 | 32000-8020 10NX | 1996 | KLX650C | 1996 | KLX650C | KYB - USD - K328-R K555-L - CHROME OD 43MM - C/L 36" - UPPER 51.9MM - LOWER 56.6MM - BRAKE MOUNT C/L 102MM - AXLE OD 15MM & 22MM - FITS 93-96 KLX650C | FITS 93-94 KDX200 KDX250, 93-95 KLX650R, 93-96 KLX650C, 94-96 KLX250R, 97-03 KLX300R, LH 55020-1363-RZ, RH 55020-1423-RZ | 1996 | KLX650C | FITS 93-96 KLX650R KLX650C, 94-96 KLX250R, 95-04 KDX200, 97-04 KLX300R - 41068-1352 | FITS 93-95 KLX650R, 93-96 KLX650C, 95-96 KLX250R | 1996 | KLX650C | FITS 94-05 KX125, 94-07 KX250, 94-04 KX500, 04-08 KX250F, 06-08 KX450F, 93-96 KLX650R KLX650C, 95-06 KDX200, 97-05 KDX220, 97-07 KLX300 | 1996 | KLX650C | ROTOR OD 290MM - ROTOR ID - 100MM - ROTOR BOLT CIRCLE 4 ON 116MM - FITS 93-96 KLX650C | F-1240 - AXLE OD 15MM - BRG TO BRG 97MM - FITS 92-94 KDX250, 93-94 KDX200, 93-96 KLX650R, 93-96 KLX650C, KLX250R, 97-07 KLX300R | FITS 84-86 KL600, 87-07 KLR650, 85-05 KLR250, 09-10 KL250, 93-96 KLX650C - 23005-1052 | FITS 93-96 KLX650R | 1996 | KLX650C | 1996 | KLX650C | FITS KLX650C 1993-1996 | FITS 93-96 KLX650R KLX650C - 39061-1188 - BOTH OUTLETS ARE 20MM OD, CORE W5.25 X H9.5 X T1.25 | FITS 93 KLX650R, 93-96 KLX650C - 39061-1189 | 1996 | KLX650C | R-1250 - AXLE DIA 20MM - BRG TO BRG 111MM - ROTOR 6 ON A 115MM BC - 36 SPOKES - FITS 94-96 KLX650C - 41034-1234 | 1996 | KLX650C | FITS 93-96 KLX650C, 93-95 KLX650R, 94 & 96 KLX250R | FITS 90-96 KX125 KX250, 91-94 KDX250, 93-96 KLX650C KLX650R, 95-06 KDX200, 97-05 KDX220 43059-1561 | 1996 | KLX650C | ROTOR OD 230MM - ID 100MM - ROTOR 6 ON A 115MM BC - FITS 93-96 KLX650C, 93-95 KLX650R - 41080-1368 | 20MM AXLE HOLE X WIDTH 21.5MM FITS 89 KX125 KX250 KX500, 89-05 KDX200, 91-94 KDX250, 93-96 KLX650 C & R, 94-96 KLX250R, 97-05 KLX300R KDX220R | 1996 | KLX650C | 1996 | KLX650C | FITS 93-96 KLX650C - 21003-1255 | 1996 | KLX650C | FITS 93-96 KLX650 C & R | 1996 | KLX650C | 1996 | KLX650C | FITS 93-96 KLX650C (I SEE VERY LITTLE DIFFERENCE IN THIS BOTTOM AND THE KLX650R 93-96) | 1996 | KLX650C | FITS 93-96 KLX650C (THE KLX650R 93-96 WILL FIT BUT THERE IS NO IGNITION MOUNT) | 1996 | KLX650C | ||||||||||||||||||||||||||||||||||||
| YEAR | TYPE | VIN FRAME USA ONLY | ENGINE ID | ENGINE CASES | AIR BOX | YEAR | TYPE | CAM SHAFT EXHAUST | CAM SHAFT INTAKE | CARBURETOR | YEAR | TYPE | CDI | CHAIN GUIDE | CHAIN SLIDE | YEAR | TYPE | CLUTCH BASKET | COIL | YEAR | TYPE | CONDENSOR | CRANK SHAFT | CYLINDER | EXHAUST HEADER | EXHAUST MUFFLER | FLY WHEEL ROTOR | YEAR | TYPE | FOOT PEGS PASSENGER | FOOT PEG PASSENGER MOUNTS | YEAR | TYPE | FORK | FORK GUARDS | YEAR | TYPE | FORK GUARD MOUNTS | FRONT AXLE | FRONT BRAKE CALIPER | YEAR | TYPE | FRONT BRAKE CALIPER MOUNT | FRONT BRAKE LEVER | FRONT BRAKE MASTER CYLINDER | YEAR | TYPE | FRONT BRAKE ROTOR | FRONT HUB | HEAD | HEAD LIGHT BODY | KICK IDLER GEAR | YEAR | TYPE | KICK LEVER | KICK LEVER SHAFT | YEAR | TYPE | LEFT CONTROL SWITCH | ONE WAY CLUTCH GEAR | PISTON | PRIMARY CRANK GEAR | RADIATOR LEFT | RADIATOR RIGHT | REAR AXLE | YEAR | TYPE | RADIATOR SHROUDS | REAR HUB | YEAR | TYPE | REAR BRAKE CALIPER | REAR BRAKE HOSE | YEAR | TYPE | REAR BRAKE MASTER CYLINDER | REAR BRAKE ROTOR | REAR WHEEL SPACERS | YEAR | TYPE | SHOCK | SIDE STAND | YEAR | TYPE | STATOR | SWING ARM | SWING ARM PIN / AXLE | YEAR | TYPE | TIMING CHAIN TENSIONER | YEAR | TYPE | TRANSMISSION | YEAR | TYPE | TRANSMISSION OUT PUT SHAFT | TRIPLE TREE BOTTOM | YEAR | TYPE | TRIPLE TREE TOP | VOLTAGE REGULATOR | WIRE HARNESS | WATER PUMP IMPELLER | YEAR | TYPE |
